CONSISTENCY - RELIABILITY - EXCELLENT WORKMANSHIP BRI-STEEL MANUFACTURING 2125 - 64 AVE EDMONTON ALBERTA T 6 P 1 Z 4 PH: (780) 469 -6603 FAX: (780) 469 -6986 www. bri-steel. com Kenton Dechant Manager of Quality and R&D Direct: (780) 469 -6603 Email: kdechant@bri-steel. com Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

Bri-Steel Mission Statement Bri-Steel Manufacturing is committed to meeting customer-specific requests covering Power, Upstream, Midstream and Downstream industries across Canada and internationally. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

About Bri-Steel Manufacturing is a state of the art facility that produces Large Diameter Seamless Steel Pipe in Canada. Bri-Steel is capable of producing pipe sizes ranging from Outside Diameters of 14 through 36 inches, and Wall Thicknesses up to 2. 343 inches in CSA, ASTM, ASME and API specifications. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

About Bri-Steel Manufacturing Bri-Steel produces pipe by a process called Thermal Pipe Expansion or "TPE". This process is performed by using an engineered-size mother tube, heating it to 900 deg C by induction heating, and pushing it over a controlled ID mandrel to expand the mother tube to a specific pipe size. After that, the pipe is tested and finished to the requested industry specifications. The TPE technology is not new to our piping markets here in North America, but is new to being utilized in North America. Utilizing TPE allows Bri-Steel to produce pipe sizes not normally produced by traditional steel pipe mills. When a 27 -inch OD 0. 965 inch Wall Thickness is optimal for your project, it is now easily available to you. There is no longer a need to re-engineer jobs to suit the manufacturer, saving time and money. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

About Bri-Steel Manufacturing By using TPE, rather than traditional manufacturing methods, we can change sizes quickly, allowing us to react quickly to our customers' needs and demands. It only takes 3 hours to change a pipe size, including the time to cool down and re-heat. With this efficient process, smaller order quantities are no problem to produce. Bri-Steel is able to produce Pipe from multiple sizes of mother tubes, resulting in greater flexibility in production. Utilizing Bri-Steel and our flexible production, we can adjust our production schedules to accommodate your scheduling, and make adjustments with only a week notice. That way if plans change we can adapt. Bri-Steel Manufacturing is an API 5 L, APIQ 1, PED & ISO 9001 approved facility. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

BRI-STEEL ESTABLISHES NEW BENCHMARK "Today marks yet another historic day at Bri-Steel Manufacturing. This was not only the largest we made but the greatest expansion, over 12 inches, " said Vern Gorman, Bri-Steel Manufacturing's Plant Manager. ( June 17 th 2013 ) "This opens the doors for opportunities to produce not only 36 inch, but also 32 -34 inch, creating even more options and opportunities for the consumers when engineering their projects. Producing standard wall is always the most difficult in large seamless production. Success in standard provides the confidence to produce all the heavier walls up to our maximum thickness. Now our production range from 14" through 36" OD with wall thickness up to 2 3/8" thick is now proven and official, " said Vern. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

Bri-Steel Quality Assurance Quality Policy We are committed to the manufacture of steel pipe that meets our customers’ requirements and all applicable industry standards. By building lasting relationships with our suppliers and clients, and by continually improving the effectiveness of our Quality Management System, we will continually improve our product’s consistency, reliability, and workmanship. Quality Objectives We are committed to: The best receiving, inspection of raw material from our suppliers. Continually improve the quality of our products thru technology, training and improved inspection techniques. Perform scheduled reviews with major clients, as required to maintain continual awareness of our client’s needs and product concerns. Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

Manufacturing Specifications Bri-Steel can produce Seamless Carbon Steel Pipe in Sizes of 14" through 36“ OD with Wall Thicknesses up to 2 3/8". Standard production will be done on Standard Pipe Scheduled products, however we have the unique ability to custom produce diameters and wall thicknesses in the following parameters. ASTM/ASME A/SA 53 Welded & Seamless Steel Pipe Gr. A: 30 ksi (205 MPa) YS, 48 ksi (330 MPa) UTS, Not Impact Tested Gr. B: 35 ksi (240 MPa) YS, 60 ksi (415 MPa) UTS, Not Impact Tested NPS 14 to 36 SMLS, All Wall Thicknesses Must Complete one of Hydrotesting, UT or ET End Finishes: Plain End, Bevel ASTM/ASME A/SA 106 Grade B/C Seamless Steel Pipe for High Temperature Service Gr. B: 35 ksi (240 MPa) YS, 60 ksi (415 MPa) UTS, Not Impact Tested Gr. C: 40 ksi (275 MPa) YS, 70 ksi (485 MPa) UTS, Not Impact Tested NPS 14 to 36 SMLS, All Wall Thicknesses Must Complete one of Hydrotesting, UT or ET End Finishes: Plain End, Bevel Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America… CSA Z 245. 1 Steel Pipe Gr. 241: 241 -495 MPa YS, 414 -760 MPa UTS Gr. 290: 290 -495 MPa YS, 414 -760 MPa UTS Gr. 359: 359 -530 MPa YS, 455 -760 MPa UTS Gr. 386: 386 -540 MPa YS, 490 -760 MPa UTS Gr. 414: 414 -565 MPa YS, 517 -760 MPa UTS Gr. 448: 448 -600 MPa YS, 531 -760 MPa UTS Category I: Not Impact Tested Category II: Impact 27 J *; 60% Shear Category III: Impact 27 J *; No Shear Requirement * End User specifies the test temperature. NPS 14 to 36 SMLS, All Wall Thicknesses Hydrostatic Testing and UT are Mandatory End Finishes: Plain End, Bevel

Manufacturing Specifications API 5 L Specification for Line Pipe Gr. B PSL 1: 35. 5 ksi (245 MPa) YS, 60. 2 ksi (415 MPa) UTS, Not Impact Tested Gr. X 42 PSL 1: 42. 1 ksi (290 MPa) YS, 60. 2 ksi (415 MPa) UTS, Not Impact Tested Gr. X 46 PSL 1: 46. 4 ksi (320 MPa) YS, 63. 1 ksi (435 MPa) UTS, Not Impact Tested Gr. X 52 PSL 1: 52. 2 ksi (360 MPa) YS, 66. 7 ksi (460 MPa) UTS, Not Impact Tested Gr. X 56 PSL 1: 56. 6 ksi (390 MPa) YS, 71. 1 ksi (490 MPa) UTS, Not Impact Tested Gr. X 60 PSL 1: 60. 2 ksi (415 MPa) YS, 75. 4 ksi (520 MPa) UTS, Not Impact Tested Gr. X 65 PSL 1: 65. 3 ksi (450 MPa) YS, 77. 6 ksi (535 MPa) UTS, Not Impact Tested Gr. B PSL 2: 35. 5 ksi (245 MPa) YS, 60. 2 ksi (415 MPa) UTS, Impact 27 J at 0ºC Gr. X 42 PSL 2: 42. 1 ksi (290 MPa) YS, 60. 2 ksi (415 MPa) UTS, Impact 27 J at 0ºC NPS 14 to 36 SMLS, All Wall Thicknesses Hydrostatic Testing is Mandatory, UT & ET when specified by end user End Finishes: Plain End, Bevel Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

Manufacturing Specifications ASTM/ASME A/SA 333 Grade 6 Seamless & Welded Steel Pipe for Low Temp Service Gr. 6: 35 ksi (240 MPa) YS, 60 ksi (415 MPa) TS, Impact 18 J at -45°C NPS 14 to 36 SMLS, All Wall Thicknesses Must Complete one of Hydrotesting, UT or ET End Finishes: Plain End, Bevel NACE MR 0103 Materials Resistant to Sulphide Stress Cracking in Corrosive Petroleum Refining Environments For carbon and low-alloy SMLS pipe steels, the following apply Max 1% Ni, Max 22 HRC Hardness, No cold work permitted NACE MR 0175 / ISO 15156 Materials for Use in H 2 S-Containing Environments in Oil & Gas Production Refer to MR 0175/ISO 15156 -2 Annex A 2 for Region 3 Applications For carbon and low-alloy hot-rolled SMLS pipe steels, the following apply Max 1% Ni, Max 22 HRC Hardness, No cold work permitted Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

MTR Sample - (BSM-3125) ASTM A 333 Get your latest MTRs: www. bri-steel. com/mtr Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…

CONSISTENCY - RELIABILITY - EXCELLENT WORKMANSHIP THANK YOU! Kenton Dechant Manager of Quality and R&D Direct: (780) 469 -6603 Email: kdechant@bri-steel. com Manufacturer of 14” to 36” Seamless Pipe Bri-Steel Manufacturing is the only Thermal Pipe Expansion mill in North America…
