Connective Tissue VIBS 443602 Very loose connective tissue
Connective Tissue VIBS 443/602
Very loose connective tissue of subdermis with adipocytes and fibroblasts 1. Adipocyte, 2. Fibroblast, and 3. Loose connective tissue
195 Fat cells of Fetal jaw
32409 • 32409 Slide 201: intestine, toluidine blue stain; 16 x 1. Goblet cells 2. Intestinal absorptive cells 3. Crypts 4. Central lacteal 5. Mast cell 6. Muscularis mucosa
32409 rat intestine
447 Duodenum, monkey (toluidine blue)
447
408 Skin, foot
109 Skin hand monkey
105 Fingertip, monkey
108 Skin, scalp
195 skin of Fetal jaw
19713 Kidney Capsule, urinary vascular poles slide #19713
202 Fibroblasts in tendon
EM 8 e EM 8 E: Fibroblast cells and collagen fibrils 1. Collagen fibril 2. Fibroblast nucleus 3. Rough endoplasmic reticulum
EM 8 d: mast cell 1. Nucleus 2. Granules
• Mast cell in human testis UT 166 34455
118 Triad with bile duct and central vein Liver & spleen with colloidal carbon, rat
118 Liver & spleen with colloidal carbon, rat
118 Liver & spleen with colloidal carbon, rat
Esophagus and trachea, monkey – 242 glands in trachea
432
432 Lung with bronchi – macrophage
19714
EM 18: Liver; 17, 333 x 1. Hepatic sinusoid 2. Bile canaliculi 3. Space of Disse
EM 8 h: Macropahge in testis; 30, 000 x 1. Enlarged basal lamina 2. Heterophagic vacuole 3. Leydig cell cytoplasm 4. Nucleolus 5. Myoid cell
140 Cardiac stomach w/chronic infection
140 Cardiac stomach w/chronic infection
153 Large intestine or Colon, monkey
EM 10 d: edge of a Schwann cell showing Type IV collagen of basal lamina and Type I collagen of supporting connective tissue 1. Basal lamina 2. Type I collagen
426 Renal artery with nerves
218 Spleen (reticulum stain)capsule and reticulum fibers
16 Internal and external laminas of elastin in the wall of the renal artery 1. Internal elastic lamina 2. External elastic lamina 3. Smooth muscle cell 4. Connective tissue
EM 9: Arteriole/Smooth muscle; 30, 000 x 1. Endothelial cell 2. Internal elastic membrane 3. Smooth muscle cell in tunica media
427 Aorta
432 Elastic artery of Lung with bronchi
196 Vein of Spermatic cord
126 Bile duct with portal vein, monkey
Elastic cartilage in pina of ear #19762
165 UT 165 larger secondary spermatocytes and smaller Golgi phase spermatids human testis
417 Spleen - capsule
Penis – transitional epithelium and surrounding 277 spongy cavernous of penal urethra
136 Skeletal muscle of Tongue, monkey
cartilage growth in endochondral bone formation of the Fetal finger 220
Fibroblasts with near by collagen, nerve cells, smooth muscle cells 19716
Fibroblasts, nerve cells, smooth muscle 34463 cells (toluidine blue)
- Slides: 50
