Connective Tissue VIBS 443602 Very loose connective tissue

Connective Tissue VIBS 443/602

Very loose connective tissue of subdermis with adipocytes and fibroblasts 1. Adipocyte, 2. Fibroblast, and 3. Loose connective tissue

195 Fat cells of Fetal jaw

32409 • 32409 Slide 201: intestine, toluidine blue stain; 16 x 1. Goblet cells 2. Intestinal absorptive cells 3. Crypts 4. Central lacteal 5. Mast cell 6. Muscularis mucosa

32409 rat intestine

447 Duodenum, monkey (toluidine blue)

447

408 Skin, foot

109 Skin hand monkey

105 Fingertip, monkey

108 Skin, scalp

195 skin of Fetal jaw

19713 Kidney Capsule, urinary vascular poles slide #19713

202 Fibroblasts in tendon

EM 8 e EM 8 E: Fibroblast cells and collagen fibrils 1. Collagen fibril 2. Fibroblast nucleus 3. Rough endoplasmic reticulum

EM 8 d: mast cell 1. Nucleus 2. Granules

• Mast cell in human testis UT 166 34455

118 Triad with bile duct and central vein Liver & spleen with colloidal carbon, rat

118 Liver & spleen with colloidal carbon, rat

118 Liver & spleen with colloidal carbon, rat

Esophagus and trachea, monkey – 242 glands in trachea

432

432 Lung with bronchi – macrophage

19714

EM 18: Liver; 17, 333 x 1. Hepatic sinusoid 2. Bile canaliculi 3. Space of Disse

EM 8 h: Macropahge in testis; 30, 000 x 1. Enlarged basal lamina 2. Heterophagic vacuole 3. Leydig cell cytoplasm 4. Nucleolus 5. Myoid cell

140 Cardiac stomach w/chronic infection

140 Cardiac stomach w/chronic infection

153 Large intestine or Colon, monkey

EM 10 d: edge of a Schwann cell showing Type IV collagen of basal lamina and Type I collagen of supporting connective tissue 1. Basal lamina 2. Type I collagen

426 Renal artery with nerves

218 Spleen (reticulum stain)capsule and reticulum fibers

16 Internal and external laminas of elastin in the wall of the renal artery 1. Internal elastic lamina 2. External elastic lamina 3. Smooth muscle cell 4. Connective tissue

EM 9: Arteriole/Smooth muscle; 30, 000 x 1. Endothelial cell 2. Internal elastic membrane 3. Smooth muscle cell in tunica media

427 Aorta

432 Elastic artery of Lung with bronchi

196 Vein of Spermatic cord

126 Bile duct with portal vein, monkey

Elastic cartilage in pina of ear #19762

165 UT 165 larger secondary spermatocytes and smaller Golgi phase spermatids human testis

417 Spleen - capsule

Penis – transitional epithelium and surrounding 277 spongy cavernous of penal urethra

136 Skeletal muscle of Tongue, monkey

cartilage growth in endochondral bone formation of the Fetal finger 220

Fibroblasts with near by collagen, nerve cells, smooth muscle cells 19716

Fibroblasts, nerve cells, smooth muscle 34463 cells (toluidine blue)
