Confidential Information Management Confidential NDA Customer Without Any Marking Customer Presentation Paper Copy PDF Copy PPT Copy YES YES YES NO NO NO NO Panasonic System Networks Co. , Ltd. NO NO Model Name Confidential Model Number YES NO NO NO Panasonic Confidential - Under NDA - YES Product Information YES NO NO Rev. xx Dec. 2009 Confidential Internal Use Only

Confidential Compact Live Model Switcher Name Tentative Model AW-HS 50 Number Product Information Rev. xx 0. 92 April Rev. Dec. 2010 2009 Panasonic System Networks Co. , Ltd.

Confidential HS Series Switcher Roadmap 2007 2008 2009 2010 16 inputs AV-HS 450 8 inputs AV-HS 400 A Successor Model of HS 300 l. Affordable HD/SD Switcher l. Simple Operation New 6 inputs AV-HS 300 5 inputs AW-HS 50 Broadcast and Multimedia Business Unit 3

Specifications Successor model of AV-HS 300 Key Features l Multi-format HD： 1080/59. 94 i, 50 i, 1080/24 Psf, 1080/23. 98 Psf, 720/59. 94 p, 50 p SD： 480/59. 94 i（NTSC）, 576/50 i(PAL） l Video Input 4 x HD/SD-SDI, 1 x DVI-D FS on all inputs (always turned on, No Gen-lock In/out) Up-converter: 2 ch, Dot by dot mode: 4 ch l Video Output: 3 x HD/SD-SDI(PGMx 2, OUT 2), 1 x DVI-D(OUT 3) ＯＵＴ１(ＳＤＩ): 　 Assignable w/o OSD , 2 connectors ＯＵＴ２(ＳＤＩ), ＯＵＴ３(ＤＶＩ): 　Assignable Compact Switcher AW-HS 50 Availability 2010/07 Broadcast and Multimedia Business Unit l 1 x AUX Bus (Supports Dissolve effect) l 1 x Multi-view display(4, 5, 6, 9 or 10 splits) w/ Audio level meter & camera status indicator l 1 x Pin. P, 1 x Keyer (Lum/Linear/Chroma) l Slide Fader (not T-bar) l Link with AW-RP 50(new camera controller) by IP l Compact Size: W 210 mm x D 177 mm x H 66 mm l DC power supply (include AC Adaptor) 4

Confidential Key features Simple Operation and Versatile Functions l. Half rack mount size l. Support Key, Pin. P and Multi-Viewer l 2 ch build-in up-convertor Affordable Compact HD/SD Switcher l 5 inputs (4 x. HD/SD SDI+DVI), 4 outputs (3 x. HD/SD SDI+DVI) l. All inputs support frame synchronizer IP control and Link with AW-RP 50 l. Camera Monitoring Function l. Focus Assist Faction (Remote Camera Controller) Broadcast and Multimedia Business Unit 5

Confidential 50 series debut Ultimate System Expandability with IP control • Can used general IP network technology for AW-HE 50 camera integration • Up to 5 AW-RP 50 s can be connected to one AW-HE 50. • Camera video monitor can be selected by AW-HS 50 synced AW-RP 50 operation Site B Site C IP Network Site A AW-RP 50 & AW-HS 50 Broadcast and Multimedia Business Unit

Confidential Front and Rear View Pin. P Ten tativ e OSD User friendly on-screen menu Key Support Luminance, Liner and Chroma AUX Support mix transition Tent ative Cross Point 5 cross point buttons Possible to select maximum 10 inputs with SHIFT button Outputs 3 x. HD/SD SDI + DVI-D Output 1(2 connecters), Output 2 and DVI: Can be assigned from PGM, PVW, AUX, MV, CLN and KEYOUT Inputs 4 x. HD/SD SDI + DVI-D IP control interface Broadcast and Multimedia Business Unit 7

Comparison Confidential ＲｏｌａｎｄｄａｔａｖｉｄｅｏＰａｎａｓｏｎｉｃ LVS-800 SE-2000 AW-HS 50 Format Analog ＳＤＨＤＨＤ／ＳＤ Number of Input ８５ 5 ＳＤＩ × ４（３）４ Analog ８（６） × × ＨＤＭＩ × × × ＰＣ２（ＲＧＢ）１（２）（ＤＶＩ－Ｄ）１（ＤＶＩ－Ｄ）ＳＤＩ × ２３ Analog ４１ × ＤＶＩ × １１ Input × XLR(4 ch) × Output × XLR(2 ch) × × Color Corrector Up Convertor Multi-Viewer Fader Wipe, Pin. P, Chroma-Key, DSK × × × T bar Wipe, Pin. P, Chroma-Key, DSK × × ○ T bar Wipe, Pin. P, Chroma-Key ４ｃｈ 2ｃｈ ○ Slider Camera Control × × ○ Link with AW-RP 50 List Price $3, 795 $6, 000 Around $4, 000 Release Date 2009/9 2009/10 2010/7　 Model Number Video Input Output Analog Audio Genlock Video Effects Functions User Interface Broadcast and Multimedia Business Unit 8

Confidential Application: Academic Meeting POINT 1. Two independent outputs 2. Build-in multi viewer AW-HE 100 for shooting a presenter P 2 Gear for Clip Playing SDI Let’s note for Presentation Switcher AW-HS 50 DVI Projector SDI(PGM) SDI(AUX) DVI-D(Multi-view) PC monitor for Monitoring Broadcast and Multimedia Business Unit P 2 Gear for Recoding PC for Authoring 9

Application: School Confidential POINT 1. Build-in chroma. Keyer 2. Picture in Picture Let’s note for Titling Switcher AW-HS 50 DVI AW-HE 100 for shooting a presenter SDI(PGM) SDI(AUX) DVI-D(Multi-view) PC monitor for Monitoring Broadcast and Multimedia Business Unit Streaming Server Internet P 2 Gear for Recoding 10

Application: Remote Studio Confidential POINT 1. Link with AWRP 50 2. Still Picture Memory x 1 AW-HE 870 & AW-PH 405 Feeding Video SDI RS 422 Switcher AW-HS 50 IP Let’s note for image transfer to the picture Memory SDI(AUX, Multi-view) Remote Camera Controller AW-RP 50 l. Interlock SDI(PGM) Camera selection is interlocked with AUX bus. l. Focus assist Call full-screen display with simple operation on the multi-view On-air Broadcast and Multimedia Business Unit 11

THANK YOU Broadcast and Multimedia Business Unit 12
