- Slides: 32
![Computer Architecture CSE 3322 Lecture 2 Computer Architecture CSE 3322 Lecture 2](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-1.jpg)
Computer Architecture CSE 3322 Lecture 2
![Why Study Computer Architecture Learn to Design Computers Processors Designed by Few Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-2.jpg)
Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few Semiconductor Companies
![Why Study Computer Architecture Learn to Design Computers Processors Designed by Few Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-3.jpg)
Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few Semiconductor Companies • Learn to Design Device Controllers
![Why Study Computer Architecture Learn to Design Computers Processors Designed by Few Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-4.jpg)
Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few Semiconductor Companies • Learn to Design Device Controllers • Learn to Design More Optimum Software!
![Why Study Computer Architecture Learn to Design Computers Processors Designed by Few Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-5.jpg)
Why Study Computer Architecture • Learn to Design Computers – Processors Designed by Few Semiconductor Companies • Learn to Design Device Controllers • Learn to Design More Optimum Software! • Learn to Design More Optimum Systems!
![How to Improve Application Performance How to Improve Application Performance ?](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-6.jpg)
How to Improve Application Performance ?
![How to Improve Application Performance Algorithm Language and Compiler Processor and How to Improve Application Performance ? • • Algorithm Language and Compiler Processor and](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-7.jpg)
How to Improve Application Performance ? • • Algorithm Language and Compiler Processor and Memory System I/O System and Devices
![Computer Generations Overview Generation Technology 0 1945 50 Relays Principle Product Adj Price Perfomance Computer Generations Overview Generation Technology 0 1945 -50 Relays Principle Product Adj Price/ Perfomance](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-8.jpg)
Computer Generations Overview Generation Technology 0 1945 -50 Relays Principle Product Adj Price/ Perfomance Research Model NA
![Computer Generations Overview Principle Product Adj Price Perfomance 0 1945 50 Relays Research Model Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-9.jpg)
Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model NA 1 1950 -59 Vacuum Tubes Commercial Monsters 1 Generation Technology Mag Core (UNIVAC )
![Computer Generations Overview Principle Product Adj Price Perfomance 0 1945 50 Relays Research Model Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-10.jpg)
Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model NA 1 1950 -59 Vacuum Tubes Commercial Monsters 1 Most Large Corp/Univ 318 Generation Technology Mag Core 2 1960 -68 Transistors Mag Core (UNIVAC )
![Computer Generations Overview Principle Product Adj Price Perfomance 0 1945 50 Relays Research Model Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-11.jpg)
Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model NA 1 1950 -59 Vacuum Tubes Commercial Monsters 1 Generation Technology Mag Core 2 1960 -68 Transistors (UNIVAC ) Most Large 318 Mag Core Corp/Univ 3 1969 -77 Integrated Circuits Minicomputer 13 K DRAM
![Computer Generations Overview Principle Product Adj Price Perfomance 0 1945 50 Relays Research Model Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-12.jpg)
Computer Generations Overview Principle Product Adj Price/ Perfomance 0 1945 -50 Relays Research Model NA 1 1950 -59 Vacuum Tubes Commercial Monsters 1 Generation Technology Mag Core 2 1960 -68 Transistors (UNIVAC ) Most Large 318 Mag Core Corp/Univ 3 1969 -77 Integrated Circuits Minicomputer 13 K DRAM VLSI Personal 4 1978239 M DRAM Computer
![Technological Growth DRAM Growth 4 X Capacity Every 3 Years Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-13.jpg)
Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years
![Technological Growth DRAM Growth 4 X Capacity Every 3 Years Workstation Performance Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-14.jpg)
Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance Improvement: 54% per year or 2 X every 18 months
![Technological Growth DRAM Growth 4 X Capacity Every 3 Years Workstation Performance Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-15.jpg)
Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance Improvement: 54% per year or 2 X every 18 months • Disk Drive Growth: Capacity More than 2 x every year
![Technological Growth DRAM Growth 4 X Capacity Every 3 Years Workstation Performance Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-16.jpg)
Technological Growth • DRAM Growth: 4 X Capacity Every 3 Years • Workstation Performance Improvement: 54% per year or 2 X every 18 months • Disk Drive Growth: Capacity More than 2 x every year • All Continue to Drive Price /Performance Improvements
![](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-17.jpg)
![Five Components of Computers Control Datapath Processor Memory Input Output Five Components of Computers Control Datapath Processor Memory Input Output](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-18.jpg)
Five Components of Computers Control Datapath Processor Memory Input Output
![Instruction Set Design Key Element in the Architecture Function Cost Performance etc Instruction Set Design • Key Element in the Architecture – Function, Cost, Performance, etc.](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-19.jpg)
Instruction Set Design • Key Element in the Architecture – Function, Cost, Performance, etc.
![Instruction Set Design Key Element in the Architecture Function Cost Performance etc Instruction Set Design • Key Element in the Architecture – Function, Cost, Performance, etc.](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-20.jpg)
Instruction Set Design • Key Element in the Architecture – Function, Cost, Performance, etc. • Typical Machine Instructions – – – Data Transfers ( reg-reg, reg-mem, mem-reg) Arithmetic (add, subtract, multiply) Logic & String (boolean, bit manipulations) Program Control ( branches, jumps) Input/Output Operations
![Instruction Set Design Study the MIPS Architecture Instruction Set Design Study the MIPS Architecture](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-21.jpg)
Instruction Set Design Study the MIPS Architecture
![Instruction Set Design Study the MIPS Architecture A WORD is 32 bits or Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-22.jpg)
Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or 4 bytes wide for Registers and Memory
![Instruction Set Design Study the MIPS Architecture A WORD is 32 bits or Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-23.jpg)
Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or 4 bytes wide for Registers and Memory • Each byte has Memory Address starting at 0
![Instruction Set Design Study the MIPS Architecture A WORD is 32 bits or Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-24.jpg)
Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or 4 bytes wide for Registers and Memory • Each byte has Memory Address starting at 0 • WORD Addresses start at 0 and are multiples of 4
![Instruction Set Design Study the MIPS Architecture A WORD is 32 bits or Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-25.jpg)
Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or 4 bytes wide for Registers and Memory • Each byte has Memory Address starting at 0 • WORD Addresses start at 0 and are multiples of 4 • Big-endian Byte 0, Byte 1, Byte 2, Byte 3 • Little-endian Byte 3, Byte 2, Byte 1, Byte 0
![Instruction Set Design Study the MIPS Architecture A WORD is 32 bits or Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-26.jpg)
Instruction Set Design Study the MIPS Architecture • A WORD is 32 bits or 4 bytes wide for Registers and Memory • Each byte has Memory Address starting at 0 • WORD Addresses start at 0 and are multiples of 4 • Big-endian Byte 0, Byte 1, Byte 2, Byte 3 • Little-endian Byte 3, Byte 2, Byte 1, Byte 0 • 32 Registers with Conventions on Use
![Memory N b M Registers 31 8 b 11 b 10 b 9 Memory N b. M Registers 31 • 8 b 11 b 10 b 9](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-27.jpg)
Memory N b. M Registers 31 • 8 b 11 b 10 b 9 b 8 4 b 7 b 6 b 5 b 4 1 0 b 3 b 2 b 1 b 0 0 32 bits • 32 bits
![MIPS Assembly Instructions Instruction Example add subtract Meaning add s 1 s 2 s MIPS Assembly Instructions Instruction Example add subtract Meaning add $s 1, $s 2, $s](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-28.jpg)
MIPS Assembly Instructions Instruction Example add subtract Meaning add $s 1, $s 2, $s 3 $s 1 = $s 2 + $s 3 sub $s 1, $s 2, $s 3 $s 1 = $s 2 - $s 3 $s 1, $s 2, $s 3, … are registers. The $ indicates a Register in the MIPS Assembly Language
![MIPS Assembly Instructions Instruction Example add subtract Meaning add s 1 s 2 s MIPS Assembly Instructions Instruction Example add subtract Meaning add $s 1, $s 2, $s](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-29.jpg)
MIPS Assembly Instructions Instruction Example add subtract Meaning add $s 1, $s 2, $s 3 $s 1 = $s 2 + $s 3 sub $s 1, $s 2, $s 3 $s 1 = $s 2 - $s 3 $s 1, $s 2, $s 3, … are registers. The $ indicates a Register in the MIPS Assembly Language Also $s 2 + $s 3 $s 1
![Machine Instruction Format R Type Instruction Instr Format op rs rt rd shamt funct Machine Instruction Format R Type Instruction Instr Format op rs rt rd shamt funct](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-30.jpg)
Machine Instruction Format R Type Instruction Instr Format op rs rt rd shamt funct add R 0 reg reg 0 32 sub R 0 reg reg 0 34 bits 6 5 5 5 6 op : opcode rd : register destination operand rs : reg source 1 operand shamt : shift amount rt : reg source 2 operand funct : function code – variant of operation
![Machine Instruction Format add t 0 s 2 t 0 where t 0 is Machine Instruction Format add $t 0, $s 2, $t 0 where $t 0 is](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-31.jpg)
Machine Instruction Format add $t 0, $s 2, $t 0 where $t 0 is reg 8, $s 2 is reg 18 $t 0 = $s 2 + $t 0 Instr Format op rs rt rd shamt funct add R 0 18 8 8 0 32 bits 6 5 5 5 6
![Machine Instruction Format add t 0 s 2 t 0 where t 0 is Machine Instruction Format add $t 0, $s 2, $t 0 where $t 0 is](https://slidetodoc.com/presentation_image/933a214fc3810b03f15d91daa425b60c/image-32.jpg)
Machine Instruction Format add $t 0, $s 2, $t 0 where $t 0 is reg 8, $s 2 is reg 18 $t 0 = $s 2 + $t 0 Instr Format op rs rt rd shamt funct add R 0 18 8 8 0 32 bits 6 5 5 5 6 Example of Machine Language Instruction op rs rt rd shamt funct 0 18 8 0 32 000000 10010 01000 00000 100000
