Company Overview Founded in 1983 Diversified into the

Company Overview • Founded in 1983 • Diversified into the aerospace, automotive, semi-conductors & oil industries • AS 9100 Approved • Approximately 40 people • Sales have averaged $12 million over the last 4 years Focusing on the Future, While Building on the Past.

Capabilities • Precision machined products for the aerospace industry • Assembly, kitting and component integration. • Aluminum, stainless steel and carbon steel welding.

Facilities • Manes Machine and Engineering is centrally located in Fort Collins, CO. • The facility is 60, 000 sq. ft. – 45, 000 sq. ft. of production space – 15, 000 sq. ft. of office space – 20, 000 sq. ft. future expansion

Approvals Huntsville, Mesa, Oakridge St. Louis, Tulsa, Wichita Ø Boeing Bronze Supplier Certification Ø Recipient of Lockheed's Small Business Supplier of the Year

Key Personnel • • Owner / President – Bruce Page Chief Financial Officer – Mike Prenzlow Plant Manager – Robert Marcus Business Unit Managers – Garry Brocklehurst Doug Green Bob Laverentz • Contracts Administration – Mary Currans • Quality Assurance Supervisor – Dana Cherry • Production Planning & Control – Dan Luebbers

Programming CATIA NCL SYSTEM VERICUT SILICON GRAPHICS UNIGRAPHICS

Quality • AS 9100 Approval • Boeing Preferred Supplier Certification • Approved to D 6 -82479 and to manufacture to the D 6 -1276 Planning Requirement Document.

Five-Axis Equipment Toshiba MPF High-speed / 12, 000 rpm 40 hp 177” x 83” Cincinnati 20 V Machining Center 20 hp 120” x 30” Cincinnati 20 V Machining Center 20 hp 80” x 30”

Four-Axis Equipment MCV 1000 VG / 12, 000 rpm 40 hp 40” x 20” Matsura MC 900 H 6 pallet changer 25 hp 36” x 28” (7) Matsura MC 900 H 2 pallet changer 25 hp 36” x 28” Three-Axis Cincinnati Gantry 50 hp 240” x 94” (2) Kuraki 2000 CNC 25 hp 80” x 32”

Equipment INSPECTION EQUIPMENT DEA SCIRROCO AUTOMATED CMM PC DMIS 40” X 72” X 30” MITITOYO B 251 MANUAL CMM GEO PACK 2000 28” X 60” X 24”

Assembly / Integration Manes Machine has expanded heavily into assemblies, kitting, and component integration to complement their machine capabilities.

Welding • Aluminum, stainless steel and carbon steel capability • Lincoln Precision TIG 275 • Miller 300 MIG

Automated Weld Cell • ABB IRB 1400 6 -axis robot –. 003 inch repeatability – Touch sensing • 250 kg rotary station – Adds 7 th axis to robot • Fixed table station – Flexible for small to large parts • Fronius TPS 4000 Power Source – 400 amp mig welding – Pulsed and Pulse on Pulse Welding

Contact Us 2421 International Blvd Fort Collins, CO 80524 www. manesmachine. com Phone: (970) 224 -3311 Fax: (970) 224 -1334 Email: brhodes@rsi. aero
