Company introduction Xingtai Hongbang Composites Manufacturing Co Ltd

Company introduction Xingtai Hongbang Composites Manufacturing Co. , Ltd. was founded in 1979. After years of development, it has formed a professional manufacturer of FRP products integrating development, design, production, sales and engineering installation. With strong technical force, modern pultrusion technology and a large number of excellent design talents, the company has accumulated rich experience in the field of FRP and provides complete FRP application solutions for customers. Relying on strict scientific management, strong technical force and superior product quality, we have developed and researched quality products from generation to generation and won the trust of customers.

Catalogue Main Product • Pultrusion Profile • Molding profile Roofing Product • FRP sheet/cover Project Display • Rain cover • Greenhouse

Pultrusion Profile FRP fiberglass rod is a kind of FRP composite material which is made of continuous fiberglass roving and resin in the pultrusion molding machine. The surface of the rich resin layer make it has a good corrosion resistance. Product Name Brand Material Color MOQ Size Pultrusion Pipe Process Surface FRP Square/Rectangle Tube/Pipe Hong. Bang Composite/Fiberglass/FRP/GFRP/CFRP/Fiber Reinforced Polymer/Plastic Any color, Welcome Customized If there is inventory, MOQ is 1 m. If not, depends on the specification you need Customized Pultrusion Technology Smooth or Customized Fence, Handrail, Ladders, Chemical Anti-corrosion, Sewage Treatment, Electrical Usage Insulation, Energy Extraction, Transportation, Construction etc. General Specification Size(mm) Weight(kg/m) 25 x 3 0. 5 30 x 2 0. 51 30 x 4 0. 77 38 x 3. 8 1 42 x 4 1. 15 50 x 6 2 85 x 35 x 4 1. 67 100 x 50 x 4 2. 063 120 x 3 2. 62 Welcome Customize any Size you need.

Features: 1, light weight, high strength, good elasticity, under certain conditions can be bent into a circular shape without cracking or fracture. 2. Stable size and anti-aging Pultrusion pole 3, beautiful and easy maintenance, diverse colors, glass fiber rod can be made into a variety of colors according to customer needs, good surface quality, good appearance. Maintenance is rarely required. 4. Insulation and flame retardant. FRP rod has excellent electrical insulation performance, fiberglass reinforced plastic is not affected by electromagnetic, can be used in the conductive danger, magnetic sensitive equipment area, as well as flammable and explosive places. 5, no thermal conductivity, frp rod has good thermal performance, thermal conductivity is relatively low, is 1/100 to 1/1000 of the metal. 6. Long-term temperature resistance. As a high-temperature resistant material, thermal expansion coefficient of glassfiber composite is much lower than that of general plastics. 7. Excellent mechanical processing performance, capable of cutting, drilling, turning, grinding and tapping.

Pultrusion Profile Pultrusion pole Product Name FRP Rod/ bar/ pole Material Fiberass Reinforced Plastic Brand Hong. Bang Color as picture show or customized MOQ 500 meters Size Customized Process Pultrusion Technology Surface Smooth Usage Chemical anti-corrosion, sewage treatment, electrical insulation, energy extraction, transportation Default specification Size(mm) Weight(kg/m 2) Φ 6. 9 0. 077 Φ 9 0. 13 Φ 10 0. 16 Φ 12 0. 23 Φ 14 0. 305 Φ 16 0. 411 Φ 18 0. 48 Φ 20 0. 67 Φ 30 1. 5

Pultrusion Profile FRP Fiberglass Coil Advantages: * * * * Excellent Corrosion Resistance 65% Lighter than Steel Impact Resistant, high strength Non-Conductive Long maintenance-free life Light and Easy to Fabricate Transparent to Radio Waves and EMI/RF Transmissions FRP curved ring pultrusion profiles are formed by using FRP ring pultrusion technology. This technology is a new FRP extrusion process developed by our company on the basis of FRP bending extrusion technology. This technology can be used to produce curved and three - dimensional profiles. With diameters ranging from 300 mm to 5000 mm, our company applies this technology to produce hollow parts with multiple Chambers. Applications: automotive, aerospace, furniture, architecture, civil engineering and other applications.

Pultrusion Profile Pultrusion beam Our high-quality Universal Beams, also known as I-beams, I sections, H sections, universal beams are essential for major support and structural integrity in building construction. Available in a range of sizes and kilogrammes per metre. Product Name Brand Material Feather Size Color Technique Application Surface Treatment OEM Product number I beam High Strength fiberglass / FRP I-beam / H-beam Hong. Bang Composite / Fiberglass / FRP / GFRP / Fiber Reinforced Polymer/Plastic Aging-Resistant, Insulation, Corrosion Resistance, High Mechanical Strength Customized size / as your requirement Customized color Pultrusion process Building structure, bridges, vehicles, brackets, machinery, etc. Smooth or customized Accesptable HB 02 -001 Regular size(mm) weight(kg/㎡) 25 x 15 x 4 0. 35 38 x 15 x 4. 5 0. 505 40 x 30 0. 641 30 x 15 x 4. 5 38 x 15 50 x 15 x 4. 6 50 x 25 58 x 4. 8 58 x 15 x 4. 3 58 x 15 x 4. 6 58 x 15 x 5. 26 65 x 30 0. 39 0. 573 0. 61 0. 86 0. 71 0. 62 0. 76 0. 9 70 x 15 0. 89 100 x 15 x 6 1. 162 100 x 10. 5 3. 65 70 x 15 x 5. 2 100 x 30 150 x 125 x 10 150 x 10 200 x 10 300 x 150 x 13. 5 0. 94 1. 233 7. 53 6. 13 7. 53 14. 74

Pultrusion Profile Pultrusion U/V/C Channle Material Fibreglass Reinforced Plastic Color as picture show or customized MOQ 500 meters Size Customized Surface Smooth Usage Construction Section/Photo Type Dimension(mm) A*B*T 1*T 2 Weight(Kg/m) C 50. 5*36*7*6 1. 4 C 76 76*38*6. 4 1. 71 C 102 A 102*35*4. 8 1. 48 C 102 B 102*35*6*6 1. 83 C 102 E 102*44*4. 8 1. 65 C 150*41*8. 0 3. 28 C 152 A 152*42*6. 4 2. 74 C 200*60*10*10 5. 7 C 254*70*12. 7 8. 9

Pultrusion Profile Pultrusion U/V/C Channle Product Name FRP V/L profile Material Fibreglass Reinforced Plastic Color as picture show or customized MOQ 500 meters Size Customized Process Pultrusion Technology Surface Smooth Usage Chemical anti-corrosion, sewage treatment, electrical insulation, energy extraction, transportation Type NO. Dimension(mm) B*H*T 1*T 2 Weight(kg/m) L-20*20*2*2 0. 145 L-25. 4*19*3. 0 0. 237 L-50*50*8. 0 1. 406 L-50. 8*6. 3*6. 3 1. 467 L-63. 7*38. 2*4. 7 0. 872 L-76*76*9. 5 1. 786 L-101*12. 7*12. 7 4. 607 L-152*9. 5*9. 5 5. 348

FRP Insulating Multi-section telescopic Extension Ladder Light FRP Insulating Multi-section telescopic Extension Ladder FRP telescopic Ladder Model HB-PC-2. 5 HB-PC-3 Extension Length(m) 2 2. 5 3 3. 5 4 5 Weight(kg) 6. 2 7. 15 9. 45 10. 65 15. 05 17. 25 Retraction Length(m) 0. 75 0. 8 0. 95 1 1. 8 Load Weight(kg) 100 100 100 Voltage Level(k. V) 0 -220 0 -220 HB-PC-3. 5 HB-PC-4 HB-PC-5

Molding Profile FRP Fiberglass Grating Advantages: Two kinds of production process—— Molded and Pultrusion Molding Grating Three kinds of Standard Resin Systems PFR Polyester Resin IFR Isophthalic Polyester Resin VFR Vinyl Ester Resin Six kinds of Surface Treatment, Any color, Any size, Any shape.

Molding Profile Molding Grating Mesh Size Standard Panel (mm) Size (mm) Open top/bottom (mm) Area 13 15 15 15 20 20 25 25 25 50. 8× 50. 8 25. 4× 25. 4 / 50. 8× 50. 8 38. 1× 38. 1 20× 20 / 40× 40 38. 1× 38. 1 12. 8× 12. 8 / 38. 5× 38. 5 38. 1× 38. 1 40× 40 19× 19 / 38× 38 3660× 1220 3660× 1225 4047× 1247 3665× 1225 3434× 970 3665× 1225 4047× 1007 4005× 1220 6. 4 / 5. 4 6. 2 / 5 6. 3 / 5. 2 6. 35 / 5. 3 6. 3 / 5 7. 2 / 6. 4 6. 35 / 5 6. 4 / 5 25 25× 100(Bearing bars to run width direction) 3007× 1009 11 25 25. 4× 101. 6(Bearing bars to run width direction) 3660× 1220 12 25 101. 6× 25. 4(Bearing bars to run length direction) 13 14 15 16 17 18 19 30 30 30 38 38 20 No. Height (mm) 1 2 3 4 5 6 7 8 9 10 Rib Thickness Weight Kgs/m 2 76% 57% 69% 47% 69% 27% 69% 70% 44% 5. 5 7. 2 6. 5 11. 5 9. 3 18. 5 12. 3 12. 2 15. 5 67% 13. 8 7/5 67% 13 3665× 1225 7/5 67% 13. 1 38. 1× 38. 1 40× 40 20× 20 / 40× 40 12. 7× 12. 7 / 38× 38 26× 26 / 52× 52 38. 1× 38. 1 40× 40 4008× 1525 4047× 1007 4047× 1247 4040× 1220 4011× 1150 3969× 1525 4047× 1007 68% 69% 42% 30% 56% 67% 14. 6 14. 2 18. 1 23. 5 13. 6 19. 2 18. 8 38 152. 4× 25. 4(Bearing bars to run length direction) 3665× 1226 6. 6 / 5 7/5 6. 5/5 7/5 7 / 5(length) 9 / 7(width) 68% 20. 4 21 38 101. 6× 38. 1(Bearing bars to run length direction) 3660× 1220 7/5 76% 14. 5 22 23 38 38 19× 19 / 38. 1× 38. 1 20× 20 / 40× 40 4045× 1220 4047× 1247 7/5 40% 42% 23. 5 22 9. 4 / 8(length) 6. 4 / 5(width)

Molding Profile Molding Grating 24 40 40× 40 4047× 1247 7/5 67% 20 25 40 220× 60 2207× 1507 7/5 85% 9. 5 26 40 20× 20 / 40× 40 4047× 1207 7/5 42% 23. 7 27 50 50. 7× 50. 7 3660× 1225 8. 3 / 5 69% 21. 5 28 50 50. 7× 50. 7 3660× 1225 8. 8 / 5 68% 23. 5 29 50 25. 35× 25. 35 / 50. 7× 50. 7 3660× 1220 8/6 47% 26 30 50 152. 4× 38. 1(Bearing bars to 3660× 1220 run length direction) 9/7 72% 20. 8 31 50 38. 1× 38. 1 3665× 1225 11. 5 / 9 48% 40. 5 32 63 38. 1× 38. 1 3660× 1220 9 / 5. 8 58% 38. 5 33 63 38. 1× 38. 1 3670× 1230 12/9 46% 52 34 P 25 38. 1× 38. 1 1220 x 3660 6. 35 / 5 69% 11. 5 35 P 30 38. 1× 38. 1 1220 x 3660 6. 6 / 5 68% 13. 5 36 P 38 38. 1× 38. 1 1220 x 3660 7/5 66% 17. 0 37 P 50 50. 7× 50. 7 1225× 3660 8. 3 / 5 69% 21. 5

Other Main Products We are specialized in producing and supplying all kinds of FRP roof panels. These plates are characterized by high tensile strength, fire resistance, corrosion resistance and light weight. Fiberglass roof panel is the best choice of roofing materials, in the need to control the light transmittance, light transmittance up to 90%. The FRP sheet forming process gives it better flexural rigidity and reduces deflection under high wind speeds, extreme weather conditions and other incipient loads. In addition, these roof slabs can be customized according to customer requirements.

Sewage Treatment Tank Cover Project Display This product is based on FRP curved and pultruded profiles independently developed by our company, combined with FRP anti-corrosion lighting tile, 304, 316 stainless steel fittings and other supporting facilities with high corrosion resistance and high oxidation resistance; Project Description Compared with the traditional steel structure cover, it has an irreplaceable advantage; the traditional steel structure cover has a service life of no more than 3 years. In the high concentration of corrosive gas and liquid environment, rust and fracture will occur, and the FRP bending provided by our company Pultrused profile-based scaffolding structure, the main structure will last for more than 10 years, and there will be no breakage in the natural environment without force majeure; Compared with the hand lay-up glass reinforced plastic shed cover, it has an irreplaceable advantage; the traditional hand-paste FRP rain cover and other covers have a long production period. In case of man-made or extreme weather damage, the replacement labor cost is high, and the sealing is not well controlled; The main structure provided can be completed within 15 -20 days from the signing of the order to the on-site construction, and can basically withstand extreme weather such as high winds above 8 and snow pressure loads above 1 m. The replacement of the panels is simple and the labor cost is low; Longer life

Sewage Treatment Tank Cover Project Display Performance Characteristics High pressure resistance (wind pressure, snow pressure), it can withstand hurricanes below 200 KM/H and snow below 1000 mm; detachable, all the joints in the shed are connected by screws, if you need to change the place of use, assembly and disassembly The time period is short (span structure is different, generally 5 -10 days, excluding transportation time); excellent performance in extended years, scaffolding structure can guarantee no deformation for at least 10 years, and maintenance is simple. 1. The main frame adopts a one-time forming process, which has good mechanical properties, and can transmit the bearing capacity of the surface of the greenhouse to the base without forming concentrated stress, thereby improving the overall strength; 2. It has good corrosion resistance and weather resistance. In the complex environment of high temperature, high oxygen content, high temperature and high corrosion gas in greenhouse, its mechanical properties in UV exposure, rain and snow, high temperature and low temperature environment The surface structure will not change significantly, and the service life will exceed 20 years; 3. High strength, can reach or exceed the steel with the same crosssectional area. Good toughness, only 1/4 of the steel, easy to install and construct;

Sewage Treatment Tank Cover Project Display At present, this product is mainly used in environmental protection water treatment fields such as sewage A/O pool, domestic sewage treatment tank and industrial wastewater treatment tank. Ningjin Yufeng First Park sewage A/0 pool cover project, using 200 x 10 mm I-beam and 73 x 6 mm purlin FRP main material, accessories and auxiliary materials are made of 304 stainless steel, with good corrosion resistance

Sewage Treatment Tank Cover Project Display

US Planting Greenhouse Project Description This product is based on FRP bending and pultruding profiles independently developed by our company. It combines steel structure, fully automatic sunshade and light curtain system, container house, solar panel and wind power system, etc. Energy-saving and environmental protection facilities have established a complete wind and solar complementary greenhouse system, which can be widely used in industry, agriculture and Other areas; this is an irreplaceable advantage in areas with harsh climates, high altitudes and large temperature differences. Other applications: including personalized hostels, restaurants, theme communities, etc.

US Planting Greenhouse Project Performance Characteristics High pressure resistance (wind pressure, snow pressure), can withstand hurricanes below 200 KM / H and snow below 1000 mm; detachable, all shacks and container houses are screwed, when the location needs to be replaced, the assembly and disassembly time is shorter ( The span structure is different, generally 5 -10 days, excluding transportation time); with excellent performance for several years, the steel frame structure of the greenhouse can guarantee no deformation for at least 30 years, and the maintenance is simple.

US Planting Greenhouse Project Performance Characteristics 1. The main frame adopts a one-shot process and has good mechanical properties. The load carrying capacity of the greenhouse surface can be transferred to the susceptor without forming concentrated stresses, thereby increasing the overall strength. 2. It has good corrosion resistance and weather resistance. In the environment of high temperature, high oxygen content and high temperature in greenhouse, its mechanical properties and surface structure will not change significantly under ultraviolet exposure, rain, snow and high temperature and low temperature environment. The service life is more than 30 years.

US Planting Greenhouse Project Engineering case 1 At present, the main supply market for this product is high latitude, high altitude, desert, high mountain and other areas in the United States; it provides breeding and planting services. Including high value-added products such as cannabis cultivation, living vegetables, and flower farming; The picture above shows the US high school project, using 350 x 12 mm I-beam and 73 x 6 mm purlin FRP main material, the fitting is 304 stainless steel, the auxiliary material is hot-dip galvanized high-galvanized steel, which has good corrosion resistance

US Planting Greenhouse Project Engineering case 2 The product is beautiful in appearance and practical; it is easy to install and can be widely used in agriculture, industry, environmental protection and other fields

US Planting Greenhouse Project Engineering case 2 The internal structure is simple, the available space is large, and the double-layer structure can be designed to make full use of the internal space. The single supply height can be adjusted according to the design requirements, generally between 6 -10 meters (such as combining container houses, single arch height At about 6 meters, it need designed to combine the height of the container).

US Planting Greenhouse Project Engineering case 4 1. US WEB project, using 160 x 8 mm I-beam and 73 x 6 mm pur strip FRP main material, the fitting is 304 stainless steel, the auxiliary material is hot dip galvanized high galvanized steel sheet, with good anti-corrosion performance. 2. The project uses three containers combination modes. 3. Equipped with containers for diversified purposes, can be used for rest, storage tools or other applied materials

US Planting Greenhouse Project
