Combustion Control by Honeywell Elements required for combustion
Combustion Control 燃烧安全控制 by Honeywell 霍达实业
Elements required for combustion 燃烧的基本要素 FUEL 燃料 AIR 空气 IGNITION 点火源 A AIR RICH 富空气 2 B FLAM-MABLE 可燃极限 HONEYWELL – Combustion Control C FUEL RICH 富燃料 File Number
Flame characteristics and Flame Safeguard 火焰特性和燃烧安全控制 • • PRODUCTION OF HEAT 产生热量 EXPANSION OF GASES 气体膨胀 PRODUCTION OF BY-PRODUCTS 产生燃烧产物 EMISSION OF LIGHT (INFRARED TO ULTRAVIOLET) 发光(红外线, 可见光,紫外线) • IONIZATION IN AND AROUND THE FLAME 火焰内部及火焰周围产生 电离 To recognize the flame 鉴别火焰存在 Flame safeguard solution: 安全燃烧控制要求 Safety ignition…flame monitor…safety shutoff 安全点火…火焰检测 …熄火切断保护 3 HONEYWELL – Combustion Control File Number
Combustion Controls - Profile and Products 燃烧控制器 – 产品系列 Profile Total Revenue WW : $ 600 M Europe USA • More than 7 M gas valve produced in 2005 for resid. heating world wide • 2005年超过700万件燃气阀应用于民用采暖用途 • More than 6 M electronic board produced in 2005 • 2005年超过600万套电子控制板 • R&D ww team 142 poeple 全球142位研发队伍人员 • 8 manufacturing facilities in six different countries • 在 8个国家拥有8个生产基地 Residential Commercial Industrial 民用领域 商用领域 业领域 Boiler Electronics 燃气锅炉控制板 Burner controllers 燃烧程序控制器 Gas Valve 燃气控制阀 Gas valve 燃气控制阀 Water Valve 水路控制阀 Sensors 感应器 Remote MMI 房间遥控温控器 Damper motors 节流马达 Sensors & Accessories 感应器及辅件 Burner controllers 燃烧程序控制器 Gas valve 燃气控制阀 Sensors 感应器 Damper motors 节流马达 Accessories, others 辅件和其他 80% OF BUSINESS GLOBALLY DONE WITH APPLIANCE MANUFACTURERS (OEMs) 4 HONEYWELL – Combustion Control File Number
Combustion control products (BBC) 燃烧安全控制产品( 业商业用): Gas valves 阀门 Controllers and sensors 控制器和传感器 Others 其他附件 7800 controllers 7800 系列控制器 Actuators 电动执行器 Single gas valve 单阀 Flame sensors 火焰探测器 Gas train 阀门组 5 Satronic controller 燃烧安全控制器 HONEYWELL – Combustion Control Pressure switch 压力开关 Igniter 点火器 Regulator VPS 稳压器 泄漏检测器 File Number
Commercial combustion control solution 商用燃烧器控制方案 燃烧器应用 Burner Control 燃烧安全控制器 阀门泄漏检测器 Safety Electronic controller VPS 压力开关 Pressure Switch 火焰探测器 Flame Sensors 点火变压器 Igniter 6 风门执行器 Actuator HONEYWELL – Combustion Control 燃气切断阀组 Gas Train File Number
Applications using Honeywell products 典型应用范例- Honeywell控制产品 1. New Premix burners 7 全新预混功能燃烧器 HONEYWELL – Combustion Control File Number
2. Hot-air 8 Furnace 烘烤热风炉 HONEYWELL – Combustion Control File Number
Industrial gas combustion heating furnace 业燃气加热炉 10 HONEYWELL – Combustion Control File Number
Residential combustion solution 家用燃烧安全保控制解决方案 Combi-boiler logical controller 锅炉运行逻辑控制板 Gas Valves 组合燃气阀 Combi-boiler solution 壁挂炉控制系统解决方案 + 3 -way valve 三通水阀 DPS 压力开关 Temp. sensor 温度传感器 Ignition Controller 燃烧安全控制器 水路控制系统 12 Programmable thermostat 可编程房间温控器 HONEYWELL – Combustion Control File Number
Benefits of using Combustion Controls 采用优质燃烧控制器的优点 • Safe start up and shut down of gas burning • 安全地对燃气燃烧过程的启动和关闭 • Can accurately control temperature of the process • 能精确地控制燃烧过程温度 • Gas & Oil are Cleaner and more efficient fuels than coal • 燃气和燃油是比燃煤更为清洁和高效的燃料 • New Premix technologies in gas control reduces pollution • 全新的燃气预混合控制技术极大地减少废气污染 • This mixes the gas & air before igniting 在点火前将燃气和空气预混合 • Premix is a high efficiency way of burning gas 预混技术使燃气高效充分燃烧 • Produces less CO 2 更少的二氧化碳排放 • Has lower running costs 更低的运行成本 • Premix reduces the size of the Combustion chamber and the size of the appliance • 预混技术减小了燃烧室的体积,因此也精减了整体设备和产品的体积 Gas is a safe, clean & low pollution fuel to us 燃气是我们安全、清洁和低污染的燃料 13 HONEYWELL – Combustion Control File Number
Any questions ? Contact 联系方式 Shirley Yin – Sales Manager 王婷 销售经理/Shanghai Office : 021 -50339761 Mobile : 0 -13636335385 MSN : chengyage 1314@hotmail. com E-mail : sales@huoder. com
