CMM Proposal for AUP Hexagon 454 SF CMM
- Slides: 10
CMM Proposal for AUP Hexagon 454 SF CMM Fred Nobrega 12 September 2018
Hexagon 454 SF CMM • CMM cost ~$46 k. • Additional costs include: o Software o Tooling CMM http: //www. hartwiginc. com/machine/hexagon-454 -sf 2 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
CMM Coil Holder 3 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
40 mm Star Probe • Full scan of coil perimeter without pause. • 40 mm Star probe included in quote. 4 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
Star Probe Demonstration at Vendor Site, 360° Coverage 5 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
454 SF CMM Cost Breakdown • Standard Package $45, 947 k – 4. 5. 4 SF Shop Floor CMM – UMP 360 Control System – Temperature Compensation – HH-T Manual Probe Head / Accessory Kit 3 -M 3 – Calibration Sphere – Computer System and Touch Screen LCD Monitor – PC-DMIS PRO Measurement Software (Level I basic GD&T measurements included in standard 454 SF CMM package) • Level II PC-DMIS CAD, import stp files, fit data to CAD files, + $8 k • Level III PC-DMIS CAD++, adds productivity tools and scanning option, +$5 k Installation and On-site Performance Verification PC-DMIS PRO Software Training (1 person for 5 days at Hexagon Metrology, Inc. ) On-line User's and Software Manuals One (1) Year System Warranty with Telephone Applications Support • • • – – Probe included Maintenance – Hexagon recommends annual calibration, +$2 k Tooling, – CMM coil holder, +$9 k Accuracy of FNAL’s CMM used for LARP/AUP coils – MPEE = 3. 1 μm, measurement error, per ISO 10360 -3: 2001 MPEE = 2. 5 μm – R = 2. 0 μm, repeatability, per ASM B 89. 4. 1 b-2001 R = 1. 9 μm – Av[L] = 6. 4 μm, volumetric accuracy, per ASM B 89. 4. 1 b-2001 Av[L] = 5 μm Gantry CMM, $600 k-$800 k Total: 46+8+9= $63 k (BNL/LBNL), $55 k (FNAL), Delivery: 4 weeks after receipt of order. 6 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
Backup Slides 8 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
454 SF Shop Floor CMM 9 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018
FARO Edge Scan. Arm® Estimate: Acquisition of Portable CMM Equipment for LARP MQX Coil Fabrication 6/3/13 Prepared By: H. Hocker 1. 2. Portable Measurement Arm • FARO “Edge” 6‐Ft Range, 7‐Axis (See attached for specifications/accuracy): $33, 928 • FARO Laser Line Probe for “Edge”: • Vacuum Mount: $12, 000 $1814 Data Acquisition • Seat of “Spatial Analyzer” (SA Ultimate) from New River Kinematics: • Yearly Maintenance (1 st Year Included with Purchase Price): 3. $12, 450 $1, 800 Tooling for Coil & Measurement Arm Support • Design: • Labor: • Materials: 4. $4000 $3000 $4000 System Integration $76, 992 Totals (Non‐Recurring): Totals (Recurring): Measurement & analysis costs are not included Assumes use of existing SMD computing hardware (laptop, etc. ) Repeatability and Accuracy 10 Fred Nobrega | Hexagon 454 SF CMM 9/12/2018 $1, 800
