CloudV Infrastructure Services Iaa S Virtual Networking Web
Архитектура Cloud-V – перспектива покупателя Infrastructure Services (Iaa. S) Virtual Networking Web Platform application Services (Paa. S) SQL Server and My. SQL database Reliable messaging
Общая архитектура Cloud-V Покупатели IT Admin Windows Azure Pack
Компоненты облака Служебные VM Клиентские VM Шлюзы Порталы, API, Auth System Center, DBs Management Compute NVGRE Monitoring Security Network SOFS
Scale-Out File Server (SOFS) • Storage Spaces, SMB 3, RDMA • Отказоустойчивое, совместимое, быстрое • DELL Power. Vault MD 3060 e (60 дисков на корзину) – 2 шт – SSD – SAS, 24 х1, 6 Тбайт, 12 Гбит/с – HDD – NL SAS, 96 x 4 Тбайт • DELL Power. Edge R 730 – 2 шт – 2 х. Intel Xeon E 5 -2670 v 3, 64 Гб RAM – 2 х. SAS HBA – 2 x 2 40 G Mellanox Connect. X-3 Pro
Compute • DELL Power. Edge R 820 – 14 шт – 4 х. Intel Xeon E 5 -4640 v 2, 512 Гб RAM – 2 x 40 G Mellanox Connect. X-3 Pro Management, NVGRE шлюзы • DELL Power. Edge R 730 – 4 шт – 4 х. Intel Xeon E 5 -4640 v 2, 384 Гб RAM – 2 x 2 10 G Mellanox Connect. X-3 Pro • IPMI, лицензии, совместимость, контроллеры
Monitoring • Nagios, Thruk • SCOM • Setpoints -> Remedy alerts
Ближайшее будущее • DBaa. S • Web. Sites • Все возможности, доступные в Azure. Pack • Business productivity – Cloud-O – Lync, Exchange, Sharepoint • SAAS – Only. Office – Own. Cloud –…
Data. Line NORD 4
