CIRCULATORY SYSTEM Dr Iram Tassaduq OVERVIEW Transport of
- Slides: 32
CIRCULATORY SYSTEM Dr Iram Tassaduq
OVERVIEW Transport of nutrients, hormones, gases, & other vital materials requires highly controlled flow. • • Body has 2 circulatory systems. Blood vascular system Lymph vascular system
BLOOD VASCULAR SYSTEM The heart, which is a pump for propelling the fluid. The arteries which are tubes for conveying the blood toward the organs & tissues. The capillaries, which are anastomosing channels of small caliber with thin walls providing for much of the interchange of substances between the blood & tissue fluids. The veins, which in their initial segment also provide for blood-tissue fluid interchange but in addition serve for the return of blood to the heart.
LYMPH VASCULAR SYSTEM Consists of lymphatic capillaries & various sized lymphatic vessels which ultimately drain into main trunks, the thoracic duct & the right lymphatic duct, which empty into large veins in the neck.
VESSEL WALLS TUNICA INTIMA TUNICA MEDIA TUNICA ADVENTITIA
ELASTIC ARTERY (AORTA) § § § Also called conducting arteries. Diameter: >1 cm Intima: Endothelium Connective tissue Smooth muscles Stained with orsein 1 - Tunica intima 2 - Tunica media 3 - Tunica externa
TUNICA MEDIA § Smooth muscles § Elastic lamellae
TUNICA ADVENTITIA §Thinner than tunica media §Connective tissue §Elastic fibers
MUSCULAR ARTERY 2 -10 mm in diameter § § Intima: Endothelium Connective tissue Smooth muscle Internal elastic membrane
MUSCULAR ARTERY § Media: 25 -40 layers of Smooth muscle fibers § Collagen fibers § Elastic tissue
MUSCULAR ARTERY § Adventitia: Thinner than media § Connective tissue § Some elastic fibers
MUSCULAR ARTERY
SMALL ARTERY 0. 1 -2 mm in diameter Internal elastic membrane present 8 -10 layers of smooth muscles. Very thin tunica adventitia
SMALL ARTERY LOW POWER VIEW OF SMALL ARTERY HIGH POWER VIEW OF SMALL ARTERY & ARTERIOLE
ARTERIOLE Arterioles can be differentiated from arteries by the numbers of layers of smooth muscle. No more than 6 layers. A “precapillary arteriole” (1 -2 layers)
VEINS Veins are distinguished by their thinner wall, valves, collapsed state. The tunica media does not look as well organized as that in the artery or arteriole.
VENULE § § MUSCULAR VENULE: 50 -100 µm in diameter 1 -2 layers of smooth muscles in media V A N
SMALL SIZE VEIN 0. 1 -1 mm in diameter 2 -3 layers of smooth muscles in tunica media Thicker adventitia
MEDIUM VEIN 1 -10 mm in diameter Media is considerably thinner Adventitia is well developed & forms bulk of the wall.
LARGE VEIN
LARGE VEIN >1 mm in diameter 2 -15 layers of smooth muscles Much thicker adventitia containing connective tissue & some elastic fibers.
CAPILLARIES Thin walled tubules with an average diameter of about 410 µm. Branch extensively without much change in caliber, & the branches anastomose to form networks which vary in density & pattern in different tissues & organs. The tissues with the highest metabolic activity have networks of elaborately branched & closely packed capillaries.
TYPES OF CAPILLARIES
MICROSCOPIC VIEW
MEDIUM SIZE ARTERY AND VEIN
ARTERIOLE & VENULES SMALL ARTERY & VEIN
