Circle Theorems Tangents Chords Higher GCSE Questions These
- Slides: 7
Circle Theorems – Tangents & Chords – Higher – GCSE Questions These questions are the same format as previous GCSE exams. COPY means they use the exact same numbers as the original GCSE question. Otherwise, they are clone questions using different numbers. The worksheets are provided in a variety of sizes.
Printing To print handouts from slides Select the slide from the left. Then click: File > Print > ‘Print Current Slide’ To print multiple slides Click on a section title to highlight all those slides, or press ‘Ctrl’ at the same time as selecting slides to highlight more than one. Then click: File > Print > ‘Print Selection’ To print double-sided handouts Highlight both slides before using ‘Print Selection’. Choose ‘Print on Both Sides’ and ‘Flip on Short Edge’.
GCSE Edexcel Higher : May 2018 Paper 1, Q 11 B 1 C C O A B and C are points on a circle, centre O. BA is a tangent to the circle. AOC is a straight line. Angle OBC = x°. Find the size of angle BAC, in terms of x. Give your answer in its simplest form. Give reasons for each stage of your working. (Total for Question 1 is 5 marks)
GCSE Edexcel Higher : May 2018 Paper 1, Q 11 B 1 C O A B and C are points on a circle, centre O. BA is a tangent to the circle. AOC is a straight line. Angle OBC = x°. Find the size of angle BAC, in terms of x. Give your answer in its simplest form. Give reasons for each stage of your working. (Total for Question 1 is 5 marks)
GCSE Edexcel Higher : May 2018 Paper 1, Q 11 B 1 90° C O A B and C are points on a circle, centre O. BA is a tangent to the circle. AOC is a straight line. Angle OBC = x°. Find the size of angle BAC, in terms of x. Give your answer in its simplest form. Give reasons for each stage of your working. Rearrange (Total for Question 1 is 5 marks)
Questions? Comments? Suggestions? …or have you found a mistake!? Any feedback would be appreciated . Please feel free to email: tom@goteachmaths. co. uk
