Chapter 2 Motion Along a Straight Line Power. Point® Lectures for University Physics, Thirteenth Edition – Hugh D. Young and Roger A. Freedman Lectures by Wayne Anderson Copyright © 2012 Pearson Education Inc. Modifications by Mike Brotherton

Goals for Chapter 2 • To describe straight-line motion in terms of velocity and acceleration • To distinguish between average and instantaneous velocity and average and instantaneous acceleration • To interpret graphs of position versus time, velocity versus time, and acceleration versus time for straight-line motion • To understand straight-line motion with constant acceleration • To examine freely falling bodies • To analyze straight-line motion when the acceleration is not constant Copyright © 2012 Pearson Education Inc.

Introduction • Kinematics is the study of motion. • Velocity and acceleration are important physical quantities. • A bungee jumper speeds up during the first part of his fall and then slows to a halt. Spidey, too! Copyright © 2012 Pearson Education Inc.

Displacement, time, and average velocity—Figure 2. 1 • A heromoving along the x-axis has a coordinate x. • The change in the hero’s coordinate is x = x 2 x 1. • The average x-velocity of the hero is vav-x = x/ t. • Figure 2. 1 illustrates how these quantities are related. Copyright © 2012 Pearson Education Inc.

Negative velocity • The average x-velocity is negative during a time interval if the hero moves in the negative x-direction for that time interval. Figure 2. 2 illustrates this situation. Copyright © 2012 Pearson Education Inc.

A position-time graph—Figure 2. 3 • A position-time graph (an x-t graph) shows the particle’s position x as a function of time t. • Figure 2. 3 shows how the average x-velocity is related to the slope of an x-t graph. Copyright © 2012 Pearson Education Inc.

Instantaneous velocity—Figure 2. 4 • The instantaneous velocity is the velocity at a specific instant of time or specific point along the path and is given by vx = dx/dt. • The average speed is not the magnitude of the average velocity! Copyright © 2012 Pearson Education Inc.

Motion diagrams • A motion diagram shows the position of a particle at various instants, and arrows represent its velocity at each instant. • Figure 2. 8 shows the x-t graph and the motion diagram for a moving particle. Copyright © 2012 Pearson Education Inc.

Average vs. instantaneous acceleration • Acceleration describes the rate of change of velocity with time. • The average x-acceleration is aav-x = vx/ t. • The instantaneous acceleration is ax = dvx/dt. Copyright © 2012 Pearson Education Inc.

Motion with constant acceleration—Figures 2. 15 and 2. 17 • For a particle with constant acceleration, the velocity changes at the same rate throughout the motion. Copyright © 2012 Pearson Education Inc.

The equations of motion with constant acceleration • The four equations shown to the right apply to any straightline motion with constant acceleration ax. • We can work this out with a little integral calculus, but it’s also possible to do with just algebra for this specific case. Copyright © 2012 Pearson Education Inc.

Freely falling bodies • Free fall is the motion of an object under the influence of only gravity. • In the figure, a strobe light flashes with equal time intervals between flashes. • The velocity change is the same in each time interval, so the acceleration is constant. Copyright © 2012 Pearson Education Inc.

A freely falling coin • Aristotle thought that heavy bodies fall faster than light ones, but Galileo showed that all bodies fall at the same rate. • If there is no air resistance, the downward acceleration of any freely falling object is g = 9. 8 m/s 2 = 32 ft/s 2. • Follow Example 2. 6 for a coin dropped from the Leaning Tower of Pisa. Copyright © 2012 Pearson Education Inc.

Up-and-down motion in free fall • An object is in free fall even when it is moving upward. • Instead of a ball, let’s pretend it’s something more interesting like a blood-filled pumpkin or a human heart. Copyright © 2012 Pearson Education Inc.

Is the acceleration zero at the highest point? —Figure 2. 25 • The vertical velocity, but not the acceleration, is zero at the highest point. Think about our hammer vs. feather moon video. How could you use the information there to calculate the acceleration due to the moon’s surface gravity? Copyright © 2012 Pearson Education Inc.
