Chapter 12 MultiWay search Trees 1 2 3
- Slides: 82
Chapter 12 Multi-Way search Trees 1. 2 -3 Trees: a. Nodes may contain 1 or 2 items. b. A node with k items has k + 1 children c. All leaves are on same level. 1
Example • A 2 -3 tree storing 18 items. 20 80 30 70 5 2 4 10 25 40 50 75 90 100 85 95 110 120 2
Updating • Insertion: • Find the appropriate leaf. If there is only one item, just add to leaf. • Insert(23); Insert(15) • If no room, move middle item to parent and split remaining two items among two children. • Insert(3); 3
Insertion • Insert(3); 20 80 5 2 3 4 10 15 30 70 23 25 40 50 75 90 100 85 95 110 120 4
Insert(3); • In mid air… 20 80 5 30 70 90 100 3 2 4 10 15 23 25 40 50 75 85 95 110 120 5
Done…. 20 80 3 5 2 30 70 4 10 15 23 25 40 50 75 90 100 85 95 110 120 6
Tree grows at the root… • Insert(45); 20 80 3 5 2 4 30 70 10 25 40 45 50 75 90 100 85 95 110 120 7
• New root: 45 20 3 5 2 4 80 30 10 25 40 70 50 90 100 75 85 95 110 120 8
Delete • If item is not in a leaf exchange with inorder successor. • If leaf has another item, remove item. • Examples: Remove(110); • (Insert(110); Remove(100); ) • If leaf has only one item but sibling has two items: redistribute items. Remove(80); 9
Remove(80); • Step 1: Exchange 80 with in-order successor. 45 20 3 5 2 4 85 30 10 25 40 70 50 90 100 75 80 95 110 120 10
• Redistribute Remove(80); 45 20 3 5 2 4 85 30 10 25 40 70 50 95 110 75 90 100 120 11
Some more removals… • Remove(70); Swap(70, 75); Remove(70); “Merge” Empty node with sibling; Join parent with node; Now every node has k+1 children except that one node has 0 items and one child. Sibling 95 110 can spare an item: redistribute. 12
Delete(70) 45 20 3 5 2 4 85 30 10 25 40 75 50 95 110 90 100 120 13
New tree: • Delete(85) will “shrink” the tree. 45 20 3 5 2 4 95 30 10 85 25 40 50 110 90 100 120 14
Details • • • 1. Swap(85, 90) //inorder successor 2. Remove(85) //empty node created 3. Merge with sibling 4. Drop item from parent// (50, 90) empty Parent 5. Merge empty node with sibling, drop item from parent (95) • 6. Parent empty, merge with sibling drop item. Parent (root) empty, remove root. 15
“Shorter” 2 -3 Tree 20 45 3 5 2 4 30 10 25 40 95 110 50 90 100 120 16
Deletion Summary • If item k is present but not in a leaf, swap with inorder successor; • Delete item k from leaf L. • If L has no items: Fix(L); • Fix(Node N); • //All nodes have k items and k+1 children • // A node with 0 items and 1 child is possible, it will have to be fixed. 17
Deletion (continued) • If N is the root, delete it and return its child as the new root. • Example: Delete(8); 5 5 1 3 2 8 3 3 Return 35 35 18
Deletion (Continued) • If a sibling S of N has 2 items distribute items among N, S and the parent P; if N is internal, move the appropriate child from S to N. • Else bring an item from P into S; • If N is internal, make its (single) child the child of S; remove N. • If P has no items Fix(P) (recursive call) 19
(2, 4) Trees • Size Property: nodes may have 1, 2, 3 items. • Every node, except leaves has size+1 children. • Depth property: all leaves have the same depth. • Insertion: If during the search for the leaf you encounter a “full” node, split it. 20
(2, 4) Tree 10 45 3 8 25 60 50 55 70 90 100 21
Insert(38); 45 10 60 3 8 25 38 50 55 70 90 100 22
Insert(105) • Insert(105); 45 10 3 8 25 38 60 90 50 55 70 105 23
Removal • As with BS trees, we may place the node to be removed in a leaf. • If the leaf v has another item, done. • If not, we have an UNDERFLOW. • If a sibling of v has 2 or 3 items, transfer an item. • If v has 2 or 3 siblings we perform a transfer 24
Removal • If v has only one sibling with a single item we drop an item from the parent to the sibling, remove v. This may create an underflow at the parent. We “percolate” up the underflow. It may reach the root in which case the root will be discarded and the tree will “shrink”. 25
Delete(15) 35 20 6 60 15 40 50 70 80 90 26
Delete(15) 35 20 6 60 40 50 70 80 90 27
Continued • Drop item from parent 35 60 6 20 40 50 70 80 90 28
Fuse 35 60 6 20 40 50 70 80 90 29
Drop item from root • Remove root, return the child. 35 60 6 20 40 50 70 80 90 30
Summary • Both 2 -3 trees and 2 -4 trees make it very easy to maintain balance. • Insertion and deletion easier for 2 -4 tree. • Cost is waste of space in each node. Also extra comparison inside each node. • Does not “extend” binary trees. 31
Red-Black Trees • Root property: Root is BLACK. • External Property: Every external node is BLACK (external nodes: null nodes) • Internal property: Children of a RED node are BLACK. • Depth property: All external nodes have the same BLACK depth. 32
A Red. Black tree. Black depth 3. 30 15 10 70 20 85 60 5 65 80 50 40 55 90 33
Red. Black Insertion 34
Red Black Trees, Insertion 1. Find proper external node. 2. Insert and color node red. 3. No black depth violation but may violate the red-black parent-child relationship. 4. Let: z be the inserted node, v its parent and u its grandparent. If v is red then u must be black. 35
Color adjustments. • Red child, red parent. Parent has a black sibling (Zig-Zag). a b u w v z Vl Zl Zr 36
Rotation • Z-middle key. Black height does not change! No more red-red. a b z u v Vl Zl Zr w 37
Color adjustment II a b u w v Vr z Zl Zr 38
Rotation II • v-middle key a b v u z Zl Zr Vr w 39
Recoloring • Red child, red parent. Parent has a red sibling. a b u w v z Vl Zr 40
Color adjustment • Red-red may move up… a b u w v z Vl Zl Zr 41
Red Black Tree • Insert 10 – root 10 42
Red Black Tree • Insert 10 – root (external nodes not shown) 10 43
Red Black Tree • Insert 85 10 85 44
Red Black Tree • Insert 15 10 85 15 45
Red Black Tree • Rotate – Change colors 15 10 85 46
Red Black Tree • Insert 70 15 10 85 70 47
Red Black Tree • Change Color 15 10 85 70 48
Red Black Tree • Insert 20 (sibling of parent is black) 15 10 85 70 20 49
Red Black Tree • Rotate 15 10 70 20 85 50
Red Black Tree • Insert 60 (sibling of parent is red) 15 10 70 85 20 60 51
Red Black Tree • Change Color 15 10 70 85 20 60 52
Red Black Tree • Insert 30 (sibling of parent is black) 15 10 70 85 20 60 30 53
Red Black Tree • Rotate 15 10 70 85 30 20 60 54
Red Black Tree • Insert 50 (sibling ? ) 15 10 70 85 30 20 60 50 55
Red Black Tree • Insert 50 (sibling of 70 is black!) 15 gramps 15 10 70 Child 30 Oops, red-red. ROTATE! 85 30 20 Parent 70 60 50 56
Red Black Tree • Double Rotate – Adjust colors 30 15 10 Child-Parent-Gramps 70 20 60 85 50 Middle goes to “top” Previous top becomes child. Its right child is middles left child. 57
Red Black Tree • Insert 65 30 15 10 70 20 85 60 50 65 58
Red Black Tree • Insert 80 30 15 10 70 20 85 60 50 65 80 59
Red Black Tree • Insert 90 30 15 10 70 20 85 60 50 65 80 90 60
Red Black Tree • Insert 40 30 15 10 70 20 85 60 50 40 65 80 90 61
Red Black Tree • Adjust color 30 15 10 70 20 85 60 50 40 65 80 90 62
Red Black Tree • Insert 5 30 15 10 70 20 85 60 5 50 40 65 80 90 63
Red Black Tree • Insert 55 30 15 10 70 20 85 60 5 65 80 50 40 55 90 64
Delete • We first note that a red node is either a leaf or must have two children. • Also, if a black node has a single child it must be a red leaf. • Swap X with inorder successor. • If inorder successor is red, (must be a leaf) delete. If it is a single child parent, delete and change its child color to black. In both cases the resulting tree is a legit red-black tree. 65
Delete demo • Delete 30: Swap with 40 and delete red leaf. 30 15 10 70 20 85 60 5 65 80 50 40 55 90 66
40 15 10 5 70 20 85 60 65 80 50 55 90 67
Inorder successor is Black Change colors along the traverse path so that the leaf to be deleted is RED. Delete 15. 30 15 10 70 20 85 60 5 65 80 50 40 55 90 68
General strategy • As you traverse the tree to locate the inorder successor let X be the current node, T its sibling and P the parent. • Color the root red. • Retain: “the color of P is red. ” • If all children of X and T are black: • P Black, X Red, T Red 69
P X A T B Both children of X and T are black: P Black X Red, T Red 70
P X A T B If X is a leaf we are done. Recall: x is the inorder successor! 71
Even though we want to proceed with X we have a red-red violation that needs to be fixed. P T has a red child. X T C 1 A D B Zig-Zag, C 1 Middle key. C 72
Note: black depth remains unchanged! C 1 P T X A B C D 73
B will become P’s right child. No change in depth. Third case P X T C 1 A B C T middle key. D 74
T P C 1 X A B C D 75
• If both children of T are red select one of the two rotations. • If the right child of X is red make it the new parent (it is on the inorder-successor path). • If the left child of X is red: 76
Root of C is black Otherwise, continue X has a red child P X C 1 T C B E Y A B 77
P C 1 T X E Y A B C 78
30 Delete 15 15 10 70 20 85 60 5 65 80 50 40 90 55 79
60 Delete 15 30 70 15 10 50 20 40 80 55 30 70 20 10 5 50 15 90 60 Swap (15, 20) 5 85 65 40 85 65 55 80 90 80
60 Delete 15 30 70 20 10 50 15 40 85 65 55 80 90 5 Third case: (mirror image) X (15) has two black children (Nulls) Sibling has one red and one black child. 81
60 Delete 15 30 70 10 5 50 20 40 85 65 55 80 90 82
