Building Joint Sealing with Kemperol V 210 Pictures

Building Joint Sealing with Kemperol V 210 Pictures & Details by Build Care Services India Pvt Ltd www. buildcare. in

Internal Seals over Crumple Joints Internal Seals

Vertical Expansion Joint Sealed with Kemperol V 210 A Closer View

Leaking RCC Gutters Holes in the RCC Gutters Detached Silicon Seal

ARRANGEMENT FOR SEALING EXP JT WITH PIPES GOING ACROSS

Gutters Repaired with Kemperol V 210

Sealing Crumple Joints at Terrace Level Kemperol V 210 Seal

Kemperol V 210 Seal Cracks Sealing Wall /Sheet Junctions

ARRANGEMENT FOR SEALING CRUMPLE JOINT NEXT TO PARAPET WALL Metal Cover Screwed on sides Flexible Waterproof Coating 75 mm 40 mm Figure 1 Parapet Wall if applicable ‘Kemperol’ Seal laid to slope for Tiles drainage Mud Phuska Slab 75 mm wide PCC 1: 1. 5: 3 cast in situ Supporting Beams/Walls Sketch not to Scale Polymer modified Gola

ARRANGEMENT FOR SEALING CRUMPLE JOINT 40 mm Flexible Waterproof Coating 75 mm Figure 2 Metal Cover Screwed on sides ‘Kemperol’ Seal laid to slope for Tiles drainage Mud Phuska Slab 75 mm wide PCC 1: 1. 5: 3 cast in situ Supporting Beams/Walls Sketch not to Scale Polymer modified Gola

SCHEMATIC ARRANGEMENT FOR EXPANSION JOINT SEALING Kemperol Seal (Double Fleece) RCC / Brick pedestal Junction Sealed with ‘Flexi Joint & Glass wool Fabric Terrace topping as applicable Expansion Joint RCC Slab Notes: 1. Sketch is Not to Scale 2. Junction of Slab & RCC/ Brick Pedestal will be sealed with ‘Flexi Joint & Glass wool Fabric to protect against leakage through this junction

SCHEMATIC ARRANGEMENT FOR EXPANSION JOINT SEALING Kemperol Seal (Double Fleece) RCC / Brick pedestal Junction Sealed with ‘Flexi Joint & Glass wool Fabric Terrace topping as applicable Expansion Joint RCC Slab Notes: 1. Sketch is Not to Scale 2. Junction of Slab & RCC/ Brick Pedestal will be sealed with ‘Flexi Joint & Glass wool Fabric to protect against leakage through this junction

Constituents of Kemperol V 210

Comparison with Conventional Sealants Silicon/ Polysulphide Kemperol V 210 Movement Accommodation upto 25% Movement Accommodation exceeds 50% Not paint able Paintable with acrylic or oil based paints Prone to detachment from edges Not prone to detachments Needs protection from wear & tear Can sustain normal foot traffic also Can not adapt to all configurations Can adapt to any shape and configuration Become stiff with prolonged exposure Maintain flexibility under prolonged exposure to extreme temperatures
