BROCADE BROCADE Demands Driving the Evolution of IT
BROCADE
BROCADE
Demands Driving the Evolution of IT Business Needs • Going Green – Corporate citizenship and cost reduction • Business Efficiency – Reduce Cap. Ex and Op. Ex costs • Zero Downtime – Customers expect high -quality service • Speed and Agility – Fast response to growth and demands • Information Security – Protect customer information IT Initiatives IT Requirements • Power Efficiency • – Increase capability within budget • Optimize Utilization – Refresh and grow in virtual architecture • – Server, storage, network w/ scale • Always On • – Data encryption, secure data transit Global Data Centers – State-of-the-art datacentric services • – Simplicity, low risk, non-disruptive • Data Protection Tiered Services – Right resource, right place, right price – Service availability and continuity • Resource Flexibility Consolidation SOA + SOI – Connectivity and sharing, services • Compliance – PCI, HIPAA, company directives
The Evolving Role of Servers in DCF Higher Levels of Connectivity and Virtualization • Physical servers consolidate, but now a higher percentage of virtual servers connect to the shared storage network Applications A Servers Data. Storage Center Fabric Network Storage A A • Applications will move across virtual servers and across the infrastructure, no longer attached to physical ports— the Data Center Fabric (DCF) must support this • More connected elements drives new network and infrastructure requirements for Adaptive Networking • Virtual-aware end-to-end management (server-tostorage) becomes critically important
Practical Use Cases for Today’s Technology Server Virtualization Consolidation, Evolution 8 Gbit/sec Backbone 8 Gbit/sec Switch or AG Virtual Machines 8 Gbit/sec Core • 8 Gbit/sec end to end greater bandwidth for aggregated Virtual Machines • 8 Gbit/sec ISLs improve server fan-in subscription • Adaptive Networking end to end (Qo. S, VM mobility with associated personality) • End-to-end unified SAN management Mainframe Director(s) 4 Gbit/sec SAN New 8 Gbit/sec Fabric 2 Gbit/sec SAN • Power and cooling efficiency • Integrated Routing flexibility for sharing and isolation • Interoperability for transforming current fabrics • Adaptive Networking for resource management • End-to-end unified SAN management Tiered Service Levels Data center fabric with Adaptive Networking Service levels guaranteed based on chargeback model and policies • Control of tiered service levels end to end (physical, virtual) • Dynamic Flow Control so service levels follow mobile workloads • Data security/encryption for both data in-flight and at-rest • Policy-based server/storage management
Brocade Data Center Fabric Connectivity Complete Family for End-to-End Flexibility and Choice
4 G/8 G HBA
BROCADE
Download site: www. bestbrocade. com. tw
標準 enable 8 port(含SFP*8) 每次可增加採購 BR 300系列專用 8 -port POD(含License&SFP)
• • 24 port 8 Gbit/sec 1 U switch 1: 1 subscription at 24 ports Ports-on-demand options for 8, 16, 24 ports HA features –hot code load, cooling • • • ISL Trunking - 68 Gbit/sec trunks (8 ports at 8. 5 G) Path load balancing –Dynamic Path Selection Long Distance support End-end path performance monitoring Common Fabric OS with existing entry to enterprise Brocade platforms Download site: www. bestbrocade. com. tw
標準 enable 24 port(含SFP*24) 每次可增加採購 BR 5100系列專用 8 -port POD(含License&SFP)
• • • 40 port 8 Gbit/sec 1 U switch 1: 1 subscription at 40 ports Ports-on-demand options for 24, 32, 40 ports HA features –hot code load, hot-swap power, cooling ISL Trunking -68 Gbit/sec trunks (8 ports at 8. 5 G) Path load balancing –Dynamic Path Selection Long Distance support End-end path performance monitoring Common Fabric OS with existing entry to enterprise Brocade platforms Download site: www. bestbrocade. com. tw
• • 80 port 8 Gbit/sec 2 U Enterprise switch 1: 1 subscription at 80 ports Ports-on-demand options for 48, 64, 80 ports HA features –hot code load, hot-swap power, cooling • • • ISL Trunking - 68 Gbit/sec trunks (8 ports at 8. 5 G) Path load balancing –Dynamic Path Selection Long Distance support End-end path performance monitoring Common Fabric OS with existing entry to enterprise Brocade platforms Download site: www. bestbrocade. com. tw
Brocade SAN SWITCH & HBA Promotion Program P/N FC SWITCH + HBA 群環Y 10 Q 1~Q 2 Description 4 G + 4 G HBA 8 G + 8 G HBA 經銷特惠價 備註 GP% 業務成本 BR-320 -0004 -H BR 320(4 G 8 P) *1台 + HBA (4 G-HBA)*1 組 145, 000 BR-340 -0004 -H BR 340(4 G 16 P) *1台 + HBA (4 G-HBA)*2 組 230, 000 BR-360 -0004 -H BR 360(4 G 24 P) *1台 + HBA (4 G-HBA)*4 組 330, 000 BR-320 -0008 -H BR 320(8 G 8 P) *1台 + HBA (8 G-HBA)*1 組 165, 000 BR-340 -0008 -H BR 340(8 G 16 P) *1台 + HBA (8 G-HBA)*2 組 271, 000 BR-360 -0008 -H BR 340(8 G 24 P) *1台 + HBA (8 G-HBA)*4 組 392, 000 BR-415 -0010 Brocade PCI-E 4 G bps HBA (含 5 m 光纖線乙條) 16, 000 BR-425 -0010 Brocade PCI-E 4 G bps HBA (含 5 m 光纖線乙條) 25, 000 BR-815 -0010 Brocade PCI-E 8 G bps HBA (含 5 m 光纖線乙條) 24, 000 BR-815 -0010 Brocade PCI-E 8 G bps HBA (含 5 m 光纖線乙條) 30, 000 BR-320 -0004 BROCDAE 320, 8 P, FULL FABRIC, 4 Gb SWL SFPs 130, 000 BR-340 -0004 BROCDAE 340, 16 P, FULL FABRIC, 4 Gb SWL SFPs 200, 000 BR-360 -0004 BROCDAE 360, 24 P, FULL FABRIC, 4 Gb SWL SFPs 270, 000 BR-320 -0008 BROCDAE 320, 8 P, FULL FABRIC, 8 Gb SWL SFPs 145, 000 BR-340 -0008 BROCDAE 340, 16 P, FULL FABRIC, 8 Gb SWL SFPs 235, 000 BR-360 -0008 BROCDAE 360, 24 P, FULL FABRIC, 8 Gb SWL SFPs 320, 000 HBA 4 G FC SWITCH 單機促銷 8 G 4 G 8 G Brocade SWITCH 群環保固三年零件交換 Brocade SWITCH 免費安裝項目 - 1. 機器上架 2. 上電確認機器正常 3. 設定管理IP 4. 更新firmaware到最新版 5. 啟動license
