Broadband Solution u Passive Optical Network (GEPON) u Fiber Optical Network u VDSL (Very-high-data-rate Digital Subscriber Line) Ø VDSL 2 u ADSL (Asymmetric Digital Subscriber Line) Ø ADSL 2+ 2
Product Features Passive Optical Network (GEPON)
GEPON Solution GEPON OLT GEPON ONU EPL-2220 EPN-110 / EPN-103 2 -PON Port GEPON OLT with Uplink 2 -Port 1000 Base-X SFP Slot ( 1 -PON Interface, 1 -Port FE + 1 -Port Gb. E Interface) u 1. 25 Gbps for upstream and downstream u Up to 20 km distance u Up to 64 ONUs split ratio per GEPON port u PON interface complies with IEEE 802. 3 ah u Dynamic Bandwidth Allocation (DBA) support u 802. 1 x authentication engine u 802. 1 q VLAN and 802. 1 p Qo. S support u Supports IGMP 4
GEPON Application u FTTH EPL-2220 5
Product Features Fiber Optical Network
Fiber Optical Network u Carrier Fiber Ethernet Solution SGS-6340 -16 XR XGS-6350 -12 X 8 TR XGS 3 -24242 GS-5220 -46 S 2 C 4 X MGSW-28240 F 16 -Port 10 G SFP+ Layer 3 Stackable Managed Switch 12 -Port 10 G SFP+ Layer 3 Managed Switch 24 -Port Gigabit SFP + 16 -Port Shared TP + 4 -Port 10 G SFP+ Layer 3 Stackable Managed Switch 46 -Port Gigabit SFP + 2 -Port Gigabit TP/SFP + 4 -Port 10 G SFP+ L 2+ Managed Switch 24 -Port Gigabit SFP with 4 -Port 10 G SFP+ L 2/L 4 Managed Metro Ethernet Switch u Cost-effective FTTH Solution FRT-405 FRT-415 N Wired + Wireless Up to 15 Km Up to 120 Km 7
10 G Ethernet FTTx Applications ü 10 Gb Ethernet ü Single IP Management up to 24 units ü Layer 3 IPv 6/IPv 4 Routing ü IP Routing protocol: l RIP v 1/v 2 l OSPF v 2/v 3 l BGP 4/4+ l VRRP v 1/v 3 ü IPv 6/IPv 4 Tunneling ü IPv 6/IPv 4 Dual Stack ü IPv 6/IPv 4 ACL & Qo. S ü Enhanced Security 8
Fiber Router Total Solution u Two-way 100 Mbps Optical Fiber Communication u Point-to-Point and Point-to-Multipoint Fiber Applications u IPv 6/IPv 4 Dual-Stack Networks u 300 Mbps High-Speed Wi-Fi Connection u Able to handle multiple HD services, such as IPTV, Vo. IP, Online Gaming 9
Product Features VDSL Products
VDSL 2 Profile 30 a Downstream/Upstream 100/100 Mbps VDSL 2 IP DSLAM VDSL 2 CO Switch Redundant Status VDSL 2 Port. Power Configuration VDL-2420 M (24 -Port VDSL 2) VC-820 M (8 -Port VDSL 2 + 2 G) Management features VDSL 2 Port Configuration VDSL 2 Router Redundant Power Status VDSL 2 Bridge CPE VDR-300 NU VDR-301 N VC-231 G VC-234 G 11
Features VDL-2420 M u High-Performance of Ethernet over VDSL 2 Solution ü ü ü u 24 Full-Duplex VDSL 2 links via RJ 21(Telco-50) connector Up to 100/100 Mbps symmetric data rate within 300 m 2 10/1000 Mbps TP and SFP shared combo interfaces Built-in POTS Splitters flexible link option VDL-2420 M VDSL 2 30 a profile 100~240 V AC / 48 V DC Dual power redundant Delivers High-Demand Services Connectivity for ISP / Triple Play Devices ü ü ü VOD (Video on Demand) Voice over IP Video phone IPTV Distance education 12
Features VC-231 G / VC-234 G / VC-232 G High-speed Ethernet over VDSL 2 Converter/Bridge/Extender u Upstream/Downstream bandwidth up to 200/160 Mbps u Extends Ethernet up to 1. 4 km over 2 -wire twisted pair u 4 -port 10/1000 BASE-T Gigabit LAN u 1 -/4 -port RJ 11 connector for VDSL 2 connection u ITU-T G. 993. 2 VDSL 2 Profile 30 a u ITU-T G. 993. 5 G. Vectoring and G. INP for improvement of VDSL 2 line performance u CO/CPE mode selectable via DIP switch u ADSL 2+ is backward compatible (VC-231 G) u Built-in POTS splitter (VC-234 G) u Used in pairs to extend Point-to-Point connection up to 1. 4 km (VC-232 G) u VC-231 G Ethernet over VDSL 2 Converter VC-234 G Ethernet over VDSL 2 Bridge VC-232 G Ethernet over Coaxial Extender Uses existing coaxial cable - RG 59, RG 6 or RG 7 (VC-232 G) 13
Features VDR-301 N 802. 11 n Wireless VDSL 2 Router u VDSL 2 G. Vector / ADSL 2+ in one solution, up to 100/100 Mbps up/downstream u 300 Mbps 2. 4 GHz Wireless Connectivity u Supports IPv 6/IPv 4 Dual Stack Network, DLNA, DMZ, IGMP, Qo. S, Virtual Server u Supports IPsec to implement VPN u TR-069 and SNMP Remote Management VDR-301 N 14
Product Features ADSL 2/2+ Products
ADSL 2/2+ IDL-2402 IDL-4802 IP DSLAM 48 ports, IP/Hardware Stacking) ADSL Profile VDSL 2 & ADSL 2+ Router/CPE 24 ports, IP Stacking 802. 1 x Security VLAN VC-231 G VC-234 G Ethernet over x. DSL Converter Ethernet over x. DSL Bridge SNMP VDR-301 N 802. 11 n Wireless VDSL 2 Bridge/Router 16
Features IP DSLAM u u SNMPProfile 802. 1 x Security VLAN ADSL 17
Comparions IP DSLAM IDL-2402 IDL-4802 24 48 1 Gb. E 2 Gb. E Combo 25 M / 3 M 5. 6 km Web Management V V Hardware Stackable - Up to 4 Units IP Stacking - Up to 4 Units Co-existing with Voice V V Model Feature DLS ports Ethernet ports Max. Speed (Downstream/ Upstream) Max. Distance 18
u View PLANET Broadband Communication solution online 19
