Broadband Communication Solution Broadband Solution u Passive Optical
Broadband Communication Solution
Broadband Solution u Passive Optical Network (GEPON) u Fiber Optical Network u VDSL (Very-high-data-rate Digital Subscriber Line) Ø VDSL 2 u ADSL (Asymmetric Digital Subscriber Line) Ø ADSL 2+ 2
Product Features Passive Optical Network (GEPON)
GEPON Solution GEPON OLT GEPON ONU GEPON Wi. Fi ONU EPL-2220 EPN-110 / EPN-103 EPN-402 NV 2 -PON Port GEPON OLT with Uplink 2 -Port 1000 Base-X SFP Slot ( 1 -PON Interface, 1 -Port FE + 1 -Port Gb. E Interface) ( 1 -PON Interface, 4 -Port FE + 2 -Port FXS, 300 Mbps 802. 11 n Wi. Fi) u 1. 25 Gbps for upstream and downstream u Up to 20 km distance u Up to 64 ONUs split ratio per GEPON port u PON interface complies with IEEE 802. 3 ah u Dynamic Bandwidth Allocation (DBA) support u 802. 1 x authentication engine u 802. 1 q VLAN and 802. 1 p Qo. S support u Supports IGMP 4
GEPON Application u FTTH EPL-2220 5
Product Features Fiber Optical Network
Fiber Optical Network u u Carrier Fiber Ethernet Solution SGS-6340 -16 XR XGS 3 -24242 GS-5220 -46 S 2 C 4 X MGSW-28240 F 16 -Port 10 G SFP+ Layer 3 Stackable Managed Switch 24 -Port Gigabit SFP + 16 -Port Shared TP + 4 -Port 10 G SFP+ Layer 3 Stackable Managed Switch 46 -Port Gigabit SFP + 2 -Port Gigabit TP/SFP + 4 -Port 10 G SFP+ L 2+ Managed Switch 24 -Port Gigabit SFP with 4 -Port 10 G SFP+ L 2/L 4 Managed Metro Ethernet Switch Cost-effective FTTH Solution FRT-405 FRT-415 N Wired + Wireless Up to 15 Km Up to 120 Km 7
10 G Ethernet FTTx Applications ü 10 Gb Ethernet ü Single IP Management up to 24 units ü Layer 3 IPv 6/IPv 4 Routing ü IP Routing protocol: l RIP v 1/v 2 l OSPF v 2/v 3 l BGP 4/4+ l VRRP v 1/v 3 ü IPv 6/IPv 4 Tunneling ü IPv 6/IPv 4 Dual Stack ü IPv 6/IPv 4 ACL & Qo. S ü Enhanced Security 8
Fiber Router Total Solution u Two-way 100 Mbps Optical Fiber Communication u Point-to-Point and Point-to-Multipoint Fiber Applications u IPv 6/IPv 4 Dual-Stack Networks u 300 Mbps High-Speed Wi-Fi Connection u Able to handle multiple HD services, such as IPTV, Vo. IP, Online Gaming 9
Product Features VDSL Products
VDSL 2 Profile 30 a Downstream/ Upstream 100/100 Mbps VDSL 2 IP DSLAM VDSL 2 CO Switch Redundant Status VDSL 2 Port. Power Configuration VDL-2420 M (24 -Port VDSL 2) VC-820 M (8 -Port VDSL 2 + 2 G) Management features VDSL 2 Port Configuration VDSL 2 Router Redundant Power Status VDSL 2 Bridge CPE VDR-300 NU VDR-301 N VC-231 VC-234 11
Features VDL-2420 M u High-Performance of Ethernet over VDSL 2 Solution ü ü ü u 24 Full-Duplex VDSL 2 links via RJ 21(Telco-50) connector Up to 100/100 Mbps symmetric data rate within 300 m 2 10/1000 Mbps TP and SFP shared combo interfaces Built-in POTS Splitters flexible link option VDL-2420 M VDSL 2 30 a profile 100~240 V AC / 48 V DC Dual power redundant Delivers High-Demand Services Connectivity for ISP / Triple Play Devices ü ü ü VOD (Video on Demand) Voice over IP Video phone IPTV Distance education 12
Features VDR-300 NU / VDR-301 N 802. 11 n Wireless VDSL 2 Router u VDSL 2 G. Vector / ADSL 2+ in one solution, up to 100/100 Mbps up/downstream u 300 Mbps 2. 4 GHz or 5 GHz Dual-band Wireless Connectivity u 2 x USB ports for 3 G WAN, Printer and Storage Sharing u Supports IPv 6/IPv 4 Dual Stack Network, DLNA, DMZ, IGMP, Qo. S, Virtual Server u Supports IPsec to implement VPN u TR-069 and SNMP Remote Management VDR-300 NU VDR-301 N 13
Product Features ADSL 2/2+ Products
ADSL 2/2+ XDL-2420 R (24 ports ADSL 2+ / VDSL 2) IP DSLAM IDL-4802 (48 ports, IP / Hardware Stacking) ADSL Profile ADSL 2/2+ Router VLAN IDL-2402 (24 ports, IP Stacking) 802. 1 x Security SNMP ADN-4102 11 n ADSL 2/2+ Router 15
Features IP DSLAM u u SNMPProfile 802. 1 x Security VLAN ADSL 16
Features IP DSLAM XDL-2420 R IDL-2402 IDL-4802 24 24 48 Ethernet ports 2 Gb. E Combo 1 Gb. E 2 Gb. E Combo Max. Speed (Downstream/ Upstream) 25 M / 3 M Max. Distance 5. 6 km Web Management V V V Hardware Stackable - - Up to 4 Units IP Stacking - - Up to 4 Units Co-existing with Voice V V V Model Feature DLS ports 17
Features ADN-4102 150 Mbps 802. 11 n Wireless ADSL 2/2+ Router u Built-in ADSL 2/2+ Modem u WDS / WPS for easy wireless connection u 802. 1 p Qo. S compatible u UPn. P and DDNS function u VPN Passthrough support u Firewall with NAT and IP / MAC / Application / URL filtering ADN-4102 18
ADN-4102 Application 19
