BRIGHTSIGN AU 335 UltraAffordable High Bandwidth Digital Audio

BRIGHTSIGN AU 335 Ultra-Affordable, High Bandwidth Digital Audio Player August 2020

AGENDA § AU 335 Product Overview § Pricing & Availability § Sales Tools § Notable Specifications § Applications § Bright. Author: connected Audio Presentations § Questions?

INTRODUCING AN AUDIO-ONLY BRIGHTSIGN PLAYER Bright. Sign AU 335 Ultra-affordable, high bandwidth digital audio player designed with Bright. Sign’s signature reliability

BRIGHTSIGN AU 335 Features § Distributes quality high bandwidth, 24 -bit audio to ARC/e. ARC soundbars & AV receivers including Dolby Atmos , Dolby Audio™ and PCM audio § Supports up to three audio zones routed to the ARC/e. ARC or stereo analog audio outputs § Supports interactive devices via USB, GPIO & Ethernet USB also operates in host mode to update firmware on connected devices § Controls soundbar volume and input switching via CEC commands § Distributes background music to your venue § Synchronizes with additional Bright. Sign players, lighting and other devices to create unique experiences § Includes free Control Cloud subscription to BSN. cloud for access to real time player health and controls § Supports presentation authoring through free Bright. Author: connected, Bright. Script, Java. Script, and node applications or your choice of an integrated CMS solution AU 335 Digital Audio Player

AU 335 CONNECTIONS I/O ports & dimensions § Micro HDMI ARC/e. ARC output 99 § Analog stereo audio output . 9 § USB Type C § GPIO § 100 base. T Ethernet § Micro SD card slot § Locking power § LED indicators 27. 9 mm 173. 4 mm m m

PRICING & AVAILABILITY § Ultra-affordable pricing at $135 MSRP with tiered pricing for the channel § Available mid-September AU Audio Only $135 LS HD XD XT Entry Level Mainstream Advanced Enterprise $250 $350 -$450 -$550 -$850

AU 335 SALES TOOLS § Product webpage § Datasheet § Online webstore § Sales Deck

AU 335 NOTEWORTHY SPECIFICATIONS

VALUE OF ARC/e. ARC SUPPORT (Audio Return Channel / Enhanced Audio Return Channel) § The ARC standard was designed specifically to replace S/PDIF digital audio outputs for high quality audio to a sound bar or AV receiver § Supports high quality audio over an HDMI 2. 1 connection § Supports every audio format that would normally pass through S/PDIF including Dolby Audio, DTS and PCM audio § e. ARC supports higher bitrate audio playback allowing you to send higher-quality audio Feature S/PDIF digital audio ARC e. ARC Connection 3. 5 mm audio port HDMI 2. 1 (micro HDMI on AU 355) HDMI 2. 1 Max Audio Bandwidth ~384 Kbits/second ~1 Mbits/second 37 Mbits/second High Bitrate audio up to 192 k. Hz, 24 -bit No No Yes Audio formats Dolby Audio, DTS & PCM audio Dolby Audio, PCM audio, Dolby Atmos

AU 335 STREAMLINED SETUP for ARC/e. ARC Audio Applications Bright. Sign Setup for ARC/e. ARC audio BEFORE AU 335 TV was required to send ARC/e. ARC audio to AV receivers & soundbars even if a display wasn’t need for the application Bright. Sign Setup to play ARC/e. ARC audio AFTER AU 335 AU directly sends audio to the AV receivers & soundbars HDMI Micro HDMI TV needed to send ARC/e. ARC audio to soundbar HDMI

PRODUCT APPLICATIONS Soundbar retail displays • e. ARC audio allows for Dolby ATMOS and other high bandwidth audio delivery • CEC enables Soundbar volume and source control • Dual Role USB allows for host mode to provide device updates and device mode for interactive components

PRODUCT APPLICATION Background Audio Distribution • Cost-effective audio distribution device • Java. Script programming environment • Analog audio interface

THANK YOU!
