Bridges Andria Rogers Beam Bridges A beam bridge
Bridges Andria Rogers
Beam Bridges A beam bridge is a type of bridge that is made of horizontal beams that are supported by piers at each end. Fort Pitt Bridge Pittsburgh, PA
Cantilever Bridges Jadukata Bridge, Meghalaya Cantilever bridges are constructed with cantilevers which are horizontal beams that are only supported on one end. The majority of cantilever bridges are made using two cantilever arms that extend from opposite sides and meet in the middle.
Suspension Bridges Clifton Suspension Bridge Suspension bridges are suspended towers that are attached to from cables. The cables often hang from caissons or cofferdams. The caissons or cofferdams are implanted deep into the floor of a lake or river over which the bridge is suspended.
Truss Bridges Truss bridges are constructed using connected elements. These elements include a solid deck and a lattice of pin-jointed girders for the sides. Truss bridges are made completely of metals such as wrought iron and steel or sometimes of reinforced concrete.
Arch Bridges Arch bridges are arch-shaped and have abutments at each end. The weight of the truss bridge is thrust into the abutments at either side.
Bridges in Literature
Bridges in Film The Mothman Prophecies (2002) In the movie The Mothman Prophecies, the Silver Bridge collapses near the end of the movie.
Bridge Disasters Hayakawa Wire Bridge. Japan, 1980 Wire bridge. There was a lack of inspection and maintenance of the bridge for the previous decade which lead to its descent. Honeymoon Bridge- Niagara Falls, January 27, 1938 Steel arch road bridge. An ice jam in the gorge pushed the supports off their foundations. Quebec Bridge- Quebec, September 11 1916 Cantilever bridge made of steel. This bridge collapsed during construction due to an error in design because it could not hold its own weight
Rainbow Bridge - Fort Morgan, Colorado Famous Bridges Tower Bridge Manhattan Bridge
Physics of Bridges Compression is a force that acts to compress or shorten the thing it is acting on, which would be the arms of the bridge. Tension is a force that acts to expand or lengthen the thing it is acting on (bridge). Stress, or shear, is a force applied parallel to a bridge when something travels on or across it. Strain is the force which stress causes.
