Bluetooth Advances In Windows Vista And Beyond Vatsal

Bluetooth Advances In Windows Vista And Beyond Vatsal Bhardwaj Program Manager Windows Device Experience Group Microsoft Corporation

Outline Bluetooth advances in Windows Vista Partner slides: CSR Bluetooth features post Windows Vista Partner slides: Dell Inc Call to action

Core Stack Enhancements For Windows Vista Synchronous connection oriented links Channel avoidance Radio class driver enabled by Microsoft OS descriptors Pre-boot HID support for Bluetooth keyboards and mouse

Extensibility Improvements For Windows Vista Logical link control adaptation protocol (L 2 cap) and Service discovery protocol (SDP) interfaces Synchronous connection oriented links (SCO) interfaces Device installation extensibility Installation based on Bluetooth host controller (local) Installation interfaces for Server-side profiles

Profiles On Windows Vista Silicon agnostic headset and handsfree profiles available via Microsoft Update on Windows Vista Also available to PC OEMs for factory preinstall Stereo audio profiles (A 2 DP, AVRCP) available on Windows native stack via Bluetooth silicon vendors Microsoft update for stereo audio profiles currently being investigated Other profiles (FTP, BIP, BPP) available via Bluetooth silicon vendors

New Logo Requirements For Bluetooth Radios On Windows Vista Must support Bluetooth 2. 0 + EDR specifications as defined by the Bluetooth SIG Microsoft plans to upgrade stack qualification to Bluetooth 2. 0 + EDR Must support synchronous connection oriented links as defined by the Bluetooth SIG

Value Proposition of Bluetooth on Windows Vista Consumers Improved sync experience Better coexistence with 802. 11 “Ultimate” Headset experience Support for new Bluetooth radios Support for high growth profiles

Value Proposition of Bluetooth on Windows Vista OEMs and device vendors Extensible platform and reduced time to market for partners developing custom solutions Improved device coverage by Microsoft OS descriptors based radio class driver Support for high growth profiles Qualification update to Bluetooth 2. 0 + EDR

CSR David Mc. Call Vice President PC Strategic Business Unit

CSR Vista Profile Pack Adds profiles & features built on Microsoft Bluetooth APIs Stereo Audio A 2 DP & AVRCP Profiles Works with both HID & Mono Audio Additional Vo. IP clients for Mono Audio Skype Pre-boot HID Allows mouse/keyboard connection in BIOS

CSR’s Experience APIs are straight forward to use Rich interface with good granularity BRB interface follows familiar URB pattern Limitations: No RFCOMM access from kernel mode No API for Qo. S (bandwidth management & allocation) Error return codes for kernel mode APIs give limited information

Post Windows Vista Feature Considerations Core stack enhancements Simplified pairing Standardized pre boot HID solution Sniff Sub-rating Quality of service User experience Revamp of overall user experience based on Simplified pairing Improved dial-up networking and Internet connection setup experience

Post Windows Vista Feature Considerations Inbox inclusion of high growth profiles Headset and Handsfree profile Stereo audio profiles (A 2 DP, AVRCP) Other profiles which customers request Additional developer support New samples for SDK Function discovery integration (consistent APIs to discover Bluetooth devices)

Post Windows Vista Logo Requirements & Considerations Bluetooth 2. 0 + EDR requirements for HID, Printers and Headsets Microsoft OS descriptors requirement for Bluetooth radios Logo program for Bluetooth headset devices

Dell Inc Liam Quinn Director Comms & Peripherals Architecture

The Vision Ubiquitous connectivity Wireless usage continues to evolve, enabling seamless network and device connectivity… My_Network My_Data GPS WLAN WWAN BWA RFID WPAN Airport èCustomer èOffice èHome

WPAN Usage Models Bluetooth continues to gain momentum and UWB will extend the WPAN usage model Mobile/Smart HH STB/Media Center PC BT Model UWB Model Photo/Printer Mass Storage • Cable Replacement/ad-hoc connectivity • Scaleable WPAN solutions with Bluetooth and UWB HDTV KB, Mouse DVC Voice, Stereo Audio DSC

Wireless PAN Technology Landscape UWB is a natural extension to Bluetooth in terms of cable replacement and data rates … HS-WPAN 60 GHz WPAN 5 – 10 Gbps UWB BT + UWB 3. 1 – 4. 8 GHz 2. 4/3. 1 - 10. 6 GHz 3 – 480 Mbps >1+ Gbps 100 – 480 Mbps BT 2. 0+EDR CY 05 4 G WPAN ? BT 2. 1 CY 06 CY 07 WPAN Vision • Integrated WPAN (BT + UWB) solutions • BT backward compatibility with existing applications • Higher data rate support and extensibility • User transparency – Select, Detect, Connect • Eo. U, Qo. S and Security • Wireless Docking, multimedia Streaming. . • Worldwide regulatory compliance CY 08 CY 09 CY 10

Design Challenges & Opportunities The number of integrated wireless devices and design challenges continues to increase … Platform Design Challenges RFID Tag • Platform Size and mechanicals • I/O Bus Interface Transitions • System Power, Thermal, Voltage Rails • RF, EMI, regulatory and Public Policy WWAN/GPS Antennas WLAN Antennas Where You can help • Leverage economies of scale in terms of silicon integration, product interoperability, logo certification, lower power, size Mini Card and cost SIM • Develop solutions for global markets • Provide seamless WPAN solutions for end-user experience and usage transparency • Single user interface, auto connect and pairing. Bluetooth + UWB • Develop a clear marketing and branding Strategy

Call to Action ALL Install the Vista Beta 2 builds on your machines and use the Microsoft stack for Bluetooth Send us your feedback on Bthfb @microsoft. com OEMs Adopt Microsoft stack for Bluetooth on Windows Vista Device vendors and IHVs Support Bluetooth 2. 0 + EDR in your products Support Simple pairing Support Quality of service

Contact Information For feedback on Microsoft stack for Bluetooth or general Bluetooth feedback Bthfb @ microsoft. com For feedback on Microsoft SDK for Bluetooth Bthapi @ microsoft. com For feedback on Microsoft DDK for Bluetooth Bthddi @ microsoft. com For requesting details on Microsoft OS descriptors based Compat ID for Bluetooth radios Bthddi @ microsoft. com
