BIT ERROR RATE PERFORMANCE OF 64 PSK IN AWGN CHANNEL

GROUP MEMBERS: v v v M. Junaid Khalid 048) (DDP-SP 12 -BTE- Danial Ali 016) (DDP-FA 12 -BTE- Sheraz Saleem 110) (DDP-FA 12 -BTE-

OUTLINE INTRODUCTION M-ARY MODULATION M-PSK MODULATION 64 -PSK MODULATION AWGN CHANEEL BIT ERROR RATE Theoretical BER of 64 -PSK RESULTS CONCLUSION

INTRODUCTION v Binary Phase Shift Key (BPSK) v AWGN Channel v Bit Error Rate

INTRODUCTION

INTRODUCTION

BINARY MODULATION

M-ARY MODULATION To use M-ary modulation, the bit stream is blocked into groups of λ bits. The number of bit patterns is M = 2λ

M-PSK MODULATION In this modulation type, the information is encoded in the phase of the transmitted signal.

64 -PSK MODULATION The signals lie on a circle of radius √Es, and are spaced every 2π/M radians around the circle. 64 -PSK Constellation Diagram

NOISY CONSTELLATION DIAGRAMS IN AWGN CHANNEL

BIT ERROR RATE The bit error rate or bit error ratio (BER) is the number of bit errors divided by the total number of transferred bits during a studied time interval. Bit error rate (BER) is a parameter which gives an excellent indication of the performance of a data link.

THEORETHICAL BER OF 64 -PSK k=log 2 M k=log 2(64) k=6 bits

RESULTS

CONCLUSION BPSK has following specification such as: High data rate High power efficiency (minimum required transmit power) Low cost implementation

CONCLUSION Bandwidth and Power Efficiency of M-PSK Signals
