Biclustering of Expression Data by Yizong Cheng and Geoge M. Church Presented by Bojun Yan March 25, 2004

outline 1. Micro. Array and its relative research 1. 1 Micro. Array Gene Expression Data 1. 2 Main research about Micro. Array 2. Why Bicluster? 2. 1 Preceding research and its faults 2. 2 The concept of Bicluster 2. 3 Similarity measure 3. The hardness of Bicluster

4. Methods proposed by this paper 4. 1 Relative Works and paper’s goal 4. 2 Definition of mean squared residue score 4. 3 Some special matrices’ scores 4. 4 Some Theorems deduced by authors 4. 5 Algorithms proposed by this paper 5. Experiment 5. 1 Data preparation 5. 2 Determining Algorithm Parameters 5. 3 Final Algorithm 5. 4 Results and Display

1. Micro. Array and its relative Research 1. 1 Micro. Array Gene expression data: Being generated by DNA chips and other microarray technique, Row---Genes, Column---Conditions or Samples 1. 2 Main Research about Micro. Array (1) Gene Clustering: Finding the genes having similar functions (2) Conditions Clustering: Helpful to case analysis (3) Classification: Tumor Classification, Cancer prediction (4) Gene Selection: Find the genes relative to some disease (5) Gen Network: Explore the regulatory interaction between the genes 1. 3 Paper Target: Biclustering

2. Why Bicluster? 2. 1 Preceding research and its faults • Goal: Discover the regulatory patterns or condition similarities • Methods: Based on Euclidean distance or the dot product between the vectors (equally weighted) (1) Group genes (row) (2) Group conditions (column) • Result: Partition the genes or conditions into mutually exclusive groups or hierarchies

• Faults: obscuring some other similarity groups while discovering some similarity groups 2. 2 The concept of Bicluster Clustering the genes(rows) and conditions(columns) simultaneously---subspace clustering 2. 3 Similarity Measure (1)Based on Distance Metric, such as Minkowski distances (2)Cosine Measure

(3)Pearson Correlation (4)Extended Jaccard Similarity (5)Mean Sqare Residue (proposed by this paper) + A measure of the coherence of the genes and conditions in the bicluster + Symmetric function of the genes and conditions + Group genes and conditions simultaneously

3. Hardness of the bicluster • The problem of finding a maximum bicluster with a score lower than a threshold includes the problem of finding a maximum biclique in a bipartite graph as a special case • Finding the largest constant square submatrix is proven to be NP-hard (Johnson, 1987) • The problem of finding a minimum set of biclusters, either mutually exclusive or overlapping, to cover all the elements in a data matrix has been shown to be NPhard(Orlin, 1977)

4. Methods proposed by this paper 4. 1 Relative Works and the paper’s goal (1) Relative Works • Divisive algorithm: partitioning data into sets with approximately constant values, proposed by Morgan and Sonquist(1963) and Hartigan(1972) • Hartigan mentioned that the criterion for partitioning may be a two-way analysis of variance model, similar to the mean squared residue scoring proposed in this article • Mirkin(1996) presents a node addition algorithm.

• “biclustering” has been used by Mirkin(1996), which means simultaneous clustering of both row and column sets in a data matrix. • The term “direct clustering”(Hartigan 1972), and “box clustering”(Mirkin, 1996) have the same meaning. (2) The Paper’s Goal and criterion: • Goal: Finding of a set of genes showing strikingly similar up-regulation and down-regulation under a set of conditions. • Criterion: A low mean squared residue score plus a large variation from the constant as a criterion for identifying these genes and conditions • Overlapping: Biclusters should be allowed to overlap in expression data analysis

4. 2 Definition of mean squared residue score

The row variance: It is an accompanying score to reject trival or constant biclusters.

4. 3 Scores of some special matrice • A special case for a perfect score( a zero mean squared residue score) is a constant bicluster of elements of a single value • For the matrix aij=ij, i, j>0, no submatrix of a size larger than a single cell has a score lower than 0. 5 • A K×K matrix of all 0 s except one 1 has the score Equation: • A matrix with elements randomly and uniformly generated in the range of [a, b] has an expected score of (b-a)/12. For example the range is [0, 800], the expected score is 53, 333.

• Some characteristic of mean square residue score (1)Adding a constant number to the matrix will not affect the H(I, J) score (2)Multiplying a constant number will affect the score (by the square of the constant) (3)Both will not affect the ranking of the biclusters in a matrix

4. 4 Theorems deduced by authors

Comments on Algorithm 0: • Algorithm 0, although a polynomial-time one, will not be efficient enough for a quick analysis of most expression data matrices. • The complexity of Algorithm 0 is o((n+m)nm)

Comments on Algorithm 1: • In each iterate, a complete recalculation for step 1 and step 2 is needed • The time complexity of Algorithm 1 is o(nm) • Higher efficiency than Algorithm 0, but not the best.

Comments on Algorithm 2: • Need to properly select parameter α>1 • Without updating the score after the removal of each node • The time complexity of Algorithm 2 is o(logn+longm) • One may miss some large δ-bicluster

Comments on Algorithm 3: • The time complexity is o(mn) • The resulting δ-bicluster may still not be maximal because of two reasons: (1)Lemma 3 only gives a sufficient condition for adding rows and conditions (2)By adding rows and columns, the score may decrease to the point it much smaller than δ

5. Experiment 5. 1 Data preparation Datasets and Parameters: (1)Yeast data, o-value=300, n=100 (2)Human data, o-value=1200, n=100 Missing Data Replacement: Replace the missing data using the random number underlying the uinform distriubiton Biclusters is Compared to the Cluster results from (1)Travazoie et al. (1999) (2)Alizadeh et al. (2000)

5. 2 Determining Algorithm Parameters Thinking about the clusters from the papres Travazoie et al. (1999) and Alizadeh et al. (2000) For yeast data, δ= 300, α=1. 2 For human gene data, δ= 1200, α=1. 2 The number of biclusters is n=100 Masking discovered Biclusters: Each time a bicluster was discovered, the elements in it will be replaced by random number because the algorithms are deterministic 5. 3 Final Algorithm

Biclusters for Yeast data

Biclusters for human data
