BAE SYSTEMS Organization Structure Sir Richard Evans* Chairman John Weston* CEO Tony Mc. Carthy Group HR Director Dave Gardner Tony Rice Group MD Ventures Sir Charles Masefield* Group Engineering Director Group Marketing Director Roger Hawksworth Chief of Staff Mike Turner* Integration Steve Mogford* COO Mike Rouse Group MD International Partnerships Functional Directors Alison Wood Group Strategy & Planning Director Michael Lester* COO Mark Ronald Hugh Colver CEO and President BAE SYSTEMS North America Inc Terry Morgan Group MD Operations Ian King Mike O’Callaghan MD Aircraft Services Group Stephen Henwood Group MD Customer Solutions & Support Tom Williams Group MD Programmes MD Airbus Jonathan Neale MD Hawk Alison Wood MD Future Systems Rebecca Elliott Ross Bradley MD Lancer MD Eurofighter * Executive Directors Tom Nicholson Cliff Duke Kevin Taylor Programmes Organisation MD Nimrod MD Aviation Services Rod Leggetter Group Procurement and IT Director Group MD Avionics MD Merger Integration George Rose* Group Communications Director Chris Geoghegan Alastair Imrie Group Legal Director MD Astute Chris Boardman MD Harrier, Tornado & US Military Aircraft Projects Nick Franks MD Gripen & South Africa Brian Phillipson Mark Kane MD Future Carrier MD Type 45 Group Finance Director

BAE SYSTEMS Capabilities • • • • Airbus Avionics Civil Aircraft Commercial Shipbuilding and Repair Customer Solutions and Support Defence Systems Land Naval Artillery Systems Military Aircraft Missiles Naval Vessels Prime Contracting Space Systems Integration Underwater Systems

BAE SYSTEMS MARINE ORGANISATION SITES CAPABILITIES PRODUCTS

BAE SYSTEMS Marine Site Locations Barrow-in-Furness, Cumbria Glasgow (Scotstoun and Govan)

BAE SYSTEMS Marine, Barrow Site · Modern facilities - Covered Construction Hall (DDH) - Syncro Lift - New Superberth · Designed for Submarine/Surface Ships · Only Nuclear Submarine Build Facility in the UK · Design and Construction Experience with Large Naval Ships · Unique First of Class Experience and System Design Capabilities · Operates Smart Procurement, Modular Build, Advanced Outfitting, Lean Manufacturing · Flexible, Highly Skilled Workforce · Large Engineering Design Resource · Large Site with Space for Development

BAE SYSTEMS Marine, Scotstoun Site • Specialist Frigate Production Facility • Surface Ship Exports • 3 Covered Berths • 3 Dry Docks • Good river frontage • Low cost base • Skilled labour force • Large resource pool • Site development proposed

BAE SYSTEMS Marine, Govan Site • Low cost base • Commercial Standards Simple ships built quickly • Hybrid Commercial/Naval Ship experience • Large Module Assembly Hall • Capable of building ships up to Panamax size (32 m beam) • Large steel production workforce accustomed to flexible working • Large resource pool • Large unconstrained leased site • Site development proposed

BAE SYSTEMS Upholder (Victoria) Class Submarines - Type SSK Four conventional Vanguard 2400 tonne Victorious diesel-electric Vigilant submarines built for the RN and currently being Vengeance refurbished and reactivated for service with the Canadian Navy as the Victoria Class.

BAE SYSTEMS Vanguard Class Submarines - Type SSBN Major 15 -year 4 -boat Vanguard Strategic Ballistic Nuclear. Victorious Submarine Vigilant Prime Contract/ Build. Vengeance Programme completed at Barrow in November 1999 Vanguard / Victorious / Vigilant / Vengeance

BAE SYSTEMS Astute Class Submarines - Type SSN Major 3 -boat 7200 tonne Fleet Nuclear Submarine Build Contract for the Astute Class Programme Organization and the Royal Navy. Fabrication of first submarine in progress at Barrow. Projected in-service dates for the three boats are between 2005 and 2008

BAE SYSTEMS Amphibious Assault Ship - Type LPD Two of these 18, 400 -ton vessels are currently in build at Barrow for the Royal Navy. Albion was launched on 9 th March 2001. Bulwark’s launch is scheduled for November 2001 Albion / Bulwark

BAE SYSTEMS Amphibious Helicopter Carrier - Type LPH 20, 000 -tonne carrier commissioned into UK RN service September 1998. Has already been on active service in several theatres of operation worldwide. HMS Ocean

BAE SYSTEMS Two 12000 -ton (27000 -tons fully laden) fleet oilers currently in build at Barrow and Govan, for the Royal Fleet Auxiliary. Wave Knight launched 29 th September 2000. Wave Ruler launched 9 th February 2001. Wave Knight / Wave Ruler

BAE SYSTEMS Type 23 Frigates HMS Kent was delivered in February 2000 and HMS Portland in 2001. The last Royal Navy Type 23 Class Frigate St Albans is now being outfitted at Scotstoun. Norfolk / Argyll / Lancaster / Iron Duke / Monmouth / Montrose / Somerset / Grafton / Sutherland / Kent / Portland / St Albans

BAE SYSTEMS Brunei Offshore Patrol Vessel A three-vessel prime contract including design, build and support. First vessel launched in January 2001

BAE SYSTEMS Malaysian Frigate Both vessels commissioned. In-service support contract under negotiation. KD Jebat / KD Lekiu

BAE SYSTEMS Anti Air Warfare Type 45 Destroyer (AAWD) Current IPT involvement and projected RN first of class build at Scotstoun. Potential for eleven further vessels BAE SYSTEMS holds the Prime Contract for the first three vessels. The Type 45 s are planned to enter service between 2007 and 2014. BAE SYSTEMS Marine has submitted an unsolicited bid to build all 12 Type 45 destroyers.

BAE SYSTEMS Commercial Shipbuilding and Repair 3 Clean Products Tankers Build Programme completed at Barrow 1997/8 Work undertaken on two Super Seacat Ferries in Dry Dock Facilities at Scotstoun during 2000. Govan is building a 75 m Anchor Handler Tug Supply (AHTS) vessel and bow fabrications for a second similar vessel during 2001. Thames Fisher / Humber Fisher / Mersey Fisher Anchor Handler Tug Supply (AHTS) vessel
