AYDIN TORNA SAN VE TIC LTD STI ESTABLISH

AYDIN TORNA SAN. VE TIC. LTD. STI.

ESTABLISH AND PRESENTATION

AYDIN TORNA SAN. VE TIC. LTD. STI, AYDIN TORNA IS SPECIFIED FOR (CNC) MACHINING AND WAS FOUNDED IN 1983 FOR THIS PURPOSE BY MUZAFFER AYDINLI

AYDIN TORNA ORGANISATION

IN OUR FIRM: 6 Management Personel, 2 Export/ Import Responsible, 2 Machine Engineers, 5 Qualityleader, 1 Production Chief, 26 CNC operator, 2 office employee Total: 44 People are employed

AYDIN TORNA produces preworked and ready-worked products for the • AUTOMOTIVE INDUSTRY • DEFENCE INDUSTRY • HEAVY METAL INDUSTRY and for all kinds of industries. This products made by casting, forging and stripe material by machining process. These are sold in the own and world market.

OUR FIRM CATCH THE FAST DEVELOPMENT OF MACHINING INDUSTRY BY THE FOLLOWING TOOLS: • • • CNC LATHES , CNC VERTICAL MACHINING CENTERS, CNC HORIZONTAL MACHINING CENTERS, CNC BOHRWERK 3 D COORDINATE MEASURING MACHINE AND • IN 2005 GOT THE ISO 9001: 2000 QUALITY MANAGEMENT SYSTEM CERTIFICATE

BOHRWERK-FEMCO BMC 110 HORIZONTAL MACHINING CENTER, ROTARY TABLE=360º 5 AXIS, TABLE SIZE: 1440 x 1600 mm, TABLE LOAD: 6300 kg MAX X AXIS TRAVEL: 3000 mm MAX Y AXIS TRAVEL: 1700 mm MAX Z AXIS TRAVEL: 1800 mm

MORI SEIKI NH 5000 DCG HORIZONTAL MACHINING CENTER TWO PALLETS + ROTARY TABLE=360º, TABLE LOAD: 1000 kg, SPECIFICATIONS: MAX X AXIS TRAVEL: 730 mm MAX Y AXIS TRAVEL: 730 mm MAX Z AXIS TRAVEL: 850 mm

(2 x) MORI SEIKI NH 4000 DCG HORIZONTAL MACHINING CENTER TWO PALLETS+ROTARY TABLE=360º, TABLE LOAD: 1000 kg, SPECIFICATIONS: MAX X AXIS TRAVEL: 560 mm MAX Y AXIS TRAVEL: 560 mm MAX Z AXIS TRAVEL: 630 mm

GOODWAY-GS 400 L-Model 2008 CNC LATHE -Max. Turning Diameter : Ø 610 mm -Max. Turning Length : 1190 mm. -Max. Swing Diameter : Ø 740 mm. - Turning Chuck : 15” -Spindle Bar Capacity : Ø 115 mm. - Programmable Base and Quill Hydraulic Tailstock Capacity : Ø 50 -Ø 200 mm.

FEELER FV-1000 VERTICAL MACHINING CENTER, 3 AXIS, SPECIFICATIONS: MAX X AXIS TRAVEL: 1000 mm MAX Y AXIS TRAVEL: 500 mm MAX Z AXIS TRAVEL: 500 mm

HUEYLONG VMC-1270 STARWAY VMC-1270 VERTICAL MACHINING CENTER, 4 AXIS, ROTARY TABLE=360º SPECIFICATIONS: MAX X AXIS TRAVEL: 1200 mm MAX Y AXIS TRAVEL: 700 mm MAX Z AXIS TRAVEL: 700 mm

ALEX-TECH ANL-52 T CNC LATHE, 2 AXIS, SPECIFICATIONS: MAX TURNING DIAMETER : Ø 420 mm MAX TURNING LENGHT: 600 mm

VICTOR-V TURN 20 CNC LATHE, 2 AXIS, SPECIFICATION: MAX TURNING DIAMETER : Ø 250 mm MAX TURNING LENGHT : 700 mm

TAKANG –TNC 30 -NL CNC LATHE, 2 AXIS, SPECIFICATION: MAX X AXIS TRAVEL: Ø 450 mm MAX Z AXIS TRAVEL: 1090 mm

GOODWAY –TNC 30 L CNC LATHE, 2 AXIS, SPECIFICATION: MAX X AXIS TRAVEL : Ø 360 mm MAX Z AXIS TRAVEL : 700 mm

CMM MITUTOYO CRYST APEX C 574 3 D COORDINATE MEASURING MACHINE MEASURE RANGE: X: Y: Z=500: 700: 400 MEASURE SENSITIVITY: E=(3, 5+0, 451/100) μm

► MOTOR CARRIER ► DIFFERANTIAL CARRIER ► GEARBOX CARRIER ► ELEVATOR BRAKE DISC ► HELICOPTER PARTS ► FEATHER CARRIER ► GEAR BOX ► CONNECTING ROD

GOALS FOR NEXT TWO YEARS

• MOVING TO ESKIŞEHIR ORGANIZED INDUSTRIAL DISTRICT • MAKING NEW LATHES AND EQUIPMENT INVESTMENTS

• TO INCREASE THE CUSTOMER TYPES BY THE NEW CUSTOMER CONNECTION AND INCREASE THE EXPORT ON 60% • TO GET ISO 14001 “ENVIRONMENT MANAGEMENT SYSTEM”

OUR CERTIFICATES AND DOCUMENTS

ISO 9001: 2000 QUALITY MANAGEMENT SYSTEM CERTIFICATE

TAI-TURKISH Aerospace Industries SUPPLIER QUALITY SYSTEM APPROVAL CERTIFICATE

OUR REFERENCES

CONNECTION: www. aydintorna. com TELEPHONE NUMBERS: (+90) 0222 228 13 24 -25 -26 FAX: (+90) 0222 228 13 22 Address: Eskişehir Org. San. Böl. Tornacılar San. Sit. A Blok No: 5/6/7/8 ESKISEHIR / TURKEY
