AXIAL SKELETON SKULL TUTORIAL Anterior Skull frontal bone
AXIAL SKELETON SKULL TUTORIAL
Anterior Skull frontal bone supraorbital foramen zygomatic bone mandibular symphysis mental foramen glabella Supraorbital ridge infraorbital foramen maxillary bone alveolar fossa mandible
Anterior Skull nasal bone perpendicular plate orbital fissure inferior nasal concha middle nasal concha vomer bone
Paranasal Sinuses frontal sinus ethmoid sinus maxilary sinus sphenoid sinus
Cranium frontal bone coronal suture sagittal suture parietal bone lambdoidal suture occipital bone
Ventral Skull palatine process vomer bone sphenoid bone palatine bone Lateral pterygoid plate Medial pterygoid plate styloid process temporal bone mastoid process external occipital protuberance occipital bone
carotid canal jugular foramen occipital condyle foramen magnum Occipital bone
squamosal suture lacrimal bone temporal bone external acoustic meatus mandibular condyle In mandibular fossa (TMJ joint) Lateral Skull
Temporal process of zygomatic bone sphenoid bone zygomatic arch coronoid process Zygomatic process of temporal bone sutural bone Mandibular notch mastoid process styloid process ramus angle body mandible Lateral Skull
Frontal bone Ethmoid bone Sphenoid bone Temporal bone Occipital bone Internal Skull
cribriform plate crista galli lesser wing greater wing optic canal sella turcica intenal acoustic meatus jugular foramen Internal Skull
Hyoid + external acoustic meatus Hyoid bone temporal mandibular joint
