At OOLab our mission is to provide our

At OOLab our mission is to provide our clients with customized 3 D digital technology and solutions: Equipment, software, services and training…

A partner of world-class standing A client portfolio that includes major international concerns involved in the following fields: Aerospace Automotive Biomechanics Consumer products Education Manufacturing Multimedia Heritage preservation & Architecture

The developer of the footprint 3 DTM Scanner • The first and only self-positioning and truly portable laser scanners • A diversified line-up of products to meet your specific needs • A worldwide distribution network

footprint 3 D™ • Self-positioning: No need for an external positioning or tracking system; complete freedom of movement • Ease of use: Quick learning curve; 3 D rendering in real time; easy and user-friendly • Cost-effectiveness: Small investment, requiring no equipment or additional devices; low maintenance costs, fast installation • Portability: Easy to store in a small case the size of a carry-on • Versatility: Easy to use in tight spaces; scanning of parts in any size, color, or texture

Our scanning method • The scanner calculates its position by triangulation • Uses positioning targets, applied randomly on the part to scan • No need for an external tracking or positioning device!

Accuracy and precision • • 3 D scanning of existing objects 3 D archiving Complex shape acquisition Measurements archiving Damage assessment Digital models and mock-ups Packaging design Rapid prototyping

True automatic multiresolution • The new Decimate Triangles slider makes it possible to: • Keep a higher resolution when needed • Keep larger triangles on flat surfaces • Produce lighter STL files

Footprint • Specifically developed for medical applications • • • Innovative Self-positioning Handheld Powerful Accurate Truly portable

Applications & Solutions

Footprint Orthotics/Prosthetics • Custom-making of artificial limbs or body part replacements • The limb to be fitted is scanned, and the data acquired is transferred into CAD applications for: • Design • Measurement • Rectification • Retrofit • Production • Loaded/unloaded 3 D digital impressions (foot imprints)

Footprint Cranial scans • Treatment of positional plagiocephaly in infants • Non contact and quick measurement of the skull for digital manufacturing of soft shell therapeutic helmets • Follow-up on the treatment

Footprint Plastic/aesthetic surgery • 3 D scanning of body parts • Ears • Hands • Feet • Nose • Breast to produce a perfectly fitted and exact match prosthesis or reconstruction

Footprint Podiatrics • 3 D scanning of the feet/toes/ankles for manufacturing of customized podiatric orthesis or apparel

Footprint Wound care • Non contact and painless 3 D scanning of wounds for treatment and follow-up purposes • For example, depth and length measurement at different stages of the healing process

Benefits

Footprint Laser-accurate measurement • The shape acquired is very accurate and constant

Footprint Totally eye-safe laser • Our class I laser guarantees patients’ and technicians’ absolute eyes safety

Footprint Quick file transfer • The system generates direct 3 D files that can be electronically transferred in seconds Quick data acquisition • Scanning sessions are short, which reduces the consultation duration and makes it possible to see more patients

Footprint Non sensitive to slight movement • Even with slight movements from the patient, the system is able to pursue the data acquisition without any loss in accuracy

Footprint User-friendly • The session can be paused and resumed if necessary • Very short learning curve; no extensive training required

Footprint Non invasive • Non contact scanning process, thus reducing the trauma and discomfort of patients

Footprint Truly portable and lightweight • Fits in a suitcase the size of a carry-on • Can be carried effortlessly from: • One room to the other • One facility to the other • Directly to the patient’s home

Footprint 3 D archiving • The system generates 3 D files that can be archived in electronic medical record databases • No more heavy casts and moulds to warehouse and organize! Recognized technology by third party health and regulatory Colleges

Footprint Clean • • Great alternative to traditional, laborious and messier casting methods No environmental waste

Technical Specifications

Footprint™ Technical Specifications Footprint™ Weight 980 grams (2. 1 lb) Dimensions 160 x 210 mm (6. 25 x 10. 2 x 8. 2 in) Measurements 18, 000 measures/s Laser Class Resolution in Z axis Accuracy Depth of field Class I (eye-safe) 0. 1 mm (0. 004 in) Up to 0. 5 mm (0. 002 in) 30 cm (12 in)

Accessories

Footprint Included • • Carrying case Calibration plate Footprintnomic support Fire. Wire cable PCMCIA connecting card Power supply 2, 500 reflective targets 1 -year warranty on parts and labour

Questions?

www. oolab. com
