ASTROFLEX S P A FLEXIBLE METAL HOSES 2017
ASTROFLEX S. P. A FLEXIBLE METAL HOSES © 2017 BY ASTROFLEX SPA
COMPANY Astroflex is a public company founded in 1991 the only production site is located in Collegno in the neighborhood of Turin. The warehouse of 7500 sqm is situated in own area of 12500 square meters. The social capital of € 3, 600, 000 fully paid. The workforce currently has 50 employees. © 2017 BY ASTROFLEX SPA
ACTIVITIES / PRODUCTION Astroflex carries within it the following activities: • Product Design • Design Tools and Equipment • Assembling Machinery • Production Products: • Flexible metal hoses • Compensators • Vibrations Absorbers • Special hoses according to the customer specifications © 2017 BY ASTROFLEX SPA
FLEXIBLE HOSE © 2017 BY ASTROFLEX SPA
COMPENSATORS © 2017 BY ASTROFLEX SPA
TURNOVER The turnover in 2017 was 6. 6 million euro divided into two main geographical areas: • Italy (50%) • Foreign (50%) © 2017 BY ASTROFLEX SPA
MARKET Astroflex is on the market in the following areas: • Domestic water connection (18%) • Gas pipes, domestic / industrial (15%) • Refrigeration (15%) • Automotive (18%) • High vacuum (22%) • Custom Pipes Industry (12%) © 2017 BY ASTROFLEX SPA
MAIN CUSTOMERS © 2017 BY ASTROFLEX SPA
RESEARCH & DEVELOPMENT Technical capabilities: • 3 Autocad Station • 1 Siemens NX Station 10 © 2017 BY ASTROFLEX SPA
LABORATORY The main instruments of our laboratory are: • Metallographic microscope • Stereoscopic Microscope • Borescope • Profilometer • Profile projector • Quantometer • Durometer • Micro-Durometer • Dynamometer • Coordinate Measuring Machine (CMM) © 2017 BY ASTROFLEX SPA
MACHINERY AND EQUIPMENT All production machines and test benches are designed, developed and assembled by ourself. The staff dedicated to these activities is composed by two engineers, two electronic technicians and three maintenance workers. This allows flexibility and responsiveness in the development of special products and samples. © 2017 BY ASTROFLEX SPA
Here the main machineries involved in the manufacturing process: • 2 tube welding lines • 8 Hydroforming machines • 2 Reductant atmosphere (H 2) Brazing Oven • Welding : • 6 lasers of 1 KW Power • 1 laser of 6 KW Power • 19 TIG Bench • 8 Plasma Bench © 2017 BY ASTROFLEX SPA
CERTIFICATIONS The Quality Management System of Astroflex has been certified in accordance with the technical specification ISO 9001: 2008 © 2017 BY ASTROFLEX SPA
Product certification relating to the European directive 97/23/EC concerning pressure equipment © 2017 BY ASTROFLEX SPA
Astroflex also provides product certifications in accordance with the specific rules of the most important European countries © 2017 BY ASTROFLEX SPA
CONTACTS ASTROFLEX S. P. A. Via Magenta 29 10093 -COLLEGNO (TORINO) ITALY TEL: +390114117026 FAX: +390114117029 Website: HTTP: //WWW. ASTROFLEX. IT Sales Representative: Carmine Attademo email: carmine. attademo@astroflex. it Quality Manager: Roberto Spalletti email: quad@astroflex. it Technical Manager: Sergio Castelli email: sergio. castelli@astroflex. it © 2017 BY ASTROFLEX SPA
