Aruba OS Virtual Appliance VM Requirements jihu sunhpe

MM Requirements SKUs Total v. CPU (hyper threaded) Memory (GB) Flash/Disk (GB) MM-VA-50 3 6 6 2 data ports (0/0/0, 0/0/1), 1 mgmt port MM-VA-500 6 8 8 2 data ports (0/0/0, 0/0/1), 1 mgmt port MM-VA-1 K 8 32 32 2 data ports (0/0/0, 0/0/1), 1 mgmt port MM-VA-5 K 10 64 64 2 data ports (0/0/0, 0/0/1), 1 mgmt port MM-VA-10 K 16 128 2 data ports (0/0/0, 0/0/1), 1 mgmt port 引用：Aruba. OS Virtual Appliance Installation Guide CONFIDENTIAL © Copyright. 2018 Aruba Networks, an HP company. All rights reserved. Total Supported Interfaces 11

VMC Requirements SKUs Total v. CPU (hyper threaded) Memory (GB) Flash/Disk (GB) Total Supported Interfaces MC-VA-10 3 4 6 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port MC-VA-50 4 6 6 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port MC-VA-250 5 8 8 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port MC-VA-1 K 6 16 16 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port MC-VA-4 K 12 48 48 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port MC-VA-6 K 14 64 64 3 data ports (0/0/0, 0/0/1, 0/0/2), 1 mgmt port 引用：Aruba. OS Virtual Appliance Installation Guide CONFIDENTIAL © Copyright. 2018 Aruba Networks, an HP company. All rights reserved. 22

Clear. Pass 6. 7/6. 8 VM Requirements SKUs Total v. CPU (hyper Memory Flash/Disk Passmark threaded) (GB) Score Total Supported Interfaces Functional IOP rating CLABV 2 6 80 C 1000 V 8 8 1000 ≥ 3000 2 Gigabit virtual switched ports 40 -60 read/write profile for 4 K random read/write = 75 C 2000 V 8 8 1000 ≥ 9600 2 Gigabit virtual switched ports 40 -60 read/write profile for 4 K random read/write = 105 24 64 1800 ≥ 9900 2 Gigabit virtual switched ports 40 -60 read/write profile for 4 K random read/write = 350 C 3000 V 引用： Tech_Note_Installing_Clear. Pass_6. 7_on_a_VM CONFIDENTIAL © Copyright. 2018 Aruba Networks, an HP company. All rights reserved. 33

Airwave 8. 2. 9 VM Requirements Managed Devices CPU Cores Memory (GB) Storage (GB) Passmark Score Recommended IOPS 750 Dual Intel Xeon CPU E 5 -2640 v 3 @ 2. 60 GHz or higher 8 48 500 9, 942 2, 132 1, 500 Dual Intel Xeon CPU E 5 -2640 v 3 @ 2. 60 GHz or higher 10 56 800 14, 057 2, 558 2, 500 Dual Intel Xeon CPU E 5 -2640 v 3 @ 2. 60 GHz or higher 16 96 1000 19, 892 2, 842 4, 000 Dual Intel Xeon CPU E 5 -2640 v 3 @ 2. 60 GHz or higher 20 1200 25, 116 3, 410 引用： Air. Wave 8. 2. 9 Server Sizing Guide CONFIDENTIAL © Copyright. 2018 Aruba Networks, an HP company. All rights reserved. 44

ALE VM Requirements Configuration Number of AP’s/Clients CPU Cores Memory (GB) Storage (GB) SMALL 500 / 8000 4 16 GB 160 GB MEDIUM 1, 000 / 16, 000 8 24 GB 320 GB LARGE 2, 000 / 32, 000 16 48 GB 1 TB – Notes on Server Sizing: • Maximum number of controllers per ALE instance = 4 • Maximum number of Air. Wave servers per ALE instance = 1 • Max number of APs per ALE instance = 2 K • Maximum number of clients per ALE instance = 32 K Client counts includes mix of associated and unassociated devices • Recommended Grid Size (Floor Plan in Air. Wave) = 10 x 10 ft （3 mx 3 m） CONFIDENTIAL © Copyright. 2018 Aruba Networks, an HP company. All rights reserved. 55
