Arlen Nipper President CTO Cirrus Link Solutions Big

Arlen Nipper President & CTO / Cirrus Link Solutions

Big Access: Unleashing the Real Value of Your IIOT Data (without Big Access you can’t realize Big Data) Arlen Nipper President & CTO / Cirrus Link Solutions

What is the difference between an embedded computer and a “Internet of Things” device? “ An embedded computer system is typically any microprocessor-based device that encapsulates a basic process knowledge. ” IT integration and communications connectivity is at best an effort in hindsight and at worst ignored altogether. “ Internet of Things provides technology and infrastructure to enable the process knowledge and associated parameters to be distributed within the enterprise … and beyond” IT integration and communications becomes a native capability of the system.

The Journey ICC 2015 Leveraging IIo. T Technology: Building for Tomorrow with Ignition and MQTT ICC 2016 Accelerate IIo. T Solution Deployment Using Ignition and MQTT ICC 2017 Big Access: Unleashing the Real Value of your IIo. T Data

The Sparkplug Specification Sparkplug is a specification that defines how to use MQTT in a mission critical, real time environment. Ø Defines MQTT Topic Namespace Ø Defines MQTT Payload Definition Ø Defines MQTT State Management Ø High Availability / Redundancy / Scale

Ecosystems for the Outcome Economy “For industrial businesses ecosystems are unavoidable. ” “They should first and foremost aim to create these as parts of viable networks of partners with the shared aim of developing new products and services targeted at outcome focused customers. ” Industry X. 0 Pages 243 -244

The Ecosystem

New Features • • Automatic tag history during network outages. Complex data type support (UDT’s, Datasets, Arrays, Files). Tag properties support. Redundant Ignition Gateway support. • • • Historical Data Inserts for Store & Forward Supports MQTT JSON connections Support New Sparkplug B Complex Data Types Compression & Tag Name Alias Support Redundant Ignition Gateway Support • • • Store & Forward Server Sets – Send data to multiple endpoints Compression & Tag Alias Name Support Custom Transmitters- Added Tag Tree Flexibility Redundant Ignition Gateway support

Big Access 1. 2. 3. 4. 5. 6. 7. Connect devices to infrastructure, NOT to applications. Secure, remote originated connections. Ultra efficient network bandwidth utilization. Send more data over the same bandwidth. Provide a “Single Source of Truth” for tags and associated properties. Demonstrate a superior OT solution. Provide Plug-and-Play functionality. Eliminate SCADA system “cutovers. ” Provide unlimited tags and unlimited clients. “The transformation to IIo. T will NOT be an IT-down-to-OT exercise. It will require empowering OT with the tools and technology to execute an OT-to-IT migration. “

The World Today! • We live in a brownfield environment • Assets and devices already deployed will be there for the next decade or even longer. • ROI’s rarely provide the rip and replace scenario Therefore, we MUST demonstrate migration technologies that mitigates risk and provide operational integrity, safety, and security of the system as a whole throughout the migration process.

The Power of the Ignition Platform To migrate the brownfield world driving the business requirements, a “Swiss Army Knife” of tools is essential and Ignition is much, much more than HMI / SCADA… • • • MQTT to OPC-UA Bridge OT to IT Bridge MES & OEE Out at the Edge with Reporting & Alarming Cloud Connectivity

Big Access to Big Data: Enable Ignition Connections to Cloud Services These new Injector modules easily connect any tag data from the Ignition platform into the Amazon Web Services (AWS) and/or Microsoft Azure cloud services infrastructure. With a simple configuration, tag data will flow into the AWS or Azure cloud Big Data services. • • • Connects to any TAG Data Easy to Configure Same efficient tag reporting scheme as used in MQTT Transmission For use on Gateway or Edge Supports Store & Forward – Coming Soon!

AWS Injector Amazon Web Services Serving Tier Operational Data Science Sandbox Amazon Elasti. Cache Redis Amazon Aurora Amazon Athena Relational Database Clusterless SQL Query Amazon Data. Redshift Warehouse Amazon Dynamo. DB No. SQL Database s Data Sources ic lyt Amazon Kinesis Streams & Firehose h tc a An Ba St Any Open Source in Tool of Choice on g/ EC 2 Re al -ti m e An al yt ic s Amazon S 3 Data Lake re am Amazon Glue Clusterless ETL Amazon EMR Amazon Machine Learning Hadoop / Spark Predictive Analytics Streaming Analytics Tools Amazon Elasticsearch Service Spark Streaming on EMR AWS Lambda Amazon Kinesis Analytics Apache Flink on EMR Apache Storm on EMR Visualization / Reporting

Azure Injector Communication Transformation Operational Data Storage Azure SQL Database Stream Analytics Azure IOT HUB Analytics Azure SQL Data Warehouse Visualization Web App Document. DB Storage Blob HDInsight Data Factory Storage Table Data Lake Machine Learning Cortana

Unleashing The REAL Value of Big Data The Power of Big Data, Predictive Analytics & AI • • • Gain insight needed to deliver intelligent actions Increase Revenue Lower Costs Improve Safety Increase Productivity We understand the Why? With Ignition and Cirrus Link, you have to the tools to Deliver!

Legacy SCADA Azure Io. T Hub OPC Big Access to Big Data to Real Value Kinesis Dynamo. DB MQTT Server Infrastructure TLS Leak Detection MES OEE Track Trace Ethernet VSAT ACL Cellular DMZ

Call to Action • • Download Experiment Demo – Brownfield to Cloud in 30 minutes Expose End Users and Line of Business Owners • Implement Real IIo. T – Real Value – Available NOW!!

Questions?

Thank You
