AnNajah National University Faculty of Engineering Building Engineering
An-Najah National University Faculty of Engineering Building Engineering Department Graduation Project 2 Villa Prepared By Abdalla Naem Dwikat Project supervisor: DR. Monther Dwikat :
Outline: ü Project Definition ü Architectural Design ü Environmental Design. ü Structural Design ü Electrical Design ü Mechanical Design ü Safety Design
Site of the project: Location and Site: my project located in sarra, sarra Located to the southwest of the city of Nablus
Architectural Design
Site Plan :
Ground Floor (Area = 200 square meter)
First Floor (Area = 200 square meter)
North Elevation:
South Elevation:
East Elevation:
West Elevation:
Sections 1 :
Sections 2 :
Environmental design
ü Thermal Comfort ü Heating and cooling load ü water efficiency ü Natural Lighting ü Shading ü Acoustics Comfort
Thermal Comfort : external wall layer's
Total Heating and Cooling Load we use split unit for heating and cooling
water efficiency: we separate the gray and black water
Natural Lighting
day light factor in the fig we can see the daylight factor in a gust bed room in the ground floor and we can see that the average value is 4. 29% and that is good daylight factor and the distribution of the daylight is very good.
Shading
Shutters Design with 25 cm
Acoustics Comfort
Acoustics design for bed room Area* Wall 42 0. 3 12. 6 Ceiling 27 0. 04 1. 08 Floor 21 0. 03 0. 64 Door 2. 25 0. 05 0. 1125 Window 4. 75 0. 04 0. 19 wood 1. 9 0. 07 0. 133 curtains 4. 12 0. 58 7. 192 Bed 3. 22 0. 30 0. 93 Total 114. 52 a average = 0. 19996 accepted. 22. 9 RT 60= 0. 80013 , it is
STC Value: 52 db external wall 47 db internal wall
Structural Design
Model (concrete frame ) 2 floor , All floor one way ribbed slab Compatibility , equilibrium Internal forces : ok
(concrete frame ) : slab design 25 cm one way ribbed slab L. L = 3 KN/ m^2 Super D. L = 4 KN / m^2
(concrete frame ) : beams, columns design beam b*h Column b *h b 1 700*500 b 2 600*300 C 1 600*300 b 3 500*500 C 2 500*300 b 4 400*500 C 3 400*300
(concrete frame ) : beam details
(concrete frame ) : Footing Layout Bearing capacity of soil = 300 KN/ m^2
(concrete frame ) : Footing Details
(concrete frame ) : shear wall Details
Electrical Design
Lighting design (artificial lighting ) : Luminaries Data we used fluorescent lamps because of its ability to save power and they have long life cycle.
Lighting design (artificial lighting ) : Lighting Distribution to the ground floor
Lighting design (artificial lighting ) : socket Distribution to the ground floor
Lighting design (artificial lighting ) : switch Distribution to the ground floor
Power design : Circuit Breaker Plans Total load = 4 kw Total current = 5. 93 Am Total load = 3. 1 kw Total current = 5. 48 Am
Mechanical Design
ü Water Supply System ü Drainage system ü AC System ü Fire Place System ü Fire System ü Elevators System
Roof water Supply System:
Water supply system:
Draneg System:
Manhole system:
AC System:
Fire Place system:
FIRE SYSTEM: WE USE FIRE EXTINGUISHER
Elevators System
