애니모션텍 주식회사 ANI MOTION TECH LTD Confidential DEEP DRILLING TEST 광학 공정팀 위창현 The key to success, Animotion Tech contribute not only to laser and robot system but also success vision through business consultation and the whole heart companionship.
애니모션텍 주식회사 ANI TEST. ANI MOTION TECH LTD Confidential TEST. S 1000 FEED. = 10 ㎜/s, 2000 ㎐, 5 µm 간격, 0. 1 W, 50 µJ, 45 회 반복 가공 TACT TIME : 27. 6 sec, ( 1. 1 sec / hole)
S 1000 5 X 5 ARRAY SAMPLE 가공 위치 애니모션텍 주식회사 ANI ANI MOTION TECH LTD Confidential
애니모션텍 주식회사 ANI TEST. 결과 (S-1000) ANI MOTION TECH LTD Confidential 6. 9 µm 7. 4 µm X 20 38. 1 µm 15. 8 µm 14. 1 µm 30. 3 µm THICKNESS : 0. 46 ㎜ , TAPER : 89. 7 ° ( TOP 면 가공 )
애니모션텍 주식회사 ANI TEST. 결과 (S-1000) ANI MOTION TECH LTD Confidential 4 µm 7. 7 µm X 20 37. 2 µm 6. 7 µm 8. 9 µm 37. 1 µm THICKNESS : 0. 46 ㎜ , TAPER : 90 ° ( TOP, BOTTOM 면 양면 가공 )
