ANATOMY OF A NETWORK CLOUD Amy Wheelus ATT
- Slides: 21
ANATOMY OF A NETWORK CLOUD Amy Wheelus – AT&T Ryan van Wyk – AT&T Andrew Leasck – AT&T ENTER THE TITLE OF YOUR OPENSTACK P R EOpen. Stack S E N TSummit ATION 5/22/2018 Vancouver, Canada
AGENDA Security PATH TO THE NETWORK CLOUD DESIGN DELIVERY 2 Containerizati on Quality WHAT’S NEXT © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
Security PATH TO THE NETWORK CLOUD DESIGN DELIVERY 3 Containerizati on Quality WHAT’S NEXT © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
BUSINESS DRIVERS FOR THE NETWORK CLOUD FIRSTN ET BUSINESS COLLABORA TION INTELLIGEN T EDGE 4 Security Containerizati on Quality 5 G v. EP C CRICKE T WIRELE SS © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
PATH TO THE NETWORK CLOUD 2014 – 2016 | CONVERGE 2017 | AND DEPLOY ENHANCE AIC 1. 0 – AIC 2. 5 • • 5 Common Platform Architecture Structured Agile Development Single Unified Code Base Global, automated AIC Zone Deployments AIC 3. 0 • AIC Flavor Series • Fault Tolerance, Normalization, Resiliency • Matured Security Containerizati on Quality 2018+ | EVOLVE NC 1. 0 • Container Based Resiliency • “Lego” Blocked Infrastructure • Scalable Footprint • High Performance Focused • ONAP Orchestrated © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
ONAP: THE AT&T STORY THE ROAD TO ONAP AT&T Software Defined Networking ECOMP OPEN SOURCE 8. 5 Million Lines of Code 6 OPEN SOURCE PLATFORM 1 ECOMP OPEN SOURCE PLATFORM 2 Security Containerizati on Quality Rapidly onboard new services Enables the creation of a new ecosystem of cloud consumer and enterprise services Reduces capital and operational expenditures Provides operational efficiencies ONAP 900+ contributors 50+ members – 30+ projects Allows the customer in near realtime to reconfigure their network, services, and capacity © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
Security PATH TO THE NETWORK CLOUD DESIGN DELIVERY 7 Containerizati on Quality WHAT’S NEXT © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
NETWORK CLOUD DESIGN CRITERIA Security SPEED Fast Deployments & Upgrades • • • Major upgrade days to hours • Minor upgrades 1 day to minutes Eliminates control plane dependency on high cost external storage Flexible, Fine-Grain Scaling • Upgrades with no impact to running tenant workloads* • Enabler of feature continuous delivery SW Delivery Automation (CI/CD) • Lower VM Cost Significantly reduce control plane hosts Enable Seamless Upgrades • COST • SW deploy weeks to < day Self contained control plane & deployable on a dev laptop Automated, homogenous deployments from dev to prod with zero drift *Note: HW pinning and OS upgrades mayconfig cause short Containerizati on • Granular control of scaling by component • Scale site 1 control plane host at a time • Service right sizing to site needs Reuse Extreme • • • One platform from DC to edge Single operations interface Standard APIs for tenants & ONAP Quality QUALITY Born in a Strong, Open Community • Collaborative Innovation from diverse thought leaders • Supported by leading companies in computing and Designed for Ops Excellence networking • Predictable process for all SW changes • • • Greater control Higher resiliency Greater visibility Evolves Control Plane Security • • Additional control Greater visibility interruptions 8 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
AIRSHIP | A NEW OPEN INFRASTRUCTURE PROJECT FOR O P E N|SWhat T A C&KWhy: Airship Architecture: What The focus is a declarative platform to introduce Open. Stack on Kubernetes (OOK), and the lifecycle mgmt. of the resulting cloud, with the scale, speed, resiliency, flexibility & operational predictability demanded Why of Network Clouds. DECLARATIVE CONTAINER BASED Sites are declared using YAML, including both hard assets & soft assets. You manage the document and Airship implements it. ONE WORKFLOW Containers are the unit of software delivery for Airship. This allows progress from dev, to testing, and production with confidence. ARCHITECTURALLY FLEXIBLE One workflow that handles both initial deployments and future site updates with virtually no difference in interacting with the two Airship to manages our entire cloud platform, not just Open. Stack including small and large environments with multiple configurations Airship Sub-Projects Treasure Map Shipyard Berth Drydock Promenade Divingbell Pegleg Deckhand Armada More info: http: //www. airshipit. org 9 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
AIRSHIP-AN UNDERCLOUD PLATFORM ENABLING THE NETWORK CLOUD Security Ranger Barbican Heat Cloud Platform Monitoring & Alerting Open. Stack-Helm (OSH) Ceph Calico Divingbe ll Drydock Shipyard Deckhan d OCI Compliant Container Runtime | Kubelet Host OS Baremetal 10 Promena de Berth Underclou d Platform (UCP) Runtime End to End CI/CD Logging Cinder Neutron Nova Horizon Glance Swift VNF SDN Controller Armada Helm Kubernetes Security & Operations Keystone ONAP Containerizati on Quality The blue highlights the Airship projects that facilitate the creation and life-cycle management of an undercloud platform that is used to enable a Open. Stack based Network Cloud with the scale, speed, flexibility and operational predictability this infrastructure must deliver. The green highlights the Open Source projects that Airship leverages/ integrates with to deploy the undercloud platform. © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
Security PATH TO THE NETWORK CLOUD DESIGN DELIVERY 11 Containerizati on Quality WHAT’S NEXT © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
HOW TO BUILD THE NETWORK CLOUD Security Containerizati on Quality Simplicity Predictability Quality 12 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
SIMPLICITY Containerizati on Security Kubernetes Helm Airship Quality Keystone Barbican Open. Stack. Helm Multiple, best in class, opensource projects converged Shift from Imperative to declarative Shift to API layer over engines Utilize Open. Stack standalone components 13 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
PREDICTABILITY Containerizati on Security Quality … Infra Testing VNF Testing Tempest Full Testing Executed Site deploy Artifact Repository Publish Site definition Publish Merge Airship Assembled Ephemeral Deploy Containerize Clone GIT Syntax Check Bandit Unit Test Coverage Containers Built Provision Genesis Node Gerrithub. i o • Enhance developer experience by deploying a reference architecture on a single machine, increasing efficiency • Pipelines continuously run across all services, driving predictable delivery • No-touch deployment from point of merging, to posting docker images and deploying full integration labs • Continuous deployment identifies issues early in process, through quality gating in Jenkins pipeline via AQu. A testing 14 • Everything deployed is 100% containerized – common infrastructure is utilized from Jenkins to Artifactory © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners. • Bottom line: Pipeline is zero touch and human interaction eliminated from deployment process
QUALITY Containerizati on Security Quality AIC Quality Automation (AQu. A) An extensible test framework, spanning various dimensions of the delivery lifecycle required to have confidence in delivering a stable platform. AQu. A seeks to establish consistent and continuous testing across our organization. AQu. A Framework Components Principles behind AQu. A Unit testing Leverage sanctioned open source test frameworks Extend/Contribute to those frameworks Integrated as quality gates in CI/CD pipeline CSO-compliant testing and certification mechanisms Ensure that each execution cleans up its resources Call and assert meaningful results from APIs Provide Development toolset/documentation Code Quality Analysis API Testing Resource Testing Dashboard Command Line Interface (CLI) Testing Graphic User Interface (GUI) Testing Infrastructure Testing In Use Beta POC Ideatio n Security Performance Resiliency 15 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
Security PATH TO THE NETWORK CLOUD DESIGN DELIVERY 16 Containerizati on Quality WHAT’S NEXT © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
WHAT’S NEXT NC Beta for 5 G (In Process) Security NC 1. 0 (Q 4) 5 G Market Launch (Q 4) Containerizati on Quality Airship Milestones AT&T Summit Sessions (Airship / Helm) 1. Airship: A New Open Infrastructure Project for Open. Stack 2. Open. Stack-Helm Hands-on Workshop: Deploy & Upgrade Open. Stack on Kubernetes 3. Open. Stack-Helm Project Update 4. Effective Kubernetes Helm Engineering: Open Stack-Helm Lessons Learned 5. AT&T Integrated Cloud - Transition from Virtualized to Containerized Control Plan CI/CD 6. The Open. Stack and Kubernetes Smorrebrod (Open Sandwich) 7. Telco Cloud Next Generation Stack Update: What's Changed with Open. Stack-Helm and Open. Contrail-Helm 17 © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
Appendix
THE AIRSHIP SUB PROJECTS Security Containerizati on Treasure Map: Divingbell: is the documentation project that outlines a reference architecture for automated cloud provisioning and management, leveraging the Airship interoperable opensource tools. is a lightweight solution for 1) Bare metal configuration management for a few very targeted use cases and 2) Bare metal package manager orchestration Shipyard: is the directed acyclic graph controller for Kubernetes and Open. Stack control plane life cycle management, and a component of the Undercloud Platform (UCP). Drydock: is a python REST orchestrator to translate a YAML host topology to a provisioned set of hosts and provide a set of postprovisioning instructions. 20 Quality Deckhand: is a storage service for YAML-based configuration documents, which are managed through version control and automatically validated. Deckhand provides users with a variety of different document types that describe complex configurations using the features listed below. © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners.
THE AIRSHIP SUB PROJECTS Armada: is a tool for managing multiple Helm charts with dependencies by centralizing all configurations in a single Armada YAML and providing life-cycle hooks for all Helm releases. Note: Armada is an enhancement to the helm client. Still using the helm tiller service, we deploy multiple charts with data-driven yamls. Promenade: is a tool for bootstrapping a resilient Kubernetes cluster and managing its life-cycle via Helm charts. Berth: is a deliberately minimalist VM runner for Kubernetes. Pegleg: Security Containerizati on Quality Open Source Projects that Airship Leverages/Integrates with: Open. Stack-Helm: is a Open. Stack project to provide a collection of Helm charts that simply, resiliently, and flexibly deploy Open. Stack and related services on Kubernetes Helm: is a tool for managing Kubernetes charts. Charts are packages of pre-configured Kubernetes resources. Kubernetes (K 8 s): is a open-source platform for managing containerized workloads and services, that facilitates both declarative configuration and automation. document aggregator providing early linting © 2018 AT&T Intellectual Property. All Rights Reserved. AT&T, the Globe logo, Mobilizing Your World and Direc. TV are registered trademarks and service marks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks are the property of their respective owners. and validations via Deckhand for documents 21
