ALUMINIUM DOORS WINDOWS Comprehensive range of products Aluminium

ALUMINIUM DOORS & WINDOWS

Comprehensive range of products – Aluminium Glazing Systems

Comprehensive range of products – Kawneer Aluminium Systems BIFOLD DOORS PATIO DOORS ENTRANCE DOORS FRENCH DOORS WINDOWS

Kawneer Aluminium - Bifold Door Features § § § Industry leading weather resistance Thermally broken aluminium bifold door system From 1 to 7 panels in various configurations Slim sightlines, no floating mullions Inward or outward opening Standard fully weathered threshold 45 mm § Low threshold option (24 mm) Multipoint locking system to master door 3 star diamond security rated cylinder with Kitemark § PAS 24: 2016 enhanced security available Discreet lever handle to intermediate doors 7 colour options from stock § Black anodised finish available Chamfered 28 mm glazing bead as standard § 28 mm, 32 mm & 44 mm square bead options: 36 mm chamfered bead option Sits on 95 mm, 150 mm and 174 mm cills

Kawneer Aluminium - Bifold Door Colour options 7 colours from stock with a 2 week lead time : Single colours § Black, White, Anthracite Grey, Textured Slate Grey, Light Grey Dual colours § Black out/White in and Anthracite Grey out/White in § Marine Grade Black Anodised finish available

Kawneer Aluminium - Bifold Door Furniture colour options • Master handles with design exclusive to KAT. Available in White, Grey, Black, Chrome, Gold and Brushed Steel • Master handles carry a 10 year guarantee • Locking intermediate lever handle available in White, Black, Chrome and Brushed Steel finish.

Kawneer Aluminium - Bifold Door configurations

Kawneer Aluminium - Bifold Door Size limits Maximum Minimum Height 2930 mm depends on width 1930 mm Overall width 10000 mm 1500 mm based on 2 panels Panel width 1200 mm 700 mm Weight per panel 120 Kgs For doors greater than 6. 4 metres, outerframe will be provided as a mechanically jointed kit

Kawneer Aluminium - Bifold Door Mechanical joint option § Doors are fabricated and fully assembled as standard § Outer frames can be supplied mechanically jointed as an option § Outer frames will be supplied in kit form for doors greater than 6. 4 m in width or 2. 2 m in height § Full installation instructions available

Kawneer Aluminium - Bifold Door Bifold detail Rebated head/jamb Corner post (option) 28 mm Chamfered bead Door sash/vent

Kawneer Aluminium - Bifold Door Frame edge detail § 72 mm edge detail § Universal coupler & range of ancillaries § 45 mm fully weathered threshold § 24 mm low threshold option (not severe weather rated) 15 mm coupler

Kawneer Aluminium - Bifold Door Threshold Options Standard threshold (with full weather rating) Low threshold (not severe weather rated)

Kawneer Aluminium - Bifold Door Cill Options 95 150 174 § 95 mm, 150 mm and 175 mm cills

Kawneer Aluminium – Bifold Door Hardware § Sobinco hook lock to the master door – 5 point locking § Stainless steel track § Rollers designed to take 120 Kgs per sash § Magnetic door catches § Lockable lever handle on intermediate door § Doors with slave leaf operated with finger bolts § PAS 24: 2016 enhanced security available Magnetic door catches Intermediate handle

Kawneer Aluminium - Bifold Door Weather rating § Low U Value – with DGU of 1. 0 centre pane value, full door indicative U Value of 1. 4 W/m²K° § U Value of 1. 0 W/m²K° achievable with 0. 5 W/m²K° triple glazed unit § Leading the industry for weather rating § Air Class 3 600 Pascals § Wind Class A 5 1600 Pascals § Water Class E 750 Pascals

Kawneer Aluminium Bifold Door U Values Part L 1 B/L 2 B OPEN IN OR OPEN OUT FSD Panel Variant Glass U Value (W/m²K) 2 Panel 3 Panel 4 Panel 5 Panel 6 Panel 1. 2 1. 54 1. 52 1. 51 1. 50 1. 1 1. 47 1. 44 1. 43 1. 0 1. 40 1. 37 1. 36 1. 35 0. 9 1. 32 1. 29 1. 28 0. 8 1. 25 1. 22 1. 21 1. 20 0. 7 1. 18 1. 15 1. 14 1. 13 1. 12 0. 5 1. 03 1. 0 0. 99 0. 98 0. 97 Door U Value

Kawneer Aluminium - Bifold Door Summary § § § Industry leading weather resistance Thermally broken aluminium bifold door system From 1 to 7 panels in various configurations Slim sightlines, no floating mullions Inward or outward opening Standard fully weathered threshold 45 mm § Low threshold option (24 mm) Multipoint locking system to master door 3 star diamond security rated cylinder with Kitemark § PAS 24: 2016 enhanced security available Discreet lever handle to intermediate doors 7 colour options from stock § Black anodised finish available Chamfered 28 mm glazing bead as standard § 28 mm, 32 mm & 44 mm square bead options: 36 mm chamfered bead option Sits on 95 mm, 150 mm and 174 mm cills

Kawneer Aluminium– Inline Sliding Patio Doors Features § § § Industry leading weather resistance Choose from 7 colours, including dual colours Black Anodised finish available 400 mm cranked bar handle in brushed steel Pentalock 5 point enhanced security lock Twin track - 2, 3 or 4 pane options Triple track - 3 or 6 pane options Adjustable tandem rollers to ensure sashes run smoothly Stainless steel wheels and tracks 87 mm meeting style 28 mm, 32 mm or 36 mm glazing 10 year guarantee

Kawneer Aluminium– Inline Sliding Patio Doors Options § PAS 24: 2016 enhanced security § 1, 000 mm cranked bar handle in brushed steel to inside § 400 mm or 1, 000 mm cranked bar handle in brushed steel to outside to match internal side § Pentalock lever and cylinder to outside § Midrail § Option for 141 mm, 196 mm or 220 mm cill § triple track 194 mm, 249 mm, 273 mm § 10 year guarantee

Kawneer Aluminium– Inline Sliding Patio Doors Colour options 7 colours from stock with a 2 week lead time: Single colours § Black, White, Anthracite Grey, Textured Slate Grey or Light Grey Dual colours § Black out/White in and Anthracite Grey out/White in § Marine Grade Black Anodised finish available

Kawneer Aluminium– Inline Sliding Patio Doors Door configurations

Kawneer Aluminium– Inline Sliding Patio Doors Outer Frame - Mechanical Jointed § Mitre cut outer frame – mechanically joint on-site § Allows transportation of large frames § Aids manoeuvrability on-site § Joints must be adequately sealed on site § Sashes are crimped in the factory

Kawneer Aluminium– Inline Sliding Patio Doors Patio detail § Sliding leaf on the inside as standard § Can be mounted on the outside as option 113 mm frame depth for duo rail 175 mm frame depth for triple track

Kawneer Aluminium– Inline Sliding Patio Doors Patio dimensions

Kawneer Aluminium. Inline Sliding Patio Doors Frame edge detail § Small sash – 87 mm meeting style § 22 mm add on profile or § 34 mm add on profile available specifically required for night vents Cill detail – triple track Cill detail – twin track

Kawneer Aluminium– Inline Sliding Patio Doors Hardware § § § 400 mm Brushed Stainless cranked pull handle internally Pentalock 5 point locking Escutcheon and Pentalock lever Stainless steel track Adjustable tandem rollers capable of taking 160 Kgs per sash Optional • 400 mm Pull handle or finger pull externally • Pentalock lever and escutcheon to outside § 1, 000 mm cranked pull handle internally or externally

Kawneer Aluminium– Inline Patio Doors Weather rating § Intended for domestic use – not high rise § Weather test results § Air 600 Pascals § Wind 2400 Pascals § Water 300 Pascals

Kawneer Aluminium– Inline Patio Doors Weather rating § Intended for domestic use – not high rise § Weather test results § Air 600 Pascals § Wind 2400 Pascals § Water 300 Pascals

Kawneer Aluminium– Inline Sliding Patio Doors U Values Part L 1 B/L 2 B 28 mm Double Glazed Unit Glass U Value (W/m²K) 2 Panel 3 panel 3200 x 2100 4500 x 2100 4 panel 6000 x 2100 6 panel 6000 x 2100 1. 2 1. 96 1. 87 1. 93 1. 1 1. 83 1. 88 1. 86 1. 0 1. 75 1. 81 1. 72 1. 8 36 mm Triple Glazed Unit 0. 7 1. 52 1. 57 1. 49 1. 55

Kawneer Aluminium– Inline Sliding Patio Doors Summary Industry leading weather resistance Duo track - 2, 3 or 4 pane options Triple track - 3 or 6 pane options 87 mm or 107 mm meeting style 90 degree corner post for patio to window 400 mm cranked brushed stainless pull handle Pentalock 5 point locking enhanced security Euro cylinder Escutcheon and Pentalock lever 28 mm, 32 mm or 36 mm glazing Outer frame supplied mechanically jointed Option for 141 mm, 196 mm or 220 mm cill § triple track 194 249, 273 mm § 10 year guarantee § § §

Kawneer Aluminium– Lift & Slide Patio Doors Features § § § § § Industry leading weather resistance Brushed steel Lift & Slide handle to inside Choose from 7 stock colours, including dual colours Black anodised finish available Door sashes span up to 3 m wide and 2. 5 m high Stainless steel wheels and tracks Twin track - 2, 3 or 4 panel openings Triple track - 3 or 6 panel openings 28 mm, 32 mm or 36 mm glazing Sits on 141 mm, 196 mm or 220 mm cill § triple track 194 249, 273 mm Options • Brushed steel Lift & Slide handle to outside • Finger pull to outside

Kawneer Aluminium– Lift & Slide Patio Doors Colour options 7 colours from stock with a 2 week lead time : Single colours § Black, White, Anthracite Grey, Textured Slate Grey or Light Grey Dual colours § Black out/White in and Anthracite Grey out/White in § Marine Grade Black Anodised finish available

Kawneer Aluminium– Lift & Slide Patio Doors Door configurations

Kawneer Aluminium– Lift & Slide Patio Doors Patio detail § Sliding leaf on the inside as standard § Can be mounted on the outside as option Duo rail 113 mm Triple track 175 mm

Kawneer Aluminium. Lift & Slide Patio Doors Frame edge detail § 107 mm meeting style § 22 mm add on profile or § 34 mm add on profile available specifically required for night vents 124 Sub cill detail – triple track Sub cill detail – twin track

Kawneer Aluminium– Lift & Slide Patio Doors U Values Part L 1 B/L 2 B 28 mm Double Glazed Unit Glass U Value (W/m²K) 2 Panel 3 panel 3200 x 2100 4500 x 2100 4 panel 6000 x 2100 6 panel 6000 x 2100 1. 2 1. 96 1. 87 1. 93 1. 1 1. 83 1. 88 1. 86 1. 0 1. 75 1. 81 1. 72 1. 8 36 mm Triple Glazed Unit 0. 7 1. 52 1. 57 1. 49 1. 55

Kawneer Aluminium– Lift & Slide Patio Doors Hardware § § 250 mm brushed steel Lift & Slide handle to inside HS Portal gearing Stainless steel track Max sash weight 200 kgs Optional § Brushed steel Lift & Slide handle to outside § Finger pull to outside

Kawneer Aluminium– Lift & Slide Patio Doors Weather rating § Intended for domestic use – not high rise § Weather test results § Exceptional weather resistance: § Air 600 Pascals § Wind 2400 Pascals § Water 750 Pascals

Kawneer Aluminium– Lift & Slide Patio Doors Dimensions

Kawneer Aluminium– Lift & Slide Patio Doors Summary Brushed steel Lift & Slide handle to inside Exceptional weather resistance Choose from 7 stock colours, including dual colours Black anodised finish available Door sashes span up to 3 m wide and 2. 5 m high Stainless steel wheels and tracks Twin track - 2, 3 or 4 panel openings Triple track - 3 or 6 panel openings 28 mm, 32 mm or 36 mm glazing Sits on 141 mm, 196 mm or 220 mm cill § triple track 194 249, 273 mm Options • Brushed steel Lift & Slide handle to outside • Finger pull to outside § § § § §

Aluminium Entrance Doors Features 9 contemporary designs in Anthracite Grey Lever handle in Black, Anthracite Grey, Chrome or Brushed Steel 72 mm door frame depth Sobinco hook lock – 5 point locking 3 star diamond security cylinder with Kitemark PAS 24: 2016 enhanced security as standard Max outerframe size 986 mm wide by 2184 mm high with standard threshold § 1, 054 mm wide x 2, 218 with 34 mm add-on option § Severe weather tested 45 mm threshold § Double glazed units with satin obscured glass § § § § Options § 400 mm or 1, 000 mm Cranked bar handle in Brushed Steel with escutcheon to outside, available as inside option with outside option already fitted § Sidelights and toplights § Thumbturn cylinder § 15 mm low threshold

Aluminium Entrance Doors 9 contemporary designs in Anthracite Grey, matt finish

Aluminium Entrance Doors Hardware § Lever handle in four finishes, Black, Anthracite Grey, Chrome or Brushed Steel Options § 400 mm Cranked bar handle in Brushed Steel finish to outside, available as inside option with outside option already fitted (no lever handle when cranked bar handle is fitted) § 1000 mm Cranked bar handle in Brushed Steel finish to outside, available as inside option with outside option already fitted (no lever handle when cranked bar handle is fitted) § Thumbturn to inside

Aluminium Entrance Doors Security § Sobinco 5 point lock to master door § PAS 24: 2016 enhanced security § 3 star diamond rated security cylinder with Kitemark

Aluminium – Entrance Doors Entrance Door thresholds Standard threshold (severe weather rated) Low threshold (not severe weather rated)

Aluminium Entrance Doors Summary 9 contemporary designs in Anthracite Grey Lever handle in Black, Anthracite Grey, Chrome or Brushed Steel 72 mm door frame depth Sobinco hook lock – 5 point locking 3 star diamond security cylinder with Kitemark PAS 24: 2016 enhanced security as standard Max outerframe size 986 mm wide by 2184 mm high with standard threshold § 1, 054 mm wide x 2, 218 with 34 mm add-on option § Fully weathered 45 mm threshold § Double glazed units with satin obscured glass § § § § Options § 400 mm or 1, 000 mm Cranked bar handle in Brushed Steel with escutcheon to outside, available as inside option with outside option already fitted § Sidelights and toplights § Thumbturn cylinder § 15 mm low threshold

Kawneer Aluminium – French Doors Features § 7 colour options from stock § Black Anodised finish available § Standard fully weathered threshold 45 mm § Low threshold option (24 mm) § Finger bolt on slave door § Chamfered 28 mm glazing bead as standard § 28 mm, 32 mm & 44 mm square bead options: 36 mm chamfered bead option § 3 star diamond security cylinder with Kitemark § PAS 24: 2016 enhanced security available § Sits on 95 mm, 150 mm and 174 mm cills § 10 year guarantee

Kawneer Aluminium – French Doors Hardware • Master handles with design exclusive to KAT. Available in White, Grey, Black, Chrome, Gold and Brushed Steel guaranteed for 10 years.

Kawneer Aluminium - French Doors Colour options 7 colours from stock with a 2 week lead time : Single colours § Black, White, Anthracite Grey, Textured Slate Grey, Light Grey Dual colours § Black out/White in and Anthracite Grey out/White in § Black Anodised finish available

Kawneer Aluminium – French Doors French Door detail

Kawneer Aluminium – French Doors French Door thresholds Standard threshold (with full weather rating) Low threshold (not severe weather rated)

Kawneer Aluminium – French Doors Summary § 7 colour options from stock § Black Anodised finish available § Standard fully weathered threshold 45 mm § Low threshold option (24 mm) § Finger bolt on slave door § Chamfered 28 mm glazing bead as standard § 28 mm, 32 mm & 44 mm square bead options: 36 mm chamfered bead option § 3 star diamond security cylinder with Kitemark § PAS 24: 2016 enhanced security available § Sits on 95 mm, 150 mm and 174 mm cills § 10 year guarantee

Kawneer Aluminium Casement Windows Features of Casement Windows § • • 7 colour options from stock § Black anodised finish available 72 mm deep frame front to back Key locking handles in five finishes Excellent thermal properties Slim sight lines brick to glass Exclusive Hi-Reflex spacer bar thermal break technology Window U-Value 1. 4 with centre pane of 1. 2 Externally beaded as standard 10 year guarantee Options • Windows can be side hung, top hung or fixed • Corner posts and bay solutions • 28 mm and 36 mm Chamfered bead • 32 mm Square bead • Windows can be internally beaded

Kawneer Aluminium Casement Windows Colour options 7 colours from stock with a 2 week lead time : Single colours § Black, White, Anthracite Grey, Textured Slate Grey or Light Grey Dual colours § Black out/White in and Anthracite Grey out/White in • Black Anodised finish available

Kawneer Aluminium Casement Windows Hardware – Casement Windows • Key locking handles available in 5 finishes: Polished Chrome, Satin Silver, White, Gold and Black

Kawneer Aluminium Casement Windows U- Values Glass U Value (W/m²K) 1. 2 1. 6 1. 1 1. 53 1. 0 1. 46 0. 9 1. 39 0. 8 1. 31 0. 7 1. 24 0. 5 1. 1

Kawneer Aluminium Casement Windows Summary of Casement Windows § • • 7 colour options from stock § Black anodised finish available 72 mm deep frame front to back Key locking handles in five finishes Excellent thermal properties Slim sight lines brick to glass Exclusive Hi-Reflex spacer bar thermal break technology Window U-Value 1. 4 with centre pane of 1. 2 Externally beaded as standard 10 year guarantee Options • Windows can be side hung, top hung or fixed • Corner posts and bay solutions • 28 mm and 36 mm Chamfered bead • 32 mm Square bead • Windows can be internally beaded

Kwneer Aluminium Tilt Turn Windows

Kawneer Aluminium Tilt Turn Windows Features of Tilt Turn Windows • Hidden sash – no sash visible externally • 7 colour options from stock • Black Anodised finish available • 72 mm deep frame front to back • Lockable handles in 2 finishes • Excellent thermal properties • 80 mm Slim sight lines brick to glass across frame and sash • Square bead • Full window U-Value 1. 4 with centre pane of 1. 2 • 10 year guarantee

Kawneer Aluminium Tilt Turn Windows Hardware – Tilt Turn • Key locking handles available in 2 finishes: Inox Silver finish as pictured and White

Kawneer Aluminium Tilt Turn Windows U-Values Glass U Value (W/m²K) 1. 2 1. 52 1. 1 1. 45 1. 0 1. 37 0. 9 1. 3 0. 8 1. 23 0. 7 1. 15 0. 5 1. 01

Kawneer Aluminium Tilt Turn Windows Features of Tilt Turn Windows • Hidden sash – no sash visible externally • 7 colour options from stock • Black Anodised finish available • 72 mm deep frame front to back • Lockable handles in 2 finishes • Excellent thermal properties • 80 mm Slim sight lines brick to glass across frame and sash • Square bead • Full window U-Value 1. 4 with centre pane of 1. 2 • 10 year guarantee

Comprehensive range of products – Schüco Aluminium Systems BIFOLD DOORS PATIO DOORS WINDOWS

Schüco Aluminium Bifold Door Features § § § Thermally broken aluminium bifold door system Widely specified product with a highly regarded brand All hardware is supplied by Schüco, purpose designed for the job Variety of configurations up to 3 m high and 1. 2 m wide Inward or outward opening Standard threshold is 60 mm & Low threshold 6 mm (sunk into floor) Schüco own multipoint locking system to master door 3 star, diamond rated cylinder with Kitemark Shoot bolt lock to intermediate doors with D handle Square beads 28 mm glazing or up to 44 mm triple glazed Sits on 150 or 180 mm cills

Schüco Aluminium Bifold Door Colour options Standard white is RAL 9016 gloss Standard grey is RAL 7016 matt Both available from stock Standard black is RAL 9005 matt also available on short lead time although we do not stock it § Other RAL colours to order on extended lead times § Dual colour options as well also on extended lead times § §

Schüco Aluminium Bifold Door Furniture colour options Master handles – brushed silver and black as standard. Intermediate handle – in the same finish as master handle

Schüco Aluminium Bifold Door configurations

Schüco Aluminium Bifold Door Size limits Maximum Minimum Height 3, 000 mm depends on width 1, 600 mm Overall width 10, 000 mm 1, 800 mm Panel width 1, 200 mm 600 mm Weight per panel 100 Kgs Transport restricted to 6. 5 m therefore outer frames have to be mechanically jointed

Schüco Aluminium Bifold Door Mechanical joint option § Outer frames can be supplied as mechanically jointed § Doors are fabricated and fully assembled § Heavy product so please bare that in mind § Full installation instructions available silicone sealant

Schüco Aluminium Bifold Door Bifold detail Adjustable outer frame detail Threshold detail Low threshold

Schüco Aluminium Bifold Door Frame edge detail § § 70 mm edge detail 44 mm add on profile 150 & 180 mm cills Trickle vent through add on profile 80 442010 461230 461240 29. 5 224 079 150 108 442020 29. 5 461250 461230 22407 9 180 3 0

Schüco Aluminium Bifold Door Threshold Options Standard 60 mm threshold Low threshold is not fully weathered

Schüco Aluminium Bifold Door Hardware § Schüco have their own door lock § Stainless steel track § Rollers designed to take 100 Kgs per sash § Hinges are not adjustable but the outer frame jamb is therefore a small amount of lateral adjustment § Ball catch retainer § Slave leaf has finger bolts operated by handle

Schüco Aluminium Bifold Door Weather rating § Intended for domestic use – not high rise § U Value with standard warm edge unit 1. 2 centre pane would give a indicative U Value of 1. 7 W/m²K° § Test results § Air 600 Pascals § Wind 2400 Pascals § Water 300 Pascals

Schüco Aluminium Bifold Door Summary § § § Thermally broken aluminium bifold door system Widely specified product with a highly regarded brand All hardware is supplied by Schüco, purpose designed for the job Variety of configurations up to 3 m high and 1. 2 m wide sash size Inward or outward opening Standard threshold is 60 mm & Low threshold 6 mm (sunk into floor) Schüco own multipoint locking system to master door 3 star, diamond rated cylinder with Kitemark Shoot bolt lock to intermediate doors with D handle Square beads 28 mm glazing or up to 44 mm triple glazed Sits on 150 or 180 mm cills

Schüco Lift & Slide Patio Features § § § § In line lift & slide door system Built to accommodate very large openings up to 400 kgs Ultra smooth sliding operation Door can be opened for a small amount for ventilation Duo track or triple track 2, 3 or 4 pane options as dual rail 3 or 6 pane options as triple track Schüco own door hardware 3 star, diamond rated cylinder with Kitemark Flat glazing bead 32 mm glazing Outer frame supplied mechanically jointed or ready made Does not sit on a cill

Schüco Lift & Slide Patio Colour options § Wide range of RAL colours, including dual colours

Schüco Lift & Slide Patio Furniture colour options • Black, brushed satin or anodised silver finish • Anodised silver recommended for marine applications • All hardware is supplied by Schüco • Tracks are made from stainless steel • Purpose designed lift & slide gearing

Schüco Lift & Slide Patio Door configurations Sliding door always on the inside

Schüco Lift & Slide Patio Size limits • Minimum overall width – 2400 mm • Maximum overall width – 11500 mm • Minimum overall height – 2000 mm • Maximum overall height – 3000 mm • Minimum sash width - 1200 mm • Maximum sash width - 3000 mm Weight limit on the wheels is 400 Kgs

Schüco Lift & Slide Patio detail § Sliding leaf on the inside as standard • 160 mm frame depth for the duo rail • 250 mm for the triple track • Sightline is 88 mm or 108 mm depending on the size of the door

Schüco Lift & Slide Patio Frame edge detail § 160 mm edge detail duo track and 250 mm edge detail triple track § Outer frame is too wide to accommodate a cill and therefore it is not fitted on a cill section § The same applies to add on profiles

Schüco Lift & Slide Patio Threshold Options Alternative detail Typical threshold detail

Schüco Lift & Slide Patio Hardware § Lift & slide locking system is integrated with the roller system on this type of door § Option for two locking points or four locking points § Lever handle which turns through 180° § Stainless steel track § Rollers capable of taking 400 Kgs per sash (300 kgs if straight sliding) § Black, brushed satin or anodised silver

Schüco Lift & Slide Patio Weather rating § Intended for domestic use – not high rise § Weather test results § Air 600 Pascals § Wind 2400 Pascals § Water 150 Pascals

Schüco Lift & Slide Patio Summary § § § In line lift & slide door system Built to accommodate very large openings up to 400 kgs Ultra smooth sliding operation Door can be opened for a small amount for ventilation 2, 3, 4 or 6 pane options Duo track or triple track Schüco own door hardware 3 star, diamond rated cylinder with Kitemark Flat glazing bead 32 mm glazing Outer frame supplied mechanically jointed or ready made Does not sit on a cill

Header slide needed Schuco Aluminium Windows

Schüco Casement Windows Features § Wide range of RAL colours § Key locking handles in Anodised Silver, Black or White § Slim aluminium sections means more glass and more light § Contemporary square bead § Windows open outwards § 70 mm deep frame § Internally glazed as standard – 28 mm double glazed § U-Value 1. 5 W/(m²K) – 1. 0 W/(m²K) available Optional: § Trickle vent, allow 44 mm add-on or trickle vent through the sash § Up to 34 mm glazing available § Can conform to PAS 24 § Windows can be externally glazed

Schüco Casement Windows Colour options § Standard colours Black Matt, White Gloss or Anthracite Grey Matt available in 3 weeks § Wide range of RAL colours, including dual colours available with a longer lead time

Schüco Casement Windows Hardware § Cranked key locking handles in Anodised silver, black or white § For marine applications, we recommend the anodised silver finish § Stainless steel friction hinges, including egress § Opening restrictors § All hardware is supplied by Schüco Optional § Heavy duty austenitic stainless steel friction hinges, including egress Anodised Silver finish

Schüco Casement Windows Dimensions and opening configurations Side hung sash Top hung sash Minimum Sash Width 350 mm Maximum Sash Width 700 mm Minimum Sash Height 500 mm Maximum Sash Height 1600 mm 1800 mm Maximum Sash Weight 42 kgs 100 kgs 1800 mm

Schüco Casement Windows Cills Available at: § 85 mm § 150 mm § 190 mm Note: 25 mm platform on all cills

Schüco Casement Windows Profile § Frame depth 70 mm front to back § Contemporary square bead Slim Window Profile Standard Window Profile

Schüco Casement Windows Features § § § § Wide range of RAL colours Key locking handles in Anodised Silver, Black or White Slim aluminium sections means more glass and more light Contemporary square bead Windows open outwards 70 mm deep frame Internally glazed as standard – 28 mm double glazed U-Value 1. 5 W/(m²K) – 1. 0 W/(m²K) available Optional: § Trickle vent, allow 44 mm add-on or trickle vent through the sash § Up to 34 mm glazing available § Can conform to PAS 24 § Windows can be externally glazed
