Advanced DC Motor Advanced DC Motor Info n

Advanced DC Motor

Advanced DC Motor Info n n n Advanced D. C. Motors, Inc. combines years of DC motor building experience with tight quality control and a dedication to road-going electric vehicles that is unmatched by any other DC motor manufacturer. They are the most widely used DC motors in conversions, and for good reason. Advanced D. C. motors feature: Sealed bearings with high-temperature grease Heavy-duty commutator construction Heavy-duty brass brush boxes Stainless steel brush springs Brush life of approximately 80, 000 miles Easy brush replacement 1 1/8" keyed drive shaft High-temperature molded field insulator High-efficiency high-flow die cast aluminum fan

Advanced DC Motor Charts n. Length - 14. 50“ Diameter- 8. 0" Weight -107. 0 lbs. Input Voltage -96 -120 V Efficiency -89. 0% Test Data @ 96 V Input Time on Volts Amps RPM 5 min. 86. 0 322 3600 1 hr. 90. 0 190 4800 Continuous 91. 0 178 5000 Peak Horsepower- 68. 00 HP 31. 50 20. 60 19. 00 KW 23. 80 15. 50 14. 40 Test Data @ 120 V Input Time on Volts Amps 5 min. 111. 0 300 1 hr. 114. 0 180 Continuous 115. 0 165 Peak Horsepower- 83. 00 HP 37. 00 24. 00 21. 70 KW 28. 00 16. 30 RPM 4650 6200 6500

Scott Motor

Scott Motor

Scott Motor Info n n Horsepower Rating- 1 RPM- 2800 Voltage- 12 -24 Amps- 41 Weight- 15. 2 lbs. With Base Mount (Can be removed) These motors are ideal for Electric Vehicles up to 400 lbs. including Driver weight

Etek Motor

Etek Curve

Etek Mechanical Dimensions

Etek-R motor

Etek-R Info n n n n Power - 8 cont-- 15 pk hp Voltage - 48 V rated Speed - 3700 rpm @ 48 V unloaded Size - 8" OD, 5. 5" long (w/o shaft) Shaft - 7/8"x 1 -3/4", 3/16" key Weight - 28 lbs. Price - $450

Mars motor

Mars Motor

Mars Brushless motor info. n Brushless Motor 10 kw peak power n www. thunderstruck-ev. com n

Lemco Motor

Lemco

Lemco motor info.

Lemco motor info. Voltage Moto r Power I n Current Speed Power O u t Torque K Volts Shu nt Amps Shun t Rpm Watts Rpm Gen Moto r Nm Kgm W a tt s Efficie n c y % 24. 40 3. 70 12. 33 0. 30 1571. 00 1. 30 0. 13 0. 21 69. 20 21. 52 10. 40 34. 67 0. 75 1347. 00 4. 70 0. 48 0. 65 86. 53 21. 41 14. 80 49. 33 1. 06 1313. 00 6. 80 0. 69 0. 91 86. 20 21. 30 19. 30 64. 33 1. 37 1280. 00 9. 10 0. 93 1. 19 86. 68 21. 25 21. 00 70. 00 1. 49 1268. 00 9. 90 1. 01 1. 28 86. 05 21. 20 23. 10 77. 00 1. 63 1253. 00 11. 00 1. 12 1. 41 86. 10 21. 18 24. 70 82. 33 1. 74 1242. 00 11. 80 1. 20 1. 49 85. 70 21. 08 28. 20 94. 00 1. 98 1218. 00 13. 50 1. 38 1. 68 84. 62 21. 02 31. 00 103. 33 2. 17 1199. 00 14. 90 1. 52 1. 82 83. 87 20. 91 35. 40 118. 00 2. 47 1169. 00 17. 10 1. 74 2. 04 82. 61

Perm motor PMG 132

Perm 36 V Curve

Perm 48 V Curve

Perm 72 V Curve

Perm Mechanical Dimensions

D&D Motor

D&D Motor

D&D Motor Info n n These motors are designed and manufactured in Syracuse NY, USA, by 40 year professionals. Marketed as performance upgrades for golf cars, NEVs, and off-road buggies, Thunderstruck Motors sees their potential in a wide range of vehicle platforms. We've already put them in a large boat, an industrial truck, mountain climbing dune buggy, hot rod motorcycles. . . what's next? Sep. Ex <<What does the Separately Excited topology mean? >> These motors are similar to the series wound ADC motors we've seen; they have the same dimensions and no permanent magnets. But instead of having the motor field in series with the armature (and carrying armature current), the field is a separate electric circuit that is controlled independently by the controller. This allows the controller to alter the field strength as needed by the load; so at low speed the field strength is stronger, providing maximum torque. Then, as speed increases and armature current falls, the field weakens to optimize efficiency and allow the top speed of the motor to increase. As a bonus, the field is reversible, allowing re-gen braking! This reverse field then allows for reversing of the motor shaft without the need for external contactors or switches

D&D Motor Sep. Ex Output

D&D Motor 72 V Charts
