Accusonic Controls Pvt Limited Electrical Distributions Solutions 301

Accusonic Controls Pvt. Limited Electrical Distributions Solutions 301, R Square, Pune - 411 041, India Phone 009120 2523 6666 e-mail – info@accusonic. net, Website – www. accusonic. net

Generator Synchronizing Automation & Energy Monitoring Projects Power Accusonic Distribution Solutions Panels. Range Generator Load Banks Training & Maintenance

extensive customer experience is a key element to the solutions and services that we provide. Our Accusonic takes customercentric approach to identify the solutions that contribute to the customers success. profitability & Number 1 in Pune, Top 15 All India

Peace of Mind Understanding Customer Requirements Performance for Customer Success Sharing our experience with customers Proactive Taking Technology to customers service

Total offering • • Design Manufacture Testing Installation Commissioning Manpower Skill development After Sales Service On-Site support for assembly of busduct with PCC at Ina Bearings, Pune

Our key tie-up with technology leaders is another key element to the solutions and services that we provide.

Panel Facility

Panel Facility

Complete Routine Test Facility ü High Voltage Testing ü Insulation Resistance Testing ü Primary Injection Testing up to 4000 Amps ü Secondary Injection Testing ü Relay Testing ü PLC Logic Testing ü Heat-run Testing

Highest Customer Satisfaction

Ecu/Nco 12% Ncu 4% Ncu/Nco 7% We Care for Customer Success Ecu 35% Ncu/Eco 15% Ecu/Eco 26% 85 % business from repeat orders in projects

Mahindra & Mahindra, Chakan, Pune ü Total Accusonic Installation Value ~ Rs. 25. 00 Cr. ü Total Connected Load of over 100 Mw ü Enclosures for Dry Type Transformers ü PCCs for 41 2. 5 MVA Transformers ü APFC Panels ü Lighting Distribution Panels ü Power Distribution Boards

Accusonic Client : IT Parks ü Magarpatta City ü Infosys Technologies Ltd. ü Satyam Computers Ltd. ü Persistent Systems Ltd. ü Cybage Systems Ltd. ü IBM Daksha Ltd. ü Disha Aztech Ltd.

ACG World, Pithampur ü Total Accusonic Installation Value ~ Rs. 3. 5 Cr. ü Total Connected Load of over 5 Mw ü Synchronizing Panel for 4 x 1. 5 KVA DGs ü 6 Incomers & 3 Buscouplers ü Synchronizing within DG Sets, Synchronizing with Mains ü Automatic operation of Buscouplers

Large Hotel Projects Hotel Westin, Pune Hotel Radisson, Pune Hotel Hometel, Mumbai Hotel Shangrila, Mumbai Main Power Control Centers Power Distribution Boards Power Factor Correction Panels ü DG Synchronizing Panel ü ü ü ü

Building Projects ü ü ü ü ABIL Kolte Patil Mantri Constructions Magarpatta City Nanded City Paranjape Schemes S Balan Group

Projects in Pharma Sector ü Serum Institute ü Associated Capsules Ltd. ü Intervet Ltd. , Pune ü BILCARE Ltd. , Pune ü Pam Glatt Packaging Ltd. ü ACG World, Pithampur ü Emcure Pharmaceuticals ü Gennova Bio Pharmaceuticals ü Orchid Pharma, Aurangabad ü Actavis Pharma, Chennai

Design Highlights

Design Highlights

Generator Synchronizing ü More than 10 years of experience ü More than 100 installations ü Leader in independent Solution providers ü Complex synchronizing applications. Accusonic and Com. Ap combine their extensive experience and state of the art products range to provide the customers with innovative solutions.

DG Synchronizing Panel for 5 x 750 KVA sets

DG Synchronizing Panel for 5 x 750 KVA sets DG Synchronizing Panel for 4 x 2000 KVA sets

Magarpatta City IT Park, Pune ü Total Accusonic Installation Value ~ Rs. 20 Cr. ü Total Connected Load of over 100 Mw ü Synchronizing Panels for over 120 DGs ü AMF Panels ü APFC Panels ü Proactive Maintenance Plans

Installation at Magarpatta Cybercity, an IT Park project by Magarpatta Township Construction Company Ltd. , at Pune consisting of totally 124, 500 KVA to 750 KVA DG Sets Installations typically use a group of 4 DG Sets running in Synchronized mode as backup power to a supply from utility power

Automation Projects ü More than 20 years of experience ü System house of Schneider Electric ü Varied experience in PLC, Drives & SCADA projects ü Complex Automation applications. Accusonic and Schneider combine their extensive experience and state of the art products range to provide the customers with innovative solutions. Generator Testing Load Banks

JSW 1000 m. W Thermal Power Plant ü Total Accusonic Installation Value ~ Rs. 0. 8 Cr. ü Automation for Cooling water system ü GE Fanuc PLC ü SCADA

Installation at Naval Base of Project Seabird, Karwar. Automation consisting of 200 KW Drives , PLC, Power Panels Installation of 3200 k. W Load Bank consisting of PLCs, SCADA.

Installation with PLC based Control Panels for Load Banks

Installations of PCCs, MCCs at Chemical, Pharmaceutical Plants. Installations of PLCs, Drives & SCADA

Generator Testing Load Banks ü ü ü More than 3 years of experience Resistive & Inductive Load Banks Completely automated DG Set testing With PLC & SCADA Range of DG voltages to suit requirements. Accusonic and Cermet combine their extensive experience and state of the art products range to provide the customers with innovative solutions. Generator Testing Load Banks

3200 k. W Load Bank for Qatar Petro ü Total Accusonic Installation Value ~ Rs. 1. 60 Cr. ü Completely automatic Ship Based Generator Testing ü Schneider PLC , SCADA ü Cable reeling drum

World–Class Enclosures ü ü ü E-Coated Enclosures Completely Robotic Manufacturing Nano Ceramic coating pretreatment Arc Flash Protection Testing as per latest IEC-61439 Accusonic and Rittal combine their extensive experience and state of the art products range to provide the customers with innovative solutions. Enclosures are Type Tested to IS & IEC

Design Highlights • Flexible Cable Entry • Part Top/Part Bottom cable entry possible • Rear or Front Maintained Access

Design Highlights • • Modular Design Faster Deliveries Better Aesthetics Flexible Design

Type Test World–Class Enclosures features 1. 5500 Amps 2. 100 k. A 3. Tested with all major Switchgear brands 4. IP 55 5. Totally Type Tested Assembly (TTA) 6. Protection against

Standards World–Class Enclosures 1. IS 8623 2. IEC 60439 3. IEC 61439 4. IEC 61641

Design Highlights • Interleaved Design for higher rating • High Mechanical Withstand capability • Early warning for Abnormal conditions

World–Class Busbar Systems

Design Highlights • Busbar Designs Choices • Rear/Top/Bottom • Easy Access for Maintenance • On site up-gradation

1. Compartmenta l & Non Compartmenta World–Class Enclosures l Enclosures 2. Copper & Aluminum Busbars 3. Suitable for Sandwich Busducts

World–Class Enclosures Form 2 Form 3 Form 4 Isolation available for all internal operations Adjust setting & carry out limited maintenance when adjacent units are live Connect & disconnect cables, Adjust setting & carry out limited maintenance

Form 2 Type 2 World–Class Enclosures 1. Separation of Functional units from Busbars 2. Terminals for external conductors separatedfrom busbars

Form 3 b Type 2 World–Class Enclosures 1. Separation of Functional units from Busbars 2. Separation of terminals from functional units 3. Terminals for external conductors separatedfrom busbars but not from one another

Form 4 Type 6 World–Class Enclosures 1. Separation of Functional units from Busbars 2. Terminals are in individual, separate compartment from the functional units

Motor Control Centre for Thermax Ltd. using Rittal PS type enclosure Power Control Centre for Mahindra & Mahindra Ltd, Chakan using Rittal PS type enclosures

Design Highlights • Meets relevant Safety Standards • High Operator Safety

Design Highlights • Wiring & Marking as per Latest IS • System Designs to suit Component Co-ordination

Energy Monitoring on Ethernet Accusonic offers En. Powerment. Soft a versatile and customer configurable Energy Monitoring Software. This software automates the task of collection of energy consumption data across your facility.

Design Highlights • On-Line Display • Data Logging • Alarms • Data Analysis • Bill Generatio n

View of On-Line Data Trend Historical Trend Analysis

Pro. Care – Proactive Customer Care Accusonic with its Experience & Technology offers services to ensure that the products are installed and used to their optimum effectiveness. Accusonic also offers various training programs in the aspects of usage and maintenance for the personnel who use these products. Report format for test conducted • Annual • maintenance contracts • • Thermal imaging • • Electrical analysis Harmonic analysis ACB servicing Training On-Site support for assembly of busduct with PCC at Ina Bearings, Pune

Empowering. . through e-power

Empowering. . through e-power How can I All Set to make a difference!!! Better Energy Management + Safer Best Practices – Environment at work make a difference? ? Awareness – Raise current level of knowledge Sensitization – create buyin and motivate introduce industry best practices

Empowering. . through e-power

Accusonic believes in Punctuality Quality Service

With an Aim for Total Customer Success

Accusonic We value your business & thank you for your time
