AC Power Distribution An extensive line of power
AC Power Distribution An extensive line of power distribution, conditioners, sequencers, surge protection and accessory devices that deliver superior equipment protection
AC Power Distribution / Conditioners 19” & ½ 1 RU Rack Mount AC Power Conditioning and Distribution Units Electrical Power Sequencing control modules, featuring sequenced turn on receptacles and voltage monitoring
Included Features Radio Frequency Interference (RFI) Filtering • Radio Frequency Interference (RFI) is commonly introduced into the AC lines by nearby radio transmitters or wireless products • Typical sources of RF signals include AM & FM radio stations, walkie-talkies and mobile phones • If the RFI is audible, it can take many forms such as buzz, noise bursts, speech, or music
Included Features Electromagnetic Interference (EMI) Filtering • Electromagnetic Interference (EMI) is commonly introduced into the AC lines by electric motors, switching power supplies and lightning • The disturbance may degrade the performance of the circuit or even stop it from functioning
Included Features Circuit Breaker Protection • Circuit breaker protection is used along with grounding for protecting electronic appliances from overloading and heat build-up • Circuit breaker protection is essential in today’s world because the safety mechanism of this equipment guards a structure and its occupants against the electrical hazards of faulty wiring, damaged insulation, improper grounding, short-circuit and voltage fluctuations
Included Features Surge Protection • A voltage spike or surge, is a transient event, typically lasting 1 to 30 microseconds, that may reach over 1, 000 volts • Spikes can degrade wiring insulation and destroy electronic devices • Spikes can also occur on telephone and data lines, when AC main lines accidentally connect to them
Special Feature Glossary Dual Clamping Suppression (DCS) • If a spike intrudes the AC system, the incoming AC Mains has special suppression circuitry to eliminate the unwanted energy, and in the unlikely event of any energy getting passed the first stage, each output section has redundant DCS circuitry, clamping the unwanted energy • This circuitry is very fast and can suppress unwanted energy within a nanosecond, while sustaining the suppression up to 2 milliseconds, thus ensuring virtually trouble-free protection
Special Feature Glossary Unswitched • The 120 VAC Unswitched outlets are always live when the power cord is plugged into an AC mains power source and when voltage is present • The AC mains power switch does not affect the Unswitched AC Outlets • The Unswitched Outlets are protected by the surge protection circuitry, but will not be shut off by EVS circuitry
Special Feature Glossary Extreme Voltage Shutdown (EVS) • EVS (Extreme Voltage Shutdown) is intended to remove AC power from devices plugged into the switched outlets in the event of unsafe high or low voltage conditions • If an extreme voltage swing occurs above 132 VAC or below 101 VAC, the Extreme Voltage Shutdown (EVS) protection circuit will automatically activate and turn all outlets off until it is manually reset
Special Feature Glossary Emergency Power Down (EPD) • The EPD may be required by the local fire code to pass site inspection • This port when activated, turns Off all the SWITCHED outlets at once
Power Distribution / Conditioners AP-C 15 D 120 V 15 A AC Power Distribution with Power Conditioning and Advanced AC Mains Protection • Front Panel Digital AC Mains Voltmeter • 10 Total Outlets: 8 Rear Panel Outlets, 2 Front Panel • Dual Clamping Suppression (DCS) • Abnormal AC Line Voltage Fault Indication • Extreme Voltage Shutdown protection for both Hi & Low AC Voltages • Front Mounted Pull-Out LED Light, rear light socket https: //www. atlasied. com/ap-c 15 d
Power Distribution / Conditioners AP-S 15 A & AP-S 15 LA 120 V 15 A AC Power Distribution • Great value • 9 Total Outlets: 8 Rear Panel Outlets, 1 Front Panel Outlet • Removable 12’ IEC Cord • Front Panel Pull Out Light (on the AP-S 15 LA Only) https: //www. atlasied. com/ap-s 15 a / https: //www. atlasied. com/ap-s 15 la
Power Distribution / Conditioners AP-S 20 RT 120 V 20 A AC Power Distribution - Remote Turn On & Advanced Product Protection • 9 Total Outlets: 8 Rear, 1 Front • System Activation Via Front Panel Switch, Remote Wall Switch or 3 rd Party trigger. • EPD (Emergency Power Down) to Incorporate with Fire Control Panels • Extreme Voltage Shutdown (EVS) protection for both Hi & Low AC Mains Voltages • Rear Light Socket • Front Mounted USB Charger / Light Port https: //www. atlasied. com/ap-s 20 rt
Power Distribution / Conditioners AP-S 20 120 V 20 A AC Power Distribution • Great value for high current power distribution with AC Mains Protection • 9 Total Outlets: 8 Rear Panel Outlets, 1 Front Panel Outlet https: //www. atlasied. com/ap-s 20
Power Distribution / Conditioners AP-S 15 RTHR 120 V 15 A Half Rack AC Power Distribution With Remote Turn ON • Half Width Rack, Fits Atlas. IED Racks • 6 Total Outlets: 4 Rear Panel (Switched) • Remote Activation • EPD (Emergency Power Down) to Integrate with Fire Control Panels • 24 VDC 2000 m. A DC Output will provide power to Atlas. IED TSD products or trigger other AC Power Distribution products https: //www. atlasied. com/ap-s 15 rthr
Power Distribution / Conditioners AP-S 15 HR 120 V 15 A Half Rack AC Power Distribution • Great value with AC Protection • Half Width Rack, Fits Atlas. IED Racks • 6 Total Outlets: 5 Rear Panel Outlets, 1 Front Panel Outlet https: //www. atlasied. com/ap-s 15 hr
Power Distribution / Conditioners ECM-15 SH 15 A AC Power Conditioner & Spike Suppressor (Single Housing) • Suited for applications where AC protection is needed in tight spaces such as behind TV’s • Standalone AC Power Conditioner / Spike Suppressor • 2 Outlets • AC Fault Indicator • Active Outlet LED https: //www. atlasied. com/ecm-15 sh
Power Distribution / Conditioners ECM-20 SH 20 A AC Power Conditioner & Spike Suppressor (Single Housing) • Suited for applications where Hi Current, AC protection is needed for remote single load • Standalone AC Power Conditioner / Spike Suppressor • 2 Outlets • AC Fault Indicator https: //www. atlasied. com/ecm-20 sh
Electrical Power Sequencing What are the key benefits to Electrical Power Sequencing? 120 V AC Power Distribution, Power Sequencing, Conditioning & Surge Protection • Sequencing the power will avoid tripping the main breaker • Simply by turning the largest current drawing units On or Off - one unit at a time, will eliminate an in-rush of current • Audible pops often occur without electrical power sequencers https: //www. atlasied. com/power-distribution-electrical-power-sequencers
Electrical Power Sequencing ECS-3 120 V 15 A AC Power Distribution, Power Sequencing, Conditioning & Surge Protection • 9 Total Outlets: 6 Rear Panel Outlets Sequenced in 3 Stages, 3 Unswitched Outlets • Sequenced feed to power remote power modules like the ECM-15 SH or ECM-20 SH • Front Panel Voltmeter Display • System Activation Via Front Panel Switch, Remote Wall Switch or 3 rd Party trigger. • Dual Clamping Suppression (DCS) • Extreme Voltage Shutdown protection to Incorporate with Fire Control Panels • Front Mounted Pull-Out LED Light with 2 Position Dimmer https: //www. atlasied. com/ecs-3
Electrical Power Sequencing ECS-204 120 V 20 A AC Power Distribution, Sequencing, Conditioning & Surge Protection • 9 Total 20 A Outlets: 6 Rear Panel Outlets Sequenced in 3 Stages, 3 Unswitched Outlets • Sequenced feed to power remote power modules like the ECM-15 SH or ECM-20 SH • Front Panel Digital AC Mains Voltmeter / Dual USB Charge Ports / Rear Light Socket • Extreme Voltage Shutdown protection to Incorporate with Fire Control Panels • Emergency Power Down (EPD) contacts • AC Fault, Wiring Fault & Abnormal Voltage Indicators • Dual Clamping Suppression (DCS) • System Activation Via Front Panel Switch, Remote Wall Switch or 3 rd party trigger https: //www. atlasied. com/ecs-204
Electrical Power Sequencing TSD-SEQ 6 Sequence Controller for Remote 120 V AC Power Distribution Modules • Ultra-compact, does not require rack mounting • Integrates with ECS-2063, ECM-15 SH, ECM-20 AC Power Modules • 6 Sequenced Outputs that supports 24 VDC or Hard Switch Contact Closure (CC) per Output • Adjustable Sequence Timing • System Activation Via Front Panel Switch, Remote Wall Switch or 3 rd Party trigger. • Status Indicator for Each Output • Emergency Power Down Port to Incorporate with Fire Control Panels https: //www. atlasied. com/tsd-seq 6
Electrical Power Sequencing ECM-2063 Hi-Current 20 A – 60 A 120 V AC Power Distribution Raceway • Ideal for high current cost-effective AC power distribution systems • Designed to integrate with the TSD-SEQ 6 Controller • Accepts up to 1 -3 20 A 120 VAC Lines, Configurable • 6 sequence sections • 12 AC Outlets total • Each channel has separate status indicators • Remote or Local Activation • Electrical Knockouts 1/2" & 3/4" / 4 Rail Mounting Tabs https: //www. atlasied. com/ecm-2063
Electrical Power Sequencing ECS-6 RM Sequence Controller & Monitor for Remote 120 V AC Power Distribution Modules • Module High Current Power Distribution System • Controls & Monitoring Six Independent 20 A or 30 A 120 V Distribution Channels • Flexible Configurations, Singular Raceway or Multi Zone • Integrates with ECS-2063, ECM-15 SH, ECM-20/M AC Power Modules • Separate Voltage and Current Readings For Each Channel / Adjustable Sequencer Timing • System Activation Via Front Panel Switch, Remote Wall Switch or 3 rd Party trigger. • Individual Channel Extreme Voltage Shutdown protection • Emergency Power Down Port to Incorporate with Fire Control Panels https: //www. atlasied. com/ecs-6 rm
Electrical Power Sequencing ECM-20 / ECM-20 M 120 V 20 A AC Power Module with Conditioning & Spike & Surge Protection • Integrates with ECS-6 RM • Installs into ECM-RACEWY 1, ECM-RACEWY 3 or ECM-RACEWY 6 • 2 Outlets, 20 A 120 V • Incoming AC Present, Active & AC Fault Indicators • AC Mains Voltage & Current Monitoring (Only on ECM-20 M) https: //www. atlasied. com/ecm-20 / https: //www. atlasied. com/ecm-20 m
Electrical Power Sequencing ECM-30 120 V 30 A AC Power Module with Conditioning with Spike & Surge Protection • Single 30 A Outlet • Manual/Auto On/Off Switch • Incoming AC Present LED • Active and AC Fault LEDs • EVS Circuitry https: //www. atlasied. com/ecm-30
Electrical Power Sequencing ECM-RACEWY 1 Electrical Housing for 1 ECM Module ECM-RACEWY 3 Electrical Housing for 3 ECM Modules ECM-RACEWY 6 Electrical Housing for 6 ECM Modules ECM 120 V Power Modules Housings • ½” & ¾” Electrical Knockouts • Rail Mounting Tabs • Finished in Black Paint https: //www. atlasied. com/ecm-racewy 1 https: //www. atlasied. com/ecm-racewy 3 https: //www. atlasied. com/ecm-racewy 6
