Abstract Data Types Operation contracts CSE 432

Abstract Data Types What does ‘abstract’ mean? n From Latin: to ‘pull out’—the essentials n – To defer or hide the details – Abstraction emphasizes essentials and defers the details, making engineering artifacts easier to use n I don’t need a mechanic’s understanding of what’s under a car’s hood in order to drive it – What’s the car’s interface? – What’s the implementation?

Floating point numbers as ADTs n You don't need to know how much about floating point arithmetic works to use float – Indeed, the details can vary depending on processor, even virtual coprocessor – But the compiler hides all the details from you-some numeric ADTs are built-in – All you need to know is the syntax and meaning of operators, +, -, *, /, etc. n See multimedia: ADT for digits (properties)

ADT = properties + operations n An ADT describes a set of objects sharing the same properties and behaviors – The properties of an ADT are its data (representing the internal state of each object • double d; -- bits representing exponent & mantissa are its data or state – The behaviors of an ADT are its operations or functions (operations on each instance) • sqrt(d) / 2; //operators & functions are its behaviors n Thus, an ADT couples its data and operations – OOP emphasizes data abstraction

Design by contract n ADT is a formal description, not code – Independent of any programming language – Why is code independence a good idea? n Promotes design by contract: – Suppler/client responsibilities specified explicitly – So they can be enforced, if necessary n E. g. , a contract for writing a book: – Contract specifies the book that the author will write – Also specifies the royalties the publisher will pay, etc.

Generic Queue ADT n An ADT specification has six parts – First 3 deal with syntax: NAME, SETS and SIGNATURES NAME Queue<I> SETS I set of all items (generic type) Q set of all Queues Bset of Boolean (elements T and F) N set of natural numbers, including 0 n NAME specifies an identifier for the type – Generic parameter, <I>, may specify elements of collections n SETS specifies types of all parameters in SIGNATURES

SIGNATURES section (see umprobso—“you are adding”) SIGNATURES n n n Queue() -> Q front(Q) -/-> I is. Empty(Q) -> B enqueue(Q, I) -> Q length(Q) -> N dequeue(Q) -/-> Q SIGNATURES specifies the operations or services provided by ADT Notation of mathematical functions, with one or more inputs and producing one result: – is. Empty(Q) -> B: Given a Queue (domain), produces a Boolean (range) Functions have no side effects at all: – front(Q): given a Q, returns an item (no change) – enqueue(Q, I): returns a NEW Queue – dequeue(Q): returns another Queue Functional approach may seem inefficient, but facilitates semantics – Implementation should preserve the abstract behavior of ADT Syntax is relatively easy to specify; semantics is a bit harder….

Full vs. partial functions SIGNATURES Queue() -> Q front(Q) -/-> I is. Empty(Q) -> B enqueue(Q, I) -> Q length(Q) -> N dequeue(Q) -/-> Q n -> denotes a full function over the set Q – Always produces the specified output n ‑/‑> denotes a partial function over the set Q – May not always produce the specified output – Instead, its result may be undefined When is front undefined? When is en. Queue undefined? n Answering these questions about partial functions is semantics n – Specifically, the preconditions: – A partial function is undefined if any of its preconditions do not hold

Exercise: Stack ADT syntax n Define the NAME, SETS and SIGNATURES of an ADT for stacks (assume unlimited size) NAME Stack<i> SETS I S B set of all items set of all Stacks set of Boolean SIGNATURES Stack() -> S is. Empty(S) -> B top(S) -/-> I push(S) --> I pop(S) -/> Q

Semantics of ADTs n 3 more sections for semantics of ADTs: variables, preconditions, and postconditions VARIABLES i: I; q, r: Q; n: N; b: B PRECONDITIONS front(q) -> is. Empty (q) = false dequeue(q) -> is. Empty (q) = false VARIABLES -- declares instances of SETS, needed in PRE- and POST-CONDITIONS n How are the variables used in PRECONDITIONS? n What is the scope of these variables? n

Preconditions n n n Specify constraints on any partial functions, indicating when they fail front(q) -> is. Empty (q) = false //What does this constraint tell you? – PRECONDITIONs very explicit about the when a partial function fails Formalizes design by contract: analogous to written business contracts – Inspires confidence between clients and suppliers of products ADT specifies a contract between the supplier and client of an ADT – Supplier warrants that ADT will produce the specified behavior – so long as client provides the expected inputs – so long as client doesn’t violate the pre-conditions, behaviors will work – if the client violates the contract (any pre-condition), the behavior fails – Yet even the failure is predictable and can be handled predictably Thus PRECONDITIONS also set up exception handling Note: no need to include trivial preconditions, e. g. , is. Empty(q) -> true.

Exercise: Stack ADT preconditions n Define preconditions (and variables) for Stack ADT NAME Stack<i> SETS I set of all items S set of all Stacks B set of Boolean SIGNATURES Stack() -> S push(I, S) --> S is. Empty(S) -> B pop(S) -/> S top(S) -/-> I VARIABLES s: Stack; i: Item; PRECONDITONS top(s) -> is. Empty(s) = false pop(s) -> is. Empty(s) = false

Postconditions n Define effects of functions, i. e. , what they accomplish POSTCONDITIONS Queue() = (q. List = List()) is. Empty(q) = null(q. List) length(q) = length(q. List) front(q) = head(q. List) enqueue(q, i) = (q. List = append(q. List, i)) dequeue(q, i) = (q. List = tail(q. List, i)) n What are we assuming already exists in these postconditions? – List ADT has already been defined n Why is constructive semantics a good fit for OOP? – Reusing List implies a constructive semantics, building from other ADTs, already defined n n What does first postcondition tell you? What does second postcondition tell you?

Axiomatic semantics n Defines relations between operations strictly in terms of universal axioms (self-evident truths) – Axioms define an ADT independently of other ADTs – Constructive approach builds new ADTs based on knowledge of existing ones – The buck has to stop somewhere: e. g. , the List ADT uses an axiomatic semantics

List postconditions (axioms) n n null(List()) = true //How is this self-evident? null(prepend(list 1, i)) = null(append(list 1, i)) = false //Explain? length(List()) = 0 length(append(list 1, i)) = length(list 1)+1 tail(append(list 1, i)) = if null(list 1) then [] else append(tail(list 1), i))

Constructive semantics (See umprobso, “Queue of football”) Explain rest of Queue’s postconditions: front(q) = head(q. List) enqueue(q, i) = (q. List = append(q. List, i)) dequeue(q, i) = (q. List = tail(q. List, i)) n Why would this be harder with axioms? n – (See umprobso, “axiomatic”)

Exercise: Stack ADT postconditions n Define postconditions for Stack ADT NAME Stack<i> SETS I set of all items S set of all Stacks B set of Boolean SIGNATURES Stack() -> S is. Empty(S) -> B top(S) -/-> I VARIABLES s: Stack; i: Item; push(S) --> I pop(S) -/> S POSTCONDITIONS Stack() = (s. List = List()) is. Empty(s) = null(s. List) top(s) = head(s. List) pop(s) = (s. List = front(s. List)) push(s, i) = (s. List = prepend(s. List, i))

Inheritance and ADTs n n See Employee example How does inheritance affect name section? – NAME Employee SUPERTYPES Person n How does inheritance affect other sections? – – – n Employee inherits functions for name, address, etc, from Person Inherits both syntax (SIGNATURES) and semantics Only redefine functions in Employee if they do something different Employee just supplies new constructor, GROSS_PAY, TAX_DUE Semantics can benefit further from reuse implied by inheritance Constructor for Employee invokes constructor for Person Could add notation {abstract} to specify abstract functions

Why define ADTs? n Makes contract between designer and programmers explicit – Eliminates vagueness about what functions (operations or methods) do – Eiffel provides assertions to support programming by contract – Assertions have been added to Java n Sets up unit testing

Domain Model and Operation Contracts n. A Domain Model is a visual representation of conceptual classes in a domain of interest. n Operation Contracts describe detailed system behavior of operations – In terms of state changes to objects in the Domain Model, after a system event has executed

Example Operation Contract from Larman: enter. Item Contract CO 2: enter. Item Operation: enter. Item(item. ID : Item. ID, quantity : integer) Cross References: Use Cases: Process Sale Preconditions: There is a Sale Underway. Postconditions: -A Sales. Line. Item instance sli was created (instance creation) -sli was associated with the current Sale (association formed) -sli. quantity became quantity (attribute modification) -sli was associated with a Product. Specification, based on item. ID match (association formed) How does it differ from an ADT spec?

Postconditions Describe changes in the state of objects in the Domain Model n Include instances created, associations formed or broken, and attributes changed n Postconditions are not actions to perform n Rather, they are declarations about Domain Model objects that are true when the operation has finished n

Writing Postconditions: Past Tense n Express postconditions in the past tense, to emphasize they are declarations about a state change in the past. – (better) A Sales. Line. Item was created. – (worse) Create a Sales. Line. Item. – Why?

The Spirit of Postconditions: The Stage and Curtain n System and it’s objects are presented on a theatre stage – Before the operation, snapshot of the stage. – Close the curtains on the stage, and apply the system operation – Open curtains and take a second picture – Compare the before and after pictures, and express as postconditions the changes in the state of the stage – (A Sales. Line. Item was created…).

Writing Contracts Leads to Domain Model Updates n New conceptual classes, attributes, or associations in the Domain Model are often discovered during contract writing n Enhance the Domain Model as you make new discoveries while thinking through the operation contracts

Guidelines: Contracts n To make contracts: – Identify system operations from SSDs – For system operations that are complex and perhaps subtle in their own results, or which are not clear in the use case, construct a contract – To describe the postconditions, use: - instance creation and deletion - attribute modification - associations formed and broken

System Sequence Diagram and ADT assignment n Your assignment (on Blackboard): – Improve your domain analysis • Per my comments – Develop a System Sequence Diagram for the ATM problem – Develop ADT design/Operation contracts for the Fruit problem – Extra credit: design user interface ADTs for either • loosely coupled to problem domain ADT n Due September 30
