A Comparative Survey of Enterprise Architecture Frameworks Jaap

A Comparative Survey of Enterprise Architecture Frameworks Jaap Schekkerman, B. Sc. President of the Institute For Enterprise Architecture Developments (IFEAD) Thought Leader Business Technology Strategy & Enterprise Architecture, Capgemini Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 1

Agenda • • About the speaker EA Survey 2003 Results – EA Framework Usage EA Frameworks Comparison Conclusion Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 2

Speaker Qualifications - Jaap Schekkerman Author / Co-Author of several Architecture books & publications • Founder & President of the Institute For Enterprise Architecture Developments, The Netherlands. • Thought Leader Business Technology Strategy & Enterprise Architecture, Capgemini, The Netherlands. • Professional Associations: – – – – Advisory board member of the Federal Enterprise Architecture Certification Institute, USA. Co-Founder & Alliance member of the Global Enterprise Architecture Organisation, New Zealand. Member of the 'MANYWORLDS' knowledge network of Business Thought Leaders, USA. Member of the IEEE 1471 (Recommended Practice for Architectural Description) working group, USA. Member of the World Wide Institute of Software Architects (WWISA), USA. Member of the Netherlands Society of Information Architects (GIA), NL. Member of the SWEBOK (Software Engineering Body of Knowledge) working group of the University of Québec, Montréal. For more info about my books & publications, visit: http: //www. enterprise-architecture. info Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 3

Combining EA Research & Best Practices Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 4

Survey Question: What kind of EA Frameworks are you using? All Industries / Governments All Others except the Financial & Insurance Industry Source: EA Survey 2003, © Copyright: IFEAD Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 5

Enterprise Architecture Frameworks & the Holistic Perspective Trends • Holistic Architecture: By 2006, 20% of Global 2000 organizations will integrate holistic enterprise architecture, enterprise program management, enterprise strategy/planning, and IT portfolio management into a common set of IT management processes under the auspices of the CIO’s office. Ten percent will operate these integrated management disciplines outside the IT organization. • Value of Integrated Architecture: By 2007, 50% of Global 2000 enterprises will move beyond a pure technology architecture focus to include enterprise business architecture, enterprise information architecture, and enterprise solution architecture. Architecture teams that fail to move beyond the technical focus will come under increasing pressure to demonstrate business value. Source: META GROUP RESEARCH ~ EA TRENDS 2004 – 2005. So, EA Frameworks has to support the holistic perspective……… and more. . Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 6

Enterprise Architecture Frameworks History CIMOSA PERA SAGA Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 7

Enterprise Architecture Framework (Zachman) Characteristics: • Positioning Framework • Categorizing Deliverables • Limited usefulness EA • History in Manufacturing • Broad Acceptance • Limited Holistic Perspect. • Planning Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 8

Integrated Architecture Framework (Capgemini) Characteristics: • Positioning Framework • History in Enterprise Planning • Separation of Concerns • Categorizing Aspects • Limited Acceptance • Proprietary • Holistic Perspective. • Communication Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 9

NATO Architecture Framework / C 4 ISR / Do. DAF Business Organization Model Node Connectivity Model Information Flow Diagram Systems Conceptual Model Systems Logical Model System Physical Model Software Component Model Integration Model Implementation Model Characteristics: • Positioning Framework • History in Defence • Broad Defence Acceptance • Neutral • Limited Holistic Perspective. • Process / Planning Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 10

Extended Enterprise Architecture Framework (IFEAD) Characteristics: • Positioning Framework • History in (Extended) Enterprise Frameworks • Focusing on Collaboration • Separation of Concerns • Broad Acceptance • Neutral / Open • Complete Holistic Perspective. • Communication Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 11

Computer Integrated Manufacturing Open Systems Architecture (CIMOSA) CIMOSA Characteristics: • Process Framework • History in Manufacturing • Focusing on Views • Definition of Models • Limited Acceptance • European Initiative • Limited Holistic Perspective • Process Planning Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 12

The Open Group Architecture Framework (TOGAF v 8. x) Characteristics: • Enterprise Architecture Development Methodology • History in Defence • Open Standard • Neutral • Broad Acceptance • Holistic Perspective. • Process / Planning Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 13 Enterprise Edition

US - Federal Enterprise Architecture Framework (FEAF) Characteristics: • Enterprise Architecture Reference Framework • History in Enterprise Architecture Planning • US-Gov Standard • Broad US-Gov Acceptance • Holistic Perspective. • Planning & Communication Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 14

US - Treasury Enterprise Architecture Framework (TEAF) How, Where, and When Functional What, How Much, and How Frequently Who and Why Enabler Information Organisational Infrastructure Characteristics: • Positioning Framework • History in FEAF • US-Treasury Standard • Broad US-Treasury Acceptance • Limited Holistic Perspective. • Planning & Communication Tool Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 15

Conclusion • Most EA Frameworks have different evolutions • Most EA Frameworks serve different Purposes • Most EA Frameworks are different in Scope • Most EA Frameworks are based on different Principles • Most EA Frameworks have different Structures • Most EA Frameworks are supported by different approaches • Most EA Frameworks are different in compliancy with the Clinger Cohen Act So, the Question is: Do You Create or Choose your Enterprise Architecture Framework ISBN 1 -4120 -1607 -X http: //www. enterprise-architecture. info or http: //www. trafford. com/robots/03 -1984. html or at the author Http: //www. enterprise-architecture. info © 2004, Institute For Enterprise Architecture Developments / Capgemini - All Rights Reserved Page 16
