EKRA- 印刷機的應用範圍 Turn-key line for LTCC application

EKRA- 21/2 DTM 錫膏印刷品質檢視系統 系統檢查範圍: CCD Camera · 鋼板塞孔 · 錫量不足 · 錫膏短路 Substrate Diffused light is ON and Spot light is OFF. Pad Solder Paste Diffused light (Appears bright as light is reflected into the camera) CCD Camera Light Pad surface scattered reflects light away due to back to solder balls camera deflecting light Diffused light is OFF and Spot light is ON Substrate Pad Solder Paste (Appears dark as light is deflected away from camera) Principle of operation

EKRA- 全球的愛用者(一) • • • • Alcatel Aimtronics Applicad APIX Beltronics Blaupunkt Bosch Circuit Services C-Mac Daimler ETMA Fantom Enrg Ferroperm Fluke Grundig Hewlett – Packard • IBM • Integrex • Keja Electronics • Maschinen Fabrik • Mannesmann VDO • Megamos • MMC • MTI • NEC • Nokia (Espoo) • Osram • PCA • Pepperl & Fuchs • Hitachi • Philips Krefeld • Honeywell Centra • Selectron Lyss AG • Siemens Matsushita • Siegert • Smartflex • Thomson • Telect Corp • United Tritech • Via-Electronic • Pan Int'l Electronic • Pre. Nec • Robert Bosch • Astec • Pepperl & Fuchs • Philip Tuner

EKRA- 全球的愛用者(二) • • • • S. R. M Jetta Alco Beida Espco Computer Ltd Fabricator Int'l Fair Way Electronic Ltd Flextronic General Product Electronics Hunan Railway KAGA Electronics Ltd Philips LCD Polar Richrise S. MEGGA Technology Sea Power • Shang Tong Nan Tin Electronics • Silver • Zhejiang STYLY Group • Temic Shanghai Microsystems • W. H. Mandolyn • HTL • ICIL • Anam • Dae Han • Hanna • Mektec • Nanji • Samsung • ASTEC Power • Nexus Èlectronics

Vitronics- 加熱器之結構設計(一) • 三明治式將加熱鋁板夾在其中 • 溫度控制在 +/- 1 ºC Upper Plenum Heat Diffuser Heater Element Transport Direction Tunnel Heat Diffuser

Vitronics- 加熱穩定性

Vitronics- 加熱區及冷卻系統 (Polar Cooling) Stack Filter (optional) Controlled Exhaust (air amp. ) Flux Flow Control Nitrogen Baffle Heating Zones (top & bottom) Polar Cooling Zones Polar Cooling Pump and Reservoir Offload Fume Capture and Exhaust

Vitronics- 全球的愛用者 – – – – – Qualcomm SCI Avex Nat Steel Nortel Intel Motorola HCD MEICER – – – – Benchmark Matco JIT Omni IBM Amkor Rockwell TMC – – – – Hyundai CS 2 Samsung Chip. Pak Micron Abpack SPIL ASE

我們的主要客戶 航電 互億 泰詠 EKRA Printer 18 (Dek, MPM) 5 (Dek) 25 Vitronics Reflow 14 華寶 金寶 台表 5 6 20 4 47 (Heller (國產) (BTU) (ETC) ) 松永 10
