56 Years 1958 2014 The only Global Voluntary

56 Years 1958 - 2014 The only Global Voluntary Ship Reporting System in the World. 28, 497 Amver Participants 161 Countries J. R. Frost, USCG Office of Search and Rescue

Who Participates in Amver? Queen Mary II Pride of Baltimore II Knock Neivs Many Different Kinds of Vessels

Amver Communication Paths

Total Message Count for May 2014 911, 646

Amver. SEAS (SEAS 2000) Sending Weather Observations to the National Weather Services and Amver • Amver teamed up with NOAA to encourage vessels to participate in both the weather observation program and Amver by providing weather observation and position messages via INMARSAT C satellites. • Ships that meet the system requirements may send combined Amver/Weather observation messages free of charge.

Amver Message Statistics Messages received per day from July 1, 2001 to July 9 2014

Amver Daily Processing Statistics July 7, 2014 Results for Julian day: 188 � � � � Total messages received: 32, 175 Absolute Rejects: 348 Total messages processed: 31, 827 Number committed/processed by AMP: 29, 247 (92% Amver Processed) Number passed to rv/vr 3: 2580 (8% Corrected by the DCS Staff) Vessel not in database, NICSD: 186 Duplicate message detected: 2050 Failure conditions breakdown – (Messages with no AMP commit Resolution) � � � Message is missing required lines: 645 Could not properly predict track line: 415 Position report contains track lines: 7 Deviation report invalid: 15 Deviation check exceeds boundaries: 998 Port of arrival in message did not match database: 56 Reported current position time exceeds day boundaries: 191 Sail plan has no similar voyages in database: 41 Vessel not on plot: 32 Current position in sail plan exceeds deviation check boundaries: 2 Failed to obtain all required data for report type: 209

The Amver System at the OSC �SAR Controllers • Have one point of login to run an Amver SURPIC through SAROPS • Vessel Voyage Information and Reporting Information • Immediate access to vessel characteristic IHS Registar Fairplay information and Owner Info • Medical information from the SAR-Q is stored in the Amver database �System Support • 24 -hour Customer support • Round the clock duty analyst to address any system and or • • • commutation problem Four full-time support staff Nimsoft. Client for problem notification Enterprise Support staff trained to execute emergency SURPICs in the event of network down-time Full system redundancy in the event of hardware failures State-of-the-Art Hardware and Technology Disaster Recovery

Positioning the Vessels in Time This is an example Amver Sail Plan that is used by an Amver process that runs every fifteen minutes. This process moves the vessel in time along it’s intended SP leg according to it’s last reported course and speed. Producing a surpic_table of DR’d positions for all on plot vessels.

Report Validation Vessel Routing (RVVR)

Amver On Plot Statistics Vessels On Plot Per Day April 2004 to July 2014

Why Amver works… 7804 Vessels On Plot World Wide Observed at 12 Z on 03/11/2014

Amver Vessels On Plot January 2014 � For trend analysis, the Amver system takes a daily global "snapshot" of participating vessels. Using only the position, latitude, and longitude, a density plot is developed. This density plot is a total of all daily vessel positions for a specific month displayed within a global grid of cells. Each cell approximates a one-degree square (60 minutes in latitude and longitude). Major trade routes and highly traveled coastal and ocean areas of the world become evident, as well as those areas with very few sailings. Legend � Each colored dot displayed on the chart approximates a one-degree cell (60 minutes of latitude by 60 minutes of longitude) and is referred to as a "cell" in the legend below. � Monthly density plot totals: Red Cells : The monthly plot totaled over 51 vessels Orange Cells : The monthly plot totaled between 13 and 51 vessels Green Cells : The monthly plot totaled between 4 and 12 vessels Blue Cells : The monthly plot totaled 3 or fewer vessels Empty Cells : No vessels

Surpic Vessel Summary

Amver Awards Program BLUE pennant for a vessel completing its first year of participation and being honored for the first time. GOLD pennant for a vessel completing five consecutive years of eligibility for an Amver award PURPLE pennant for a vessel completing ten consecutive years of eligibility for an Amver award. 15 20 A ship completing fifteen years of consecutive Amver award eligibility will receive a wooden plaque in addition to the certificate and company letter. A ship completing twenty years of consecutive Amver award eligibility will receive an engraved pewter-alloy plate.

From the AMVER Website Bulk Carrier Makes First Amver Rescue of 2014 Amver Cases Reported Number of survivorsabandoned rescued: 24 Chinese seafarers Lives Assisted: ship and were rescued by an 337 398 125 Top Six Owner Countries Diverting: Amver ship 440 miles west of Guam on Monday, January 20, 2014. The Chinese seafarers abandoned their 500 -foot cargo ship after experiencing flooding Number of ships on average daily plot: Highest daily number ships on plot: and engine failure late of Sunday Ships receiving participation awards: evening. Japan (31) USA (40) Greece (22) Germany (25) Norway (9) Great Britain (11) 5, 474 7, 650 7, 613

AMVER Ship Saves Four Atlantic Rowers Four Atlantic rowers were plucked from their disabled rowboat by the AMVER participating bulker Hedvig Bulker 1, 356 miles west of Puerto Rico on Thursday, January 23, 2014. Lives saved by AMVER ships to date in 2014: 519

Amver �When preparing to visit a vessel please reach out to us and check to see if the vessel is enrolled and reporting to Amver. �Thank the master and crew for their Amver participation or ask them to join. �Additional information: http: //www. amver. com �Email: benjamin. m. strong@uscg. mil

Amver. com/Amver Blog For more information please visit www. amver. com

Questions?
