14 th January 2020 IBM Cloud Architecture Center

14 th January 2020 IBM Cloud Architecture Center Deploy a retail application on Red Hat Open. Shift Diagram Template Using the Diagram Template This template is for use in creating a visual representation of Deploy a retail application on Red Hat Open. Shift. • You may add numbers (which are provided on page 3) to the diagram to correspond to the runtime flow steps in your architecture. • See instructions on how to gray out icons and lines on Page 4 © Copyright IBM Corporation 2016

CLOUD NETWORK DATABASE SERVICES KUBERNETES CLUSTER BACKEND SERVICES FRONTEND SERVICES PUBLIC ROUTE BROWSER CATALOG ELASTICSEARCH CUSTOMER Couch. DB AUTHENTICATION KUBERNETES OR NODE PORT INGRESS OR NODE PORT INVENTORY My. SQL WEB ORDER LEGEND User Application Security Data 3 rd party components Maria. DB © Copyright IBM Corporation 2016

IBM Cloud Architecture Center Runtime numbers 1 2 3 4 5 6 7 8

IBM Cloud Architecture Center Gray Icons and Arrows for Background OFFLINE CAPABILITIES 1. Select icon and ungroup. 2. Select the icon background and change the fill color to R 221, G 221, B 221. This is a standard color. See the picture. 3. Change the text to the same color. 4. Regroup the icon. 5. Change background arrows to the same color. © Copyright IBM Corporation 2016
