1 Prints: The Language of Industry

• Identify the importance of prints. • Discuss historical processes and technologies related to prints. • Identify and define terms related to prints. • Explain how prints are produced. • Identify two important elements of print reading. Permission granted to reproduce for educational use only.

• Identify ways in which to care for prints. • Identify and discuss options for using prints in an electronic (digital) format. • Discuss the role of various organizations in the standardization of drawings. Permission granted to reproduce for educational use only.

Importance of Print Reading • Drawings are the universal language of industry • Engineers, designers, technicians, and skilled workers all use drawings • A print is a copy of a drawing Permission granted to reproduce for educational use only.

Importance of Print Reading • Prints provide the worker with the details of: – – – Size Shape Tolerance Materials used Finish Other special treatments Permission granted to reproduce for educational use only.

Print Reading and Drafting • Print reading is closely related to the study of drafting • Drafting is the field of study that focuses on the creation of technical drawings • Blueprint is a term originating from one of the earlier copying processes for technical drawings Permission granted to reproduce for educational use only.

Print Reading and Drafting • Prints used to be called blueprints Permission granted to reproduce for educational use only.

How Prints Are Made • Prints are basically a “hardcopy” of a drawing • CAD systems can create paper drawings using printers and plotters – Printers and cartridge-based plotters create raster images – Pen-based plotters create vector images Permission granted to reproduce for educational use only.

How Prints Are Made • Cartridge-based plotters create raster images Permission granted to reproduce for educational use only.

Print Reading Elements • Reading a print involves two principal elements: visualization and interpretation – Visualization is the ability to “see” the shape of the object based on the various views shown on a print – Interpretation is the ability to understand the meanings of the lines, symbols, dimensions, and notes on a print Permission granted to reproduce for educational use only.

Print Reading Elements • Visualization is “seeing” the object based on the views shown on a print Permission granted to reproduce for educational use only.

Care of Prints • When working with prints, observe these rules: – – Never write on a print Keep prints clean Be careful when folding and unfolding prints Do not lay sharp tools and parts on a print Permission granted to reproduce for educational use only.

Care of Prints • Use care when folding and unfolding prints Permission granted to reproduce for educational use only.

Electronic Formats for Drawings • Electronic formats are available that enhance the ability to share prints without sharing the actual CAD data – Portable document format (PDF) is a file format from Adobe and very common – Design web format (DWF) is a file format from Autodesk and common in environments that use Auto. CAD and other Autodesk products – Free viewers are available for both formats Permission granted to reproduce for educational use only.

Standards for Industrial Prints • A standard is a voluntary guideline • The standardization of engineering drawings for prints has long been established through the American Society for Mechanical Engineers (ASME) Permission granted to reproduce for educational use only.

Standards for Industrial Prints • The American Society for Mechanical Engineers (ASME) is the professional organization that authors and publishes engineering standards related to industrial prints Permission granted to reproduce for educational use only.

Standards for Industrial Prints • The American National Standards Institute (ANSI) is the umbrella organization that serves as an overseeing body for numerous American standards Permission granted to reproduce for educational use only.

Standards for Industrial Prints • The International Organization for Standardization (ISO) is an organization that provides over 18, 000 standards on a variety of subjects in the international and global arena Permission granted to reproduce for educational use only.

• List factors that make print reading important. Prints provide the details of size, shape, tolerances, materials used, finish, and other special treatments needed to manufacture a product Permission granted to reproduce for educational use only.

• Describe historical processes and technologies related to prints. An early copying process was a wet process that resulted in white lines on a blue background (a blueprint). A dry process (diazo) was later developed that resulted in blue lines on a white background (a whiteprint or blueline print). Today, prints are often output from a CAD system to an inkjet or laser printer/plotter. Permission granted to reproduce for educational use only.

• List some terms related to prints. Print, engineering graphics, blueprint, whiteprint, vellum, visualization, interpretation, and standards, among others Permission granted to reproduce for educational use only.

• In general, describe how prints are produced. A print is a copy of a drawing. Traditionally, a print was made with either a wet or dry process (blueprints and whiteprints), but now prints are often output from a CAD system to a printer or plotter. Permission granted to reproduce for educational use only.

• What are two important elements of print reading? Visualization and interpretation Permission granted to reproduce for educational use only.

• List four points related to the care of prints. A) Never write on a print B) Keep prints clean C) Very carefully fold and unfold prints D) Do not lay sharp objects on prints Permission granted to reproduce for educational use only.

• How can prints be used in electronic (digital) format? By distributing a DWF or PDF file, for example, to the print reader Permission granted to reproduce for educational use only.

• What are the two organizations that have a role in developing standards documents for engineering drawings? American Society of Mechanical Engineers (ASME) and International Organization for Standardization (ISO) Permission granted to reproduce for educational use only.
