Simple chemical tests 3 of 41 © Boardworks Ltd 2009

What is chemical analysis? During a chemical analysis scientists aim to identify an unknown substance. There are two major analytical methods: Chemical techniques: an unknown substance is reacted with a range of different substances. The substance is identified by characteristic reactions, such as those that produce a colour or state change. Instrumental techniques: an unknown substance is analysed using scientific instruments, which provide numerical data on the substance or its properties. This allows it to be identified. Chemical techniques often destroy the test substance in a reaction, so a large sample is needed. This is not the case for instrumental techniques. 4 of 41 © Boardworks Ltd 2009

Qualitative or quantitative? A qualitative analysis obtains non-numerical information about a substance and its properties. A quantitative analysis obtains numerical measures of a substance and its properties. Both can be used to identify an unknown substance. In general, chemical techniques tend to be qualitative, while instrumental techniques tend to be quantitative. Modern chemists tend to use instrumental techniques to identify compounds, as they are very accurate and preserve the original sample, unlike chemical techniques. 5 of 41 © Boardworks Ltd 2009

How do you perform qualitative analysis? When carrying out any analysis, it is crucial to carefully plan your method, ensuring every test improves your knowledge. Chemical tests can be split into two groups: l general tests – these help you to identify the nature of the chemical. Is it acid or alkali; covalent or ionic? l specific tests – these identify the molecules that make up a substance. General tests should be used early in your analysis. They should be informative, whatever the result, helping to narrow down your search. A specific test should be unique for that substance to prevent confusing results. 6 of 41 © Boardworks Ltd 2009

General tests What tests would you use to classify a substance into the following categories? Ionic or covalent: Ionic substances conduct electricity when liquid or when in solution, unlike covalent compounds. Acid or base: universal indicator neutralization: acid + base → salt + water Acids will react with most metals to produce hydrogen gas. Reactivity: 7 of 41 If you have a reactivity series, displacement reactions could be used to give a clearer idea of the metal present in an ionic compound. © Boardworks Ltd 2009

Acids and alkalis There are many ways to test a substance’s acidity, universal indicator being the most straight forward and informative. Identifying the p. H of a mystery substance can act as both a general and specific test: l General – knowing the p. H gives you a much smaller range of options for the substance’s identity. l Specific – a low p. H indicates the presence of H+ ions, while a high p. H reveals the presence of OH– ions in Hydrochloric acid (HCl) in solution, showing free H+ ions. 8 of 41 © Boardworks Ltd 2009

p. H as an indicator 9 of 41 © Boardworks Ltd 2009

10 of 41 © Boardworks Ltd 2009

Precipitation reactions An insoluble solid that forms during an aqueous reaction is called a precipitate. A reaction which forms a precipitate is called a precipitation reaction. The limewater test for carbon dioxide is a precipitation reaction. Limewater is actually a dilute solution of calcium hydroxide. The calcium hydroxide reacts with carbon dioxide to form calcium carbonate, which is insoluble in water: calcium carbon + hydroxide dioxide Ca(OH)2 11 of 41 + CO 2 calcium + water carbonate Ca. CO 3 + H 2 O © Boardworks Ltd 2009

Uses of precipitation reactions Most precipitation reactions are very fast reactions that occur between ions. This makes them very useful for identifying specific ions based on the type of precipitate formed. Precipitation reactions have a number of other uses: l production of coloured pigments for paints and dyes l removal of toxic chemicals from water l separation of reaction products. 12 of 41 A lead iodide precipitate. © Boardworks Ltd 2009

State symbols 13 of 41 © Boardworks Ltd 2009

Isolating the precipitate The precipitate from a precipitation reaction can be separated from the reaction mixture by filtration. Buchner funnel filter paper Buchner flask 14 of 41 vacuum pump A Buchner funnel and flask can be used to accelerate the process. This apparatus uses a vacuum pump to draw the mixture through the filter. The filtrate is finally washed and dried. © Boardworks Ltd 2009

Spectator ions In ionic precipitation reactions there are often ions that are not involved in the reaction. These are known as spectator ions. Na. I (aq) + Ag. NO 3 (aq) Ag. I (s) + Na. NO 3 (aq) The spectator ions are easily identified using the ionic equation. Na+ (aq) + I– (aq) + Ag+ (aq) + NO 3– (aq) Ag. I (s) + Na+ (aq) + NO 3– (aq) This equation shows that the silver and the iodine ions have reacted, joining together to make the precipitate. The sodium (Na+) and nitrate (NO 3–) ions are spectator ions. This means the ionic equation can be simplified to: I– (aq) + Ag+ (aq) 15 of 41 Ag. I (s) © Boardworks Ltd 2009

Which ions are spectators? 16 of 41 © Boardworks Ltd 2009

17 of 41 © Boardworks Ltd 2009

Making fireworks Many metal ions are used to give colour to fireworks. Metal ions can be identified by the unique colours of their flames. 18 of 41 © Boardworks Ltd 2009

How do flame tests work? 19 of 41 © Boardworks Ltd 2009

How to carry out a flame test 20 of 41 © Boardworks Ltd 2009

Identifying metal ions 21 of 41 © Boardworks Ltd 2009

22 of 41 © Boardworks Ltd 2009

Identifying positive ions Many metal ions can be identified by flame tests. However, precipitation reactions can also be used to identify positive ions, as many metals form hydroxide precipitates with characteristic colours. For example, when sodium hydroxide solution is added to a solution of iron (III) chloride, the reaction produces a brown precipitate of iron (III) hydroxide. iron (III) sodium + hydroxide chloride iron (III) sodium + chloride hydroxide Fe. Cl 3 (aq) + 3 Na. OH (aq) Fe(OH)3 (s) + 3 Na. Cl (aq) 23 of 41 © Boardworks Ltd 2009

Identifying positive ions: metals 24 of 41 © Boardworks Ltd 2009

Identifying positive ions: ammonium The ammonium ion (NH 4+) is a positive non-metal ion. It is found in substances like ammonium chloride (NH 4 Cl). The ammonium ion can be identified by adding sodium hydroxide solution. NH 4+ + OH– NH 3 + H 2 O Heating the mixture produces ammonia gas, which turns red litmus paper blue. This reaction can also be used as a test for hydroxide ions: addition of ammonium chloride will produce ammonia gas in the presence of hydroxide ions. 25 of 41 © Boardworks Ltd 2009

Summary – identifying positive ions 26 of 41 © Boardworks Ltd 2009

27 of 41 © Boardworks Ltd 2009

Identifying negative ions: carbonate Carbonates, which contain the CO 32– ion, are identified by the addition of a few drops of dilute hydrochloric acid. A colourless gas is given off as the carbonate ions react with the hydrogen ions. The ionic equation for this reaction is: CO 32– (aq) + 2 H+ (aq) CO 2 (g) + H 2 O (l) How would you check the limewater: identity of the gaseous goes cloudy with CO 2 product? What are the other products of this reaction? 28 of 41 © Boardworks Ltd 2009

Identifying negative ions: sulfite To identify the sulfite ion (SO 32–), add a small amount of dilute hydrochloric acid. The acidic gas, sulfur dioxide, is produced when the sulfite ions react with the acid’s hydrogen ions. The ionic equation for this reaction is: SO 32– (aq) + 2 H+ (aq) blue litmus paper SO 2 (g) + H 2 O (l) How could you show that the gas is acidic? 29 of 41 © Boardworks Ltd 2009

Identifying negative ions: nitrate The nitrate ion (NO 3–) can be identified by heating the solution with aluminium powder and sodium hydroxide solution. The aluminium reduces the nitrate ion to ammonia on heating. This is released as a gas and can be easily identified. The ionic equation for this reaction is: 3 NO 3– (aq) + 8 Al (s) + 5 OH– (aq) + 18 H 2 O (l) 3 NH 3 (g) + 8 Al(OH)4– (aq) How could you confirm that the gas given off is ammonia? How can you tell that this is a reduction reaction? 30 of 41 © Boardworks Ltd 2009

Identifying negative ions: sulfate Sulfate ions (SO 42–) are identified by adding a few drops of barium chloride solution. The solution must be acidified first with a few drops of hydrochloric acid. A white precipitate of barium sulfate forms. sodium sulfate Na 2 SO 4 (aq) + barium chloride + Ba. Cl 2 (aq) barium sulfate sodium + chloride Ba. SO 4 (s) + 2 Na. Cl (aq) The ionic equation for this reaction is: SO 42– (aq) + Ba 2+ (aq) 31 of 41 Ba. SO 4 (s) © Boardworks Ltd 2009

Chemical analysis 32 of 41 © Boardworks Ltd 2009

Identifying negative ions: halides Halide ions are formed from the Group VII elements, the halogens. Halides are detected using silver nitrate solution. The substance to be tested is first acidified with a small amount of nitric acid before adding the silver nitrate solution. If halides are present, a precipitate will form. The precipitates formed are silver halides: sodium + chloride silver nitrate Na. Cl (aq) + Ag. NO 3 (aq) Cl– (aq) 33 of 41 + Ag+ (aq) silver + chloride sodium nitrate Ag. Cl (s) + Na. NO 3 (aq) Ag. Cl (s) © Boardworks Ltd 2009

Silver halides The different silver halide precipitates can be distinguished by their differing colours. chloride bromide iodide white Ag. Cl precipitate cream Ag. Br precipitate yellow Ag. I precipitate 34 of 41 © Boardworks Ltd 2009
