1 2 ATS PDF ATS 42 U 2000

1. Система серверных шкафов 2. Шкафы электропитания ATS и PDF ATS Ø Вместимость: 42 U Ø Размеры : 2000 x 1100 x 600. Шкаф HUAWEI TECHNOLOGIES CO. , LTD. Item Specifications Surge protection level Class II/C, 8/20 us Nominal discharge current Maximum Discharge Current Installation 20 k. A 40 k. A Mounted on a wall Page 3 Item Function Voltage Frequency Input Protection performance Dimensions Specifications Applies to IT loads consuming 0 to 16 k. W. Three-phase 380 V or 220 V 50 Hz or 60 Hz One three-pole 125 A input 20 k. A, 8/20 us 1100 x 600 x 2, 000

2. Блок розеток-PDU 2. ИБП Item Specifications Function Applies to 0 -16 k. W IT loads in the 50 Hz or 60 Hz AC power distribution scenario. Voltage Three-phase, 380, 400, or 415 V AC Frequency 50 Hz or 60 Hz Input power factor 0. 99(full load) Efficiency of the whole unit ≥ 94% Noise ≤ 58 d. B Каждая батарея 12 V, всего 32 батареи в шкафу , 384 V. 105%-125% for 5 minutes Overload 120%-150 for 60 seconds ≥ 150% for 200 ms UPS: 130 mm x 435 mm x 750 mm Dimensions Battery cabinet: 2000 mm x 600 mm x 1100 mm Protection level IP 20 HUAWEI TECHNOLOGIES CO. , LTD. 2. Батареи Page 4
